Huviron SK-RH04, SK-RH08 Quick Manual

HD DVR Quick Guide
Model No.SK-RH04, SK-RH08
Thank you for purchasing our product. If there is any
question or request, please do not hesitate to contact
dealer. This manual is applicable to SK-RH04, SK-
RH08.

Chapter 1. Hard Disk Installation

Before you start
:
Before installing a hard disk drive (HDD), please make sure the
power is disconnected from the DVR. A factory recommended
HDD should be used for this installation.
1) Remove the cover from the DVR by unfastening the screws on
the back and side.
2) Connect the HDD to the motherboard of the DVR with the
included data cable.
- 1 -
2) Click the Shutdown button to enter the following dialog box:
3) Click the Yes button. The following message box pops
up:
4) Turn off the power switch on the rear panel of DVR.
- 5 -
3) Connect the power cable to the HDD
4) Re-install the cover of the DVR and fasten screws.

Chapter 2. Rear Panel

Rear Panel of SK-RH08
- 2 -

Chapter 5. Using the Setup Wizard

The Setup Wizard can walk you through some important settings
of the device. By default, the Setup Wizard starts once the
device has loaded.
Operating the Setup Wizard:
1) Please select the output resolution, which must be the same with
the resolution of the monitor screen.
2) The Setup Wizard can walk you through some important
settings of the DVR. If you don't want to use the Setup
Wizard at this time,
click the Cancel button. You can also choose to use the
Setup Wizard next time by leaving the "Start wizard when
DVR starts?"
checkbox in checked status
- 6 -
No. Item Description
1 VIDEO IN HD-SDI interface for video input.
2 VIDEO OUT RCA connector.
3 AUDIO OUT RCA connector.
DB9 connector for VGA output. Display local
4 VGA
video output and menu.
5 HDMI HDMI video output connector.
6 USB Port Universal Serial Bus (USB) port for additional devices.
7 Network Interface Connector for network
8 RS-485 Interface Connector for RS-485 devices.
9 Power Supply DC 12V power supply
10 Power Switch Switch for turning on/off the device
11 GND Ground

Chapter 3. RS-485 Connections

To connect RS-485 devices (e.g., pan/tilt unit) to the DVR:
Press and hold the orange part of the pluggable block; insert signal
cables into slots and release the orange part. Ensure signal cables
are in tight.
Note: Make sure the pan/tilt receiver unit is connected to the
D+ and D- of the RS-485 terminal of DVR.
- 3 -
3) Click Next button on the Wizard window to enter the Login
window.
4) Enter the admin password. By default, the password is 12345.
5) To change the admin password, check the New Admin Pass
word checkbox. Enter the new password and confirm the pass
word in the given fields.
6) Click the Next button to enter the date and time settings
window.
7) After the time settings, click Next button which will take you
back to the Network Setup Wizard window.
- 7 -

Chapter 4. Startup and Shutdown

Proper startup and shutdown procedures are crucial to expand
ing the life of the DVR.
Before you start:
Check that the voltage of the extra power supply is the same
with the device's requirement, and the ground connection is
working properly.
Starting up the device:
Steps:
1) Check the power supply is plugged into an electrical outlet. It is
HIGHLY recommended that an Uninterruptible Power Supply (UPS)
be used in conjunction with the device.
2) Press the POWER button on the rear panel. The Power indicator
LED should turn green indicating that the unit begins to start up.
Shutting down the device:
Steps:
1) Enter the Shutdown menu.
Menu > Shutdown
- 4 -
8) Click Next button after you having configured the network
parameters,which will take you to the HDD Management
window.
9) To initialize the HDD, click the Init button. Initialization will
remove all the data saved in the HDD.
10) Click Next button to enter the Record Settings window.
11) Click Copy to copy the settings to other channels
12) Click OK to save the settings and exit the wizard.
- 8 -
