HIDROLIMPIADORA ALTA PRESIÓN
ГИДРОМОЙКА ВЫСОКОГО ДАВЛЕНИЯ
IDROPULITRICE AD ALTA PRESSIONE
HIGH PRESSURE CLEANER
NETTOYEUR HAUTE PRESSION
HOCHDRUCKREINIGER
LAVADORA A ALTA PRESSÃO
• OPERATING INSTRUCTIONS
• MODE D'EMPLOI
• BEDIENUNGSANLEITUNG
• INSTRUCCIONES PARA EL USO
• MANUAL DE INSTRUÇÕES
• ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ
• LIBRETTO ISTRUZIONI
• DO NOT USE THE MACHINE WITHOUT FIRST READING THE OPERATING INSTRUCTIONS
• N'UTILISER L'APPAREIL QU'APRÈS AVOIR LU LE MANUEL D'INSTRUCTIONS
• GERAT ERST NACH LESEN DER BEDIENUNGSANLEITUNG VERWENDEN
• NO UTILISE EL APARATO SIN LEER ANTES LAS INSTRUCCIONES PARA SU USO
• NÃO USE A MÁQUINA SEM LER A MANUAL DE INSTRUÇÕES
• • НЕ ИСПОЛЬЗУЙТЕ УСТРОЙСТВО, НЕ ПРОЧИТАВ СНАЧАЛА ИНСТРУКЦИЮ ПО ЭКСПЛУАТАЦИИ
• NON USARE LA MACCHINA SENZA AVERE LETTO LE ISTRUZIONI PER L'USO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TX 10.130.2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Interpump TX 10.130.2

Summary of Contents for Interpump TX 10.130.2

  • Page 1 Menu HIGH PRESSURE CLEANER NETTOYEUR HAUTE PRESSION HOCHDRUCKREINIGER HIDROLIMPIADORA ALTA PRESIÓN LAVADORA A ALTA PRESSÃO ГИДРОМОЙКА ВЫСОКОГО ДАВЛЕНИЯ IDROPULITRICE AD ALTA PRESSIONE • OPERATING INSTRUCTIONS • MODE D’EMPLOI • BEDIENUNGSANLEITUNG • INSTRUCCIONES PARA EL USO • MANUAL DE INSTRUÇÕES • ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ •...
  • Page 2 INDEX ENGLISH pag..................... FRANÇAIS pag..................DEUTSCH pag..................ESPAÑOL pag................... PORTUGUÉS pag................. РУССКИЙ стр..................................... . ITALIANO pag.
  • Page 3 • CONTROL DEVICES Before connecting the machine to the water and electrical supplies, it is necessary to know the function of the controls on the machine. This must be done in accordance with the descriptions in the Instruction Manual, taking reference to the relevant instructions and illustrations.
  • Page 4 STANDARD EQUIPMENT EQUIPEMENT STANDARD ON/OFF switch Interrupteur Marche/Arrêt Pressure adjusting knob Bouton de régulation de la pression Pressure indicator Indicateur de pression Oil level indicator Indicateur de niveau d’huile High pressure hose connection (OUTLET) Raccord de tuyau haute pression (OUTLET) Inlet hose connection with water filter (INLET) Raccord d’alimentation eau et filtre (INLET) Outer chemical port...

  • Page 5: Table Of Contents

    ENGLISH TABLE OF CONTENTS 1 - Description of symbols on the high pressure cleaner........7 2 - Technical specifications of the T-TX series high pressure cleaner................. 8-9-10 3 - Product use....................... 11 3.1 • Designated use................... 11 4 - Preliminary operations..................11 4.1 •...

  • Page 6: Description Of Symbols On The High Pressure Cleaner

    1 - DESCRIPTION OF SYMBOLS ON THE HIGH PRESSURE CLEANER R R e e a a d d t t h h e e i i n n s s t t r r u u c c t t i i o o n n G G r r o o u u n n d d i i n n g g m m a a n n u u a a l l b b e e f f o o r r e e u u s s e e .
  • Page 7 2 - T SERIES HIGH PRESSURE CLEANERS TECHNICAL SPECIFICATIONS 8.90.2 10.100.2 11.120.2 10.100.4 11.120.3 MODEL SINGLE PHASE TRIPLE PHASE SINGLE PHASE l/min. Flow rate G.P.M. E.W. bar / MPa / P.S.I.: specific jet pressure in bar / MPa / P.S.I. Equivalent washing impact E.W.
  • Page 8 2 - TX SERIES HIGH PRESSURE CLEANERS TECHNICAL SPECIFICATIONS 10.130.2 12.100.2 12.140.2 13.180.2 14.120.2 15.150.2 10.130.4 12.100.4 12.140.3 13.180.3 14.120.3 15.150.3 MODEL 13.180.4 15.150.4 13.180.5 15.150.5 SINGLE PHASE SINGLE PHASE TRIPLE PHASE TRIPLE PHASE TRIPLE PHASE TRIPLE PHASE l/min. Flow rate G.P.M.
  • Page 9 2 - TX SERIES HIGH PRESSURE CLEANERS TECHNICAL SPECIFICATIONS 955.6 961.6 956.6 957.6 17.130.2 951.6 954.6 961.8 17.130.3 MODEL 17.130.4 17.130.5 SINGLE PHASE TRIPLE PHASE TRIPLE PHASE TRIPLE PHASE TRIPLE PHASE SINGLE PHASE SINGLE PHASE l/min. 11,5 15,9 13,6 Flow rate G.P.M.

  • Page 10: Product Use

    WE CONGRATULATE YOU on your choice that shows your level of technical knowledge and love of beautiful objects. In fact, you have purchased a highly technological machine produced by the world's largest manufacturer of high pressure cleaner pumps. This machine is so useful and versatile that you will use it for many years. THIS BOOKLET IS AN INTEGRAL PART OF YOUR MACHINE AND SHOULD BE CAREFULLY READ BEFORE PROCEEDING WITH INSTALLATION, START-UP AND USE.

  • Page 11: Identification Label

    4.2 - IDENTIFICATION LABEL Before using the machine, make sure that it is provided with the identification Label. In case the Identification Label is missing, do not use the machine and consult your dealer immediately. The Identification Label with the technical specifications is fixed to the motor.

  • Page 12: Connection High Pressure Outlet

    5.1 HIGH PRESSURE CONNECTION 1 - Connect one end of the high pressure hose to the automatic gun (A) and the other end to the OUTLET connection on the machine. Tighten firmly (B). 2 - Complete the assembly by coupling the extension to the gun/lance and tighten firmly (C). 5.2 - CONNECTION TO THE WATER SUPPLY 1- The maximum temperature of the inlet water must not exceed 60°C (140°F).

  • Page 13: Connection To Electric System

    5.3 - CONNECTION TO ELECTRICAL SYSTEM 1 - Check that the voltage of the electrical system (mains) is the same as indicated on the ID label of the machine. 2 - Check that the plug complies with local safety regulations, and that it is provided with ground connection (earth).

  • Page 14: Cut-Out Switch (Only The United States)

    5.3.1 - CUT-OUT SWITCH (Only the United States) This UL version high-pressure washer is equipped with a cut-out switch contained in the power cable plug. Said equipment provides extra protection against the risk of electric shock. When replacing the plug or cable, use the same components including the cut-out device. 5.4 - USE OF CORDS If an extension cord is used, make sure that plug and receptacle are of a water-tight type.

  • Page 15: Start-Up

    5.5 - START-UP - Before starting up and using the machine, make sure that it is positioned on the ground or leaning against a stable support and that the resting surface is level or with a minimum slope. - It is ESSENTIAL to ensure that the suction filter is clean before use. (see maintenance chap- ter –...

  • Page 16: General Warnings

    6 - GENERAL WARNINGS High pressure cleaners can be used neither by children nor by non authorized persons. Children must be supervised to prevent them from playing with the machine. Keep this machine out of reach of children at all times. This equipment was not designed to be used by persons with reduced physical, sensorial or mental capabilities, or with limited experience...
  • Page 17 This machine has been built in conformity with current safety regulations. Use of electric appliances requires the observations of a few simple rules: Do not touch electric parts when the machine is on. Inspection, maintenance and repairs should be carried out by qualified personnel. In any case unplug the machine before performing any of the above operations.
  • Page 18 Avoid covering the machine during use and use the machine in a well ventilated area. Do not leave the machine running for more than 5 minutes with the pistol closed. After this time period the water temperature within the machine increase and may cause damage to the machine.

  • Page 19: Chemical Product Use

    7 - HOW TO USE CHEMICAL PRODUCTS The models T and TX can suck detergents and other liquid additives from the built-in tank or from a separate tank. In the event of direct contact with detergent additives, follow instructions provided by the man- ufacturer and/or product retailer and rinse the affected body part with clean water.

  • Page 20: Use Of "Rototek" Or "Multireg 99

    Check for any water or oil leaks and/or malfunctions. If necessary, replace affected parts. The list of specific machine components and circuit diagrams are contained in the booklet "SPARE PARTS NOMENCLATURE". Contact Interpump Group customer service in the event of any doubts.

  • Page 21: Oil Change

    10.1 - OIL CHECK AND CHANGE • The oil level must be checked periodically through the oil sight glass • Oil must be changed after the first 50 hours of operation of the machine. Subsequent oil changes must be carried out every 300 hours of machine operation. •...

  • Page 22: Machine Scrapping

    11 - DISPOSAL OF THE MACHINE • In case of no further use of the machine, it is advisable to disconnect the power cord mak- ing the machine inoperative. • Keep out of reach of children. • This machine is considered "special waste", disassemble and gather homogeneous parts for recycling.

  • Page 23: Trouble Shooting

    12 - TROUBLE SHOOTING (FOR QUALIFIED PERSONNEL) CAUSE REMEDY TROUBLE The pump is running but Air suction Check suction hose and fittings Worn or dirty valves maximum pressure is Clean or substitute not obtained Unloader packings worn Check and/or substitute Nozzle worn or incorrect Check and/or substitute Piston packings worn...
  • Page 24 12 - INCONVENIENTI E RIMEDI (AD USO DI PERSONALE QUALIFICATO) INCONVENIENTI CAUSE RIMEDI La pompa aspira aria La pompa gira ma non Controllare i condotti di aspi- raggiunge le pressioni razione Valvole usurate o sporche Pulire o sostituire Guarnizioni valvola bypass usurate Controllare e/o sostituire Ugello inadeguato o usurato Controllare e/o sostituire...
  • Page 25 DECLARATION OF CONFORMITY (According to annex II of European Directive 2006/42/CE) The manufacturer INTERPUMP GROUP S.p.A. - Via E. Fermi, 25 - 42049 S. ILARIO D’ENZA (RE) - Italy DECLARES that the machine identified and described below: Type of machine: Mobile High Pressure Cleaner...

This manual is also suitable for:
