Super Circuits MDVR33COV Quick Manual page 2

1. Parts
1 2 3 4 5
1. Camera Lens 5. HDMI Socket of Connector
2. HDMI Socket of Camera 6. Extension Mic Socket
3. HDMI Jack of Cable 7. Built-in Microphone (optional)
4. HDMI Jack of Cable 8. HDMI Socket of Connector
2. Package Content
WDR Digital Camera Lens Cap Image Refine Connector
(optional)
Camera to Connector Cable
Connector to DVR Cable
Extension Microphone
(optional)
3. Camera Setup Illustration
6 7 8
Camera
1. Connect camera to Connector
using the required cable.
2. Plug the extension microphone
into Connector mic socket.
3. Connect Connector to portable
DVR using required cable.
Covert Lens
Cap
Note: Calibrate camera
and configure video signal system
after interconnecting all components.
Connection of all Components
(1)
Back View of
Microphone
Image Refine
(optional)
Connector
Extension Microphone
(optional)
Connector
Portable DVR
4. Lens Cap On
1. Remove the black lens cap from the screw pack.
2. Place the cao on the camera lens.
3. Press the DVR "Power" button to turn it on.
4. Follow the steps on next page to
calibrate the camera.
(2)
(optional)
(3)
