Summary of Contents for Intraphex MRC-UN01
Page 1
MRC-UN01 MRC-HY01 MRC-CH01 Backup Camera Mirror Installation Manual...
Page 2
General Description Factory mirror upgrade with a 4.3” High-Resolution LCD monitor hidden behind the mirror surface. The three models cover Universal (MRC-UN01), Hyundai/Kia (MRC-HY01), and Chrysler (MRC-CH01) style OEM mirror mounts. There are a total of two (2) video inputs.
Page 3
Operation While using the Video 1 Input, you can press the Power button to turn the monitor ON/OFF While using the Video 2 Input (Backup Camera), you can press the Power button for 1.5 seconds to turn the monitor ON/OFF, or use a short press to adjust the image brightness. Environment Sensor Standby Indicator On/Off/Brightness Adjusting...
Page 4
THREE (3) years from date of purchase. A sales receipt, showing the installation date and INTRAPHEX product details are required to verify proof of purchase. Should the product(s) be determined defective during the applicable warranty period, the defective product(s) will be repaired or replaced with a reconditioned product(s), at INTRAPHEX’s sole option.
