Super Circuits MDVR33COV Quick Manual

5. Setting Video Signal System
MAIN MENU PAGE PAGE
0001/0009 0001/0009
Digital CMOS Setting
Digital CMOS Setting
SD SD SD
STORAGE STORAGE STORAGE
(1)
PAGE
PAGE PAGE Settings Settings ESC ESC ESC ESC
0001/0009
0001/0009 0001/0009
ESC
ESC
NEST
Digital CMOS Setting Digital CMOS Setting
Digital CMOS Setting PAL
PAL
SD
SD SD
STORAGE STORAGE STORAGE
(2)
1. Press "Setting" on the Main Menu.
2. Drag the Setting Menu down to select "Digital CMOS Setting".
3. Select either PAL or NTSC based on your country's
video signal system.
4. After making your selection, press "Digital CMOS Setting" again to
complete the setting.
6. Camera Calibration
1. Press "Setting" on the Main Menu.
2. Drag the Setting Menu down to select "Digital CMOS Calibration".
3. After making your selection, "Calibrating" will appear on the screen.
4. When calibration is complete, "Cable Disconnect" will appear on the screen.
5. Unplug the cable to complete calibration.
MAIN MENU
Settings Settings ESC ESC ESC ESC
ESC
ESC
NEST
SD
PAL STORAGE
PAL
(3) PAGE
0001/0009
Settings ESC ESC Digital CMOS Calibration
SD
STORAGE
PAL
7. Change Covert Lens Cap
(4)
1. Remove the lens cap from the camera, and the desired lens cap from the set,
by unscrewing them (rotate counterclockwise).
2. Place the desired lens cap onto the camera.
3. Screw the desired lens cap onto the camera (rotate clockwise) until it is secure.
(4)
Calibrating
PAGE Settings
0001/0009
(1) (3)
ESC ESC
Settings
Cable Disconnect
(2) (4)
MDVR33COV

Quick Guide

Supercircuits, Inc.
(5)

Digital Camera

V1.0
