KiSS DP-508 Manual

DVD P l ay e r K iS S D P - 5 0 8
english français
Congratulations on your new KiSS DP-508
The many different functions provided by your new DVD Player will be a source of pleasure to you for many years to come. Naturally, you can play and watch DVD
films with superb audio and visual quality. You can watch films in many other formats than DVD, such as MPEG-4, XviD, DivX. The audio features also give you the
option of playing music CDs, MP3 or Ogg Vorbis files. The DP-508 automatically recognises each format and can read CD-RW and DVD-RW alike. Your new DP-508
also supports Picture CDs (jpg), which means that you can display your photos directly on the TV screen. This includes the pictures developed at the photo shop
and any photos you have scanned and saved on a CD yourself.
Note: Do not use the DVD Player until you have studied the quick setup menu. To do so, the DVD Player must be connected to a TV set.
accessories
1
Make sure the following accessories are included with your DVD Player.
KiSS PC-Link Software CD
Batteries for the Remote Control

Remote Control

[size "AAA" (R6P)]
Power Cable Audio Cable SCART S-Video
(Provided in Europe only) (Not Provided in Europe)
playing medias
6
The DVD Player supports the following media: DVD Video, DivX, XviD, ISO MPEG-4, Audio CD, MP3, Ogg Vorbis and JPG.

DVD Menu

If you have adjusted your DVD Player according to the instructions above, you can now insert a DVD into your DVD Player.
A moment later, the DVD menu will appear. Use the arrow buttons to navigate in the menu and start the film.
Note: As this menu is part of the DVD itself, it will vary from one DVD to another.

CD, MP3 and Ogg Vorbis

When you insert an audio CD or a disc with MP3 or Ogg Vorbis files, the player will automatically recognise the format
and start playing it. You can use next/previous track or you can use the menu to navigate through the file structure, and
select the song you want to hear by pressing enter.

DivX, XviD and MPEG-4

The DP-508 recognises the format and automatically starts playing the CD when you insert it into the drive. Use the
counter in the display to help you to see where you are in the film. You have access to the usual playback options, such
as stop, pause, go to next, time search, etc.

Photo CD and Jpeg

The DP-508 can show photos on your TV. The photos must be stored in JPEG format on a Disc. The player will
automatically recognise the files, and start showing them as a slide show. In the menu you can navigate to find a
specific photo, and start the slide show from here by pressing enter.
advanced functions
7
A number of advanced functions are located on the lower section of the remote control. These functions are described below.
Some functions may not work with all media formats.
STEP the players' hard disk. To do so, just view the side of the screen will show information about
This function is not used list of items already saved, and select the one the film's length, the number of chapters, the
to remove. language options and the number of subtitles.
AUDIO
Press the (AUDIO) button to change the sound SRCH If the DVD player is turned on, but not playing
format. The audio format options, such as two- Use (SRCH) to find a specific spot on the disk. films or other media, pressing this button will
channel stereo and six-channel surround, are Time: Specify time, minutes and seconds take you to a menu, where you can configure
determined by the film producer. Title/Chapter: Find the title or the chapter your DVD player. Here you can select the default
settings for language, sound, video, parental
ZOOM ANGLE level, etc.
When watching the film, you can zoom in on If the film supports more than one camera angle,
specific areas. You can zoom in either as the film you can switch from one angle to another by
is playing or after you have paused it. Activate pressing the (ANGLE) button. These buttons are used for increasing and
the function by pressing the (ZOOM) button, decreasing the sound volume.
and return to the normal picture by pressing the SUBPIC
button again. Use this button to change the film's subtitles. MARK
TIP: Use the arrow buttons to move around the If you press the (SUBPIC) button, a message This button is used to select
enlarged screen display. will appear in the top left corner of the screen files for copy or deletion
indicating the number of available languages and
the language that is currently active. If you press
REPEAT
the (SUBPIC) button again, you go to the next
As the film is playing, press the (REPEAT) button
language option. The number of languages is also
and three options will appear on the screen.
determined by the film's producer.
MODE: Shuffle (random chapter playing) or Off
(deactivated)
SETUP
Repeat: Lets you decide whether to repeat the
If the DVD Player is in the process of showing a
section or the entire film.
film or playing music, press the (SETUP) button to
see the available options on the disk. For instance,
DELETE
Use this function to delete any files stored on if you are watching a DVD film, the left-hand
overview
Discover the player in all its angles

Front panel

The front panel has the standard buttons listed below. When the disk tray is open, push the end of the tray to close it.
2
1
Option on the Setup Menu
1. On/Off 9. Fast Forward
11. Enter
2. CD Tray 10. Menu
3. Open/Close 12. Navigate Left
4. Play/Pause 13. Navigate Right
2
5. Stop 14. Navigate Up
6. Previous Chapter 15. Navigate Down
7. Next Chapter 16. Close
8. Rewind

Back panel

Detailed overview of the back panel
6
8 1 2 3 4 5
1. Ordinary Stereo Output
2. Composite Video Output for TV
3. S-Video Output for TV
4. Coaxial Output for Amplifi er
5. Optical Output for Amplifi er
6. SCART for TV
7. AC Input
8. Ethernet
Display
The DVD Player is equipped with a VFD display which indicates the current ongoing activities.
1 2
4
3
1. Indicates the selection of the disk being played
2. Indicates the track, chapter or program being played
KiSS DVD Player DP-508
3. Indicates the status on the source or the media playing
4. Indicates the type of media being played

Remote

The Player is delivered with a standard remote control. All the player's functions can be performed from it.
1. Standby 9. Right Arrow 17. Select lang/Audio
2. Open Close 10. Down Arrow 18. Next Picture
3. Title/Menu 11. Rewind 19. Select Subtitle
4. Menu 12. Play/Pause 20. Select Angle
5. Return 13. Fast Forward 21 Zoom
6. Up Arrow 14. Previous Chapter 22 Repeat
7. Left Arrow 15. Stop 23 Unused
Composite Video
8. Enter 16. Next Chapter 24 Setup
webradio
8
WebRadio enables you to listen to a great number of radio stations via the
internet. Remember that all the functions discussed below are only available if
your player is properly connected (see connecting section).
Accessing WebRadio
WebRadio, comes as a user friendly way of listening to internet radio on your DP-
508 DVD Player. Just select the WebRadio function on the player's main screen.
Listening WebRadio
The WebRadio interface is relatively simple to use. It enables you to browse and
select any Internet radio station available. The browsing is done by genre (Pop/Rock,
Classical, Jazz...) or by country. Once selected, just press "enter".
Favorites
The radio stations can also be saved in the "favorites" menu, enabling you to reach
them quickly.
Help and Info
More info, news about updates and full help will be available from: webradio2.kiss-
technology.com
KiSS PC-Link
9
KiSS PC-Link enables you to connect your computer to your DVD player through the KiSS PC-Link software. You can therefore play,
watch or listen to your PC files on your TV via the KiSS DP-508.
Note: Clicking the search function will help your computer to find your multimedia files
Installing the software
The KiSS PC-Link software must be installed on your computer, it is PC compatible and requires a
machine running minimum Microsoft Windows 98, Internet Explorer 4. After inserting the disk, the
installation program will start automatically, if not double click the "Setup" icon on your CD. Select your
preferred language and click "Next". Once the installation is completed, the KiSS PC-Link programme
will open. The main window is divided into four folders, Audio, Video, Pictures and Info.
Accessing your files on the DP-508
After connecting your PC to your DP-508 (see Connection Chapter) and entering your computer IP
address on your DVD player (see Quick Setup Chapter), press the "Menu" button on your remote control
and choose PC-Link. Then from the submenu you can access, Audio, Video or Pictures. If there are more
than one computer running KiSS PC-Link, a menu in the player allows you to browse the network for
other connected PCs. You can also press the "browse network" icon on the main screen.
KiSS PC-Link Audio Panel
KiSS PC-Link Pictures Panel
Drag and drop the audio files you would like to access from your DP-508.
Direct access to the picture fi les located on your PC. These can be selected
You can create folders with your favourite music or specific types of music. or dragged and dropped. You can also tidy them into a folder from the KISS
You can easily add, remove or move the files either by using the window PC-link window.
buttons or right clicking on the mouse and select an action.
KiSS PC-Link Info Panel
KiSS PC-Link Video Panel
You will fi nd your computer IP address located in this panel. This has to be
Drag and drop or select a movie fi le through the search window. As for entered in the last menu of the Quick Setup (see Quick Setup Chapter). This
the Audio Panel you can defi ne actions by selecting, pressing the window menu also enables you to "Check for Updates" and access the KiSS web
buttons or right-click a fi le. site.
connecting
Refer to the illustration below to connect your Player to any video or audio system. The PC to DVD illustration will also show you how to adapt
your player to your current network settings.

Video Connection

Connecting your KiSS DP-508 DVD player to your TV can be done with any of the cables below. (Only one cable can be
connected at a time)
1 RGB via SCART
7 9
2 S-Video (the cable is an extra accessory)
3 5 13 15
3 Composite via SCART
4 6 8 10
4 Composite Video
11 12 14 16 5 Component SCART
(the cable is an extra accessory)

Audio Connection

Connecting your KiSS DP-508 DVD player to your amplifier can be done with any of the cables below. (Only one cable can be connected at a time)
3
6
Optical output (the cable is an extra accessory)
1 7 Coaxial output
(the cable is an extra accessory)
8 Analogue Stereo
PC to DVD Connection
7
Below are four examples of connection for your DP-508 to a PC enabling use of all its features and programmes.
1. Connection to Router with Built-in Switch
2 3 4 5
6
KiSS DP-508
7 8 Router PC
9
10
11 13
12 2. Connection to Router and Switch
14 16
15
KiSS DP-508 Switch
18 19 20 PC
17
23 24
21 Router
22
25 28
26 27
3. Connection to Switch.
(The DHCP Server needs to be installed on the PC)
KiSS DP-508
Switch
PC
4. Straight Connection with Cross-Over Cable.
25 Delete (The DHCP Server needs to be installed on the PC)
26 Search
27. Volume +
KiSS DP-508
28. Volume -
PC
Note:
Certain functions will only work if
supported by the media.
Cross-Over Cable
hard disk functions
10
KiSS DP-508 holds an 80GB Hard Disk enabling you to store Audio/Video/Picture content on it.
Only computer generated files can be stored on the Hard Disk. DVDs, Audio CDs, SVCDs (all type
of SVCDs), VCDs can not be copied.
Access the Hard Disk
The DP-508 is equipped with a built-in 80GB Hard Disk. To access it, select the Hard Disk icon on
the main screen. You can now make you selection between playing video, listening to audio, view
pictures or view hard Disk's infos.
Copying files on the Hard Disk
There are two ways of copying files on the DP-508's Hard Disk.
1. From a CD. Insert a CD in the Player's drive. The DP-508 will automatically recognise the format
and start to play the disc's content. Press the "Menu" button on the remote to access the list of files storted on the CD, select the file(s) to copy using
the "Mark" button, and press the "Enter" button on the remote. This will instantly copy the file from the CD to the Hard Disk. If the CD contains MP3
files, there is no need to press the "Menu" button on the remote, as the list of files will appear automatically.
2. From PC-Link Software. Once PC-Link is correctly running (see the connection and PC-Link sections for details). Press the "Menu" button on the
remote, choose KiSS PC-Link from the left list of icons. Make your selection between audio/video/picture files, and choose the file to be copied using the
"Mark" button. Once selected, hit the "Enter" button from the remote. The file is being copied from the PC to the Player over the network.
In these two cases, both files or folders can be copied.
Deleting files on the Hard Disk
To delete files on the hard Disk, press "Menu" on the remote to access the hard Disk functions. Choose within Audio/Video/Picture the file to delete.
Once selected, press the "Delete" button of the remote. The file will instantly be removed.
Getting infos and Formatting the Hard Disk
To format the Hard Disk (Erasing all its content). Press "Menu" on the remote control, and, choose Hard Disk from the left list of icons. The Player will ask
you to choose between Audio/Video/Picture or Info. Select info. This menu shows you how much space available the hard Disk holds. An option, at the
bottom also enables you to "Clean the Hard Disk" (Format). Selecting this function will erase all content stored on the Players Hard Disk.

software update

11
KiSS players get regularly updated enabling new functions or improvements. An internet connection and a CD Burner are required for this
operation
Updating the Player
Once the CD is burnt with the firmware update, it needs to be loaded in the player
which will read it. A message will come up on the screen asking to restart the DVD
Player. This should be done from the on/off button on the front panel. The CD is being
loaded, this action might take a little time. The Firmware Update Screen comes up on
the TV, and two options can be selected, Full Update or Partial Update. Full update,
updates the firmware and resets the player to its factory settings. Partial Update,
only updates the firmware. KiSS recommends users to use Full Update. The player is
being updated, which might take up to a minute. Restart is needed. To verify if the
player has been well updated, once it's back up, press "Setup", the number of the
current firmware is written on the top left corner of the screen.
quick setup
If your DVD Player is correctly connected (see the chapter on cable connections), a menu will appear when you turn on the DVD Player. The menu
installs the most important settings for your TV set and language.
Note: If this menu does not appear when you start the DVD Player, recheck the cable connections.
Note: Try connecting your TV set using the Composite Video cables. Composite Video always produces a picture.
1 Language
KiSS DP-508
TV
Select the language that will
1 3 5 4 2
be used whenever you open
the DP-508's built-in menus.
Use the arrow buttons on
the remote control to move
the rectangular frame to the
language you wish to select
and press ENTER.
KiSS DP-508 Amplifier
You can always go back and start again if you happen to do something wrong,
8 7 6
Just press on the setup button of your remote, go to miscellaneous settings and
select Quick Setup.
Note: Your KiSS PC-Link software will ONLY work if the KiSS DP-508 is provided
with a valid IP address.
Connection with a Router Based Internet Connection without a Router
Connection (illustration: 1 and 2) (Illustration: 3 and 4)
Needed Equipment
Needed Equipment
advanced setup
1. A router, with a build-in switch or a separate 1. Switch/hub and 2 straight cables or a cross
switch/hub. cable.
2. 2 or 3 straight Ethernet cables.
2. A windows PC with an Ethernet connection.
3. A Windows PC with an Ethernet connection. 3. DHCP program (ex: Magic DHCP) or a player
You can always access the Setup menu and adjust the DP-508 to your specific requirements and
4. The KiSS PC-link program. with fi rmware 2.7.1 or later.
hardware. Select "Setup" from the main screen or press the SETUP button on your remote control, and
4. The PC-link program.
a menu will appear with the available options. The orange frame shows your position on the menu.
Step by Step Guide
Use the arrow buttons to move the frame and select by pressing the ENTER button. The settings on
1. Connect both the PC and the player to the Step by Step Guide.
some of the menus have already been determined under Quick setup, but there are several settings
router or switch/hub with straight cables
1. Connect the player either straight to the PC available under Advanced setup as well.
2. Connect the router to the switch/hub via the
with the cross cable or through the switch
uplink connection. with the straight cables.
3. Install the PC-link program on the PC 2. Install the DHCP program, confi gure the
4. Check which IP address is given to the PC in Language Settings
program to have and IP range and reboot the
the PC-link program under info computer.
The first menu is the Language settings menu. Here you select the language
5. Insert this IP in the DP-508 and try to connect 3. Install the PC-link program and make sure that
you wish to use for the menus, that will appear on the screen, and your
to the PC–link program
the computer's IP are in the IP-range
preferred language when playing a DVD film – for subtitles, speech and
confi gured in the DHCP program.
menus (they will only be used if the film supports the language).
Now the DP-508 should be connected 4. Turn on the DP-508 and check in the DHCP
program under leases that the player
Possible errors.
receives an IP
• Cable problem, check that there is light in all 5. Try to connect the player to the PC-link
the ports in the switch/hub
program and stream audio, video or pictures
Audio Settings
• There is installed a fi rewall on the PC, that
blocks the ports that the PC-link program uses If you have confi gured the DHCP program
KiSS has tuned the product to give you the best possible sound experience
(port 8000 must be open) correctly then the player should be able to
(Loudness). Under acoustic setup, you can neutralize these settings or
• The player and the PC are not on the same
connect to the PC. enhance them further by selecting dynamic sound. Speaker size is used
subnet (problem with playing video) to make the right bass management. When using small front speakers, try
• Your PC has been assigned a new IP address Possible errors. to place the subwoofer between the front speakers. Speakers level let you
from the DHCP server, which differs form the change the level on the speakers individually. Select the channel you want
• Cable problem, check that there is light in all
to change and use the volume buttons to adjust up and down.
one enter in the player. (Solution use a static IP the ports in the switch/hub
on the PC) • There is installed a fi rewall on the PC, that
blocks the ports that the PC-link program uses
Note: Progressive scan only works on Component video output. This connection gives the best video quality. Only select Component Progressive if your
(port 8000 must be open)
TV supports it. To leave a menu, press the left arrow on the remote control.
support
More information or assistance is available at KiSS Technology's website
under End User/Support/After sales for DVD Player.
Address: www.kiss-technology.com

Resetting

To reset the settings of the DP-508, press the following buttons on the remote
control: "Open", "Clear", "1", "2", "3". KiSS Technology A/S reserves the right to
change all settings and specifications without notice.
Important safety information
• Read these instructions carefully and pay attention to all warnings and
guidelines.
• Do not overload electrical sockets or extension cables. Overloading can result
in fire or electric shock.
• Never insert objects into the DVD player's cabinet door. They might come
into contact with dangerous voltage points or short-circuit components,
which can cause fire or electric shock.
• Do not spill liquids on the DVD player.
• If the DVD Player does not function normally, or if it emits unusual sounds
or odours, pull out the plug immediately and contact an authorised technician.
• Do not attempt to service the DVD player yourself. If you open or dismantle
the shielding, you expose yourself to dangerous voltage and other hazards.
All maintenance must be carried out by qualified service technicians.
Environmental information
• The system is made of recyclable materials which can be reused if
disassembled by authorised personnel.
• Please follow local regulations for the disposal of packaging
materials, used batteries and discarded units.
Copyright
This product contains copyright technology which is protected pursuant
to the patents that are the property of Macrovision Corporation and other
copyright holders. Any use of this copyright technology must be approved by
Macrovision Corporation. The technology is intended for use in the home unless
otherwise approved by Macrovision Corporation. Breakdown and disassembly
are prohibited.
Made under license from Dolby Laboratories. "Dolby" and the double "D"
symbol are trademarks of Dolby Laboratories. "DTS" and "DTS Digital Out" are
trademarks of Digital Theater Systems, Inc.
Getting the Firmware
Warranty certificate
KiSS provides a twenty-four (24) month warranty from the date of purchase
KiSS Players firmware updates can be found on KiSS Technology's home page.
Under www.kiss-technology.com, "end user" section, then "support". Once on the against material and manufacturing defects. For defects covered by the
support page, choose "upgrade". Select the player to upgrade from the list, and warranty, the product must be returned to the dealer that sold the product.
choose between PAL (Europe and Asia) or NTSC (US and Japan). The file should
download on the PC's Hard Disk. KiSS recommends Nero if burning the CD on a PC
Terms of Warranty
and Toast if burning on a Mac. The file is a Disc Image and has to be burnt as such.
1. The warranty is only valid on presentation of the original sales receipt, and
Make sure that "Disc at Once" and "Finalize CD" in Nero are selected or "Write Disc"
if the serial number on the product is fully legible.
and "Verify CD" in Toast are enabled. If not, an error could occur while updating the
2. The obligations of KiSS are limited either to repair or replacement of
player. More info are available in the "How to Burn" Section of the Support Page.
defective components. The repair or replacement of defective components
is based on an assessment by KiSS. Exchange is only possible if the repair
cannot be performed.
3. Warranty repairs must be carried out by an authorised KiSS dealer, or an
authorised service centre. No remuneration is provided for repairs
performed by unauthorised workshops. Any repairs or damage to the
product caused by unauthorised intervention are not covered by this
warranty.
DVD films are normally supplied with a regional code (1),
(2), etc., and can only be played on DVD players/Players
with the same regional code. You can see the region on
the back of the player. Region tags appear as follows:
4
2 Video 3 TV 4 Audio 5 IP Address
Select the video connection This screen presents two If your TV set is connected In order to use the KiSS PC-
your DVD Player is plugged different types of TV via SCART, your TV is Link software, you need to
with. Your options are SCART, formats: 4:3 (normal) or 16: automatically provided provide your DVD player with
S-Video or Component 9 (wide screen). with sound. If you would your computer IP address. To
video. Composite video is rather use an amplifier to easily fi nd this number, fi rst
always available, but the Note: Some 4:3 TV screens reproduce the sound, you install the KiSS PC-Link
quality level is not as good can display 16:9 format. have two options to choose software on your computer.
as the other connections. from: the phono jack or one Once this step is completed,
of the two digital outputs. you will fi nd the number
under the Info Panel. Type
Note: The default Audio it on the provided screen.
choice should be stereo unless Leave it blank if you do
your player is connected to a not want to set up your PC
digital amplifi er connection for the moment.
You can always go back
to the quick setup menu if
you want to provide the IP
address at a later stage.
5
Video Settings
You can select the TV type (16:9 or 4:3 aspect ratio), video system (Pal or
NTSC) and video output (Scart, S-Video, Component Video or Component
Progressive (Progressive Scan)). Composite video is available in all modes
except in progressive scan mode. Component Progressive delivers the best
video quality, but be aware that if your TV does not support Progressive
Scan the picture (and menu) will disappear. You can reset this to the factory
settings by pressing: LOAD, INFO, 1, 2, 3 on the remote control.
Miscellaneous Settings
This display lets you set your preferred level of protection on the films. Some
films are divided into levels, so that parents can prevent their children from
seeing a specific type of film. In the next menu item, you create a password
that is required for editing this setup*. The light in the DVD Player's display
can be modified from max to normal to min or off. All settings can be reset
in the "Restore settings" menu, and the Quick setup can be re-initiated from
the last menu.
*If you wish to modify this setup later on, you must re-enter the password.
4. This product will not be considered as being defective, either in materials or
in manufacture, if adaptation to national, local, technical or safety-
related requirements is required in countries other than the specific country
for which the product was originally designed and manufactured.
5. This warranty does not cover these types of adaptations, and no
remuneration will be offered for these types of adaptations or for any
consequential damages. The warranty does not cover the following:
a) Periodic inspection, maintenance and repair or replacement of parts
resulting from normal wear.
b) Costs connected to transport, disassembly or installation of the product.
c) Misuse, including use for purposes other than was intended, or faulty
installation.
d) Damage caused by lightning, water, fire, natural catastrophes, war,
insurrection, incorrect line voltage, insufficient ventilation or other causes
outside of the control of KiSS.
6. This warranty applies to every legal owner of the product during the
warranty period.
Packaging
If possible, use the original packing material for any shipping. Otherwise, repack
the DP-508 using:
• A reinforced cardboard box, strong enough to carry the weight of the
product.
• At least 6 cm / 2.36 inches of shock-absorbing material around the product.
• Nonabrasive dust-free material for the other parts.
• Nonabrasive wrapping for the product. (Dust and dirt cover)
• Repack the product in such a way as to ensure that it cannot shift in the
box during transport.
• No other alternative will be accepted
Information we must receive before repairing the product:
Model name: KiSS DVD Player DP-508
Serial no.:
Fault description (if possible):
Copy of the invoice or sales receipt
The dealer's name, address and phone no.
Personal information: Name, address, post code/city, phone no. and e-mail
address (optional).
Your signature
Dealer's stamp and signature
Date
KiSS Technology A/S, Slotsmarken 10, DK 2970 Hørsholm, Denmark
Hotline (user support) +45 45 17 00 07
hotline@kiss-technology.com
All contacts with KiSS Support should be addressed in English
