LIFETONE HL
Bedside Fire Alarm
& Clock
Sleep Safely
User's Manual
MODEL HLAC151
Lifetone Model No. HLAC151 Single- and/or Multiple-station Smoke Alarm Accessory.
S24639: UTGT, UTGT7, UUKC Low frequency sounder. Listed by UL to UL 217
and ULC S531 for use with residential smoke alarms and commercial noti cation
appliances in US and Canada, and listed to UL 1971 when used with bed shaker.
NFPA 72 compliant, editions 2010 - 2013 .
TM
TM
ENGLISH
.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LIFETONE HLAC151
Summary of Contents for LIFETONE HLAC151
- Page 1 User’s Manual ENGLISH MODEL HLAC151 Lifetone Model No. HLAC151 Single- and/or Multiple-station Smoke Alarm Accessory. S24639: UTGT, UTGT7, UUKC Low frequency sounder. Listed by UL to UL 217 and ULC S531 for use with residential smoke alarms and commercial noti cation appliances in US and Canada, and listed to UL 1971 when used with bed shaker.
-
Page 2: Table Of Contents
Sleep Safely USER'S MANUAL MODEL HLAC151 PLEASE READ THIS USER’S MANUAL COMPLETELY AND THOROUGHLY BEFORE BEGINING! I. INTRODUCTION..........................2 II. LIFETONE HL™ BEDSIDE FIRE ALARM AND CLOCK............A. CONTROLS AND DISPLAY....................3 B. FEATURES..........................3 III. WARNINGS............................. 4 IV. -
Page 3: Introduction
The product also gives its emergency signals visually on a display screen and with an optional tactile Bed Shaker, either of which may be detected by deaf individuals in their beds. The Lifetone HL™ Fire Alarm is not intended for use in marine watercraft, recreational vehicles (RVs), mobile homes, or hospitals. -
Page 4: Lifetone Hl™ Bedside Fire Alarm And Clock
10-15 seconds. 5. In the event of a power failure, the Lifetone HL™ can operate in battery backup mode for a minimum of 7 days and still provide emergency alarm signals. -
Page 5: Warnings
WARNING! ALWAYS keep noise levels in your home to a maximum of 70 dB or lower. Excessive noise levels may obstruct the emergency signals given by your existing smoke alarm to the Lifetone HL™ Fire Alarm, which may result in personal injury or death. -
Page 6: Operating Instructions
Investigate further until you are satisfied that your existing smoke alarms are UL listed and compliant T3 smoke alarms. Do not use the Lifetone HL ™ Fire Alarm with First Alert talking alarms made prior to 24 October 2011. Some may pass the setup test, but have a variable-length T3 emergency signal that is not UL 217 compliant (UL-217 6th Ed, 34.3.2b) and cannot be recognized... - Page 7 3. Keep noise levels in your home to a reasonable minimum during use. Your Lifetone HL™ Fire Alarm is at its best in a quiet environment next to your bed or in a nighttime sleeping area. Excessive noise may mask an emergency signal from your smoke alarms and may increase the amount of time to detect that signal.
-
Page 8: Before Installing
VI. INSTALLATION AND ACTIVATION A. LOCATION OF THE LIFETONE HL™ 1. Place the Lifetone HL™ next to your bed and 3 feet from where your head will be. 2. Face the speaker toward the pillow. Remove battery B. -
Page 9: Smoke Alarm Setup Test
TELL THEM YOUR TESTS ARE COMPLETED. ________________________________________________ 1. Your HLAC151 will say "At the tone, test your smoke alarm" and then it will sound a tone. Locate the most distant smoke alarm you want detected. If you have an interconnected alarm system, use the nearest smoke alarm. It is recommended you use an alarm that is easy to reach and activate , avoiding alarms on high ceilings. -
Page 10: Setting The Clock
D. SETTING THE CLOCK NOTE: If at any time during this process you need to start over, press and hold “SET CLOCK” until the flashing “12 hr” appears, and repeat the steps below. Buttons on the top of the Lifetone HL™. HOUR MINUTE... -
Page 11: Setting The Wake-Up Alarm
Or you can press ON/OFF to stop the alarm. It will go off again 24 hours later. 7. You can adjust the volume of your wake-up alarm to sound Low or Hi. The HI-LO switch is located on the top of the Lifetone HL™. During a fire emergency the alarm volume will automatically switch to high. -
Page 12: Testing The Lifetone Hl
FLASHING Lifetone HLAC151™. • The audio sensitivity test. To test the audio sensitivity of your HLAC151™ with your smoke alarm, press the test button on your nearest installed smoke alarm during the 2 minutes that the icon is displayed. -
Page 13: Unsuccessful Smoke Alarm Setup Test
H. UNSUCCESSFUL SMOKE ALARM SETUP TEST If the HLAC did not flash “FIRE” and sound an alarm, your existing smoke alarms were not detected or are not compatible with the LIFETONE HL™. Check the following conditions: • Is your smoke alarm a UL 217 listed and compliant T3 smoke alarm? Beginning in 1999, most residential building codes required UL 217 listed or compliant T3 smoke alarms. -
Page 14: Using The Lifetone Hl
5 seconds. D. OPTIONAL BED SHAKER USE AND CARE 1. The Lifetone Bed Shaker may be placed under the mattress pad or the pillow. 2. It is water resistant but not waterproof. It may be cleaned periodically with soap and a damp cloth. -
Page 15: Regular Maintenance
(2) years from the date of purchase, this product will be free from defects in material and workmanship. Lifetone, at its option, will repair or replace this product or any component of the product found to be defective during the warranty period. - Page 16 Lifetone dealers, service centers, retail stores and Internet purchase agents selling Lifetone products do not have the right to alter, modify or any way change the terms and conditions of this warranty. This warranty does not cover normal wear of parts or...
-
Page 17: Recommended Locations For Smoke Alarms
Consult your state and municipal codes for additional recommendations and requirements for smoke alarm installation. Copyright Lifetone Technology, Inc. All Rights Reserved, 2010, 2011, 2012 -16- English...
