Intraphex TD-BMW6PIN-v2 Install Manual

2012 up bmw monitors with 6 pin lvds connector 1,3,5,6,7 series
Hide thumbs

Advertisement

Quick Links

Download this manual
TD-BMW6PIN-v2
Inst all
MANUAL
APPLICATIONS:
2012 UP BMW MONITORS WITH
6 PIN L VDS CONNECTOR
1,3,5,6,7 SERIES

Advertisement

loading
Need help?

Need help?

Do you have a question about the TD-BMW6PIN-v2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intraphex TD-BMW6PIN-v2

Summary of Contents for Intraphex TD-BMW6PIN-v2

  • Page 1 TD-BMW6PIN-v2 Inst all MANUAL APPLICATIONS: 2012 UP BMW MONITORS WITH 6 PIN L VDS CONNECTOR 1,3,5,6,7 SERIES...
  • Page 2 Contacts www.INTRAPHEX.com SUPPORT@INTRAPHEX.COM SUPPORT: 810.355.2266 EXT 4 Fax: 866.431.0676 FACETIME VIDEO TECH SUPPORT: VSUPPORT@INTRAPHEX.COM...
  • Page 3 What’s In The Box RGB/GPS INTERFACE AUDIO SWITCHER   RCA HARNESS CANBUS INTERFACE  GPS ANTENNA  MOMENTARY SWITCH  INTERFACE 6 PIN  8GB SD CARD WITH  HARNESS INTRAPHEX NAV SOFTWARE NAVIGATION BOX  INSTALL/USERS TOUCH LAYER   GUIDES...

  • Page 5: Canbus Box

    CANBUS BOX  THE CANBUS INTERFACE CAN SUPPLY POWER AND GROUND TO THE ADDED DEVICES SUCH AS THE REVERSE CAMERA. THE MAXIMUM OUTPUT FOR THESE IS 1 AMP. IF THE DEVICE THAT YOU PLAN TO USE DRAWS MORE CURRENT THAN THIS, IT WILL BE NECESSARY TO USE A RELAY .
  • Page 6  NOT ALL HARNESSES WILL BE USED IN TYPICAL NAVIGATION INSTALLATION, SUCH AS AUDIO RCA HARNESS AND MOMENTARY SWITCH.
  • Page 7 INTERFACE DIP SWITCH SETTINGS DOWN RGB (NAVI) INPUT ON RGB (NAVI) INPUT OFF VIDEO 1 ON VIDEO 1 OFF VIDEO 2 ON VIDEO 2 OFF RGB RES 800X480 HD RGB RES 480X234 GREEN WIRE TRIGGER TO OEM DISPLAY GREEN WIRE TRIGGER TO CAMERA INPUT FACTORY CAMERA NO FUNCTION...
  • Page 8 CANBOX INSTALLATION  REMOVE THE MONITOR FROM THE VEHICLE. BECAUSE THE 6 PIN INTERFACE WILL FIT ALL MODELS OF BMW 6 PIN SYSTEM, THIS WILL VARY FROM CAR TO CAR.  REMOVE CD PLAYER ASSEMBLY TO GAIN ACCESS TO THE MAIN HARNESS.

  • Page 9: Interface Installation

     ONCE THE PROPER CONNECTIONS HAVE BEEN MADE THE CANBOX LEDS WILL LIGHT UP. ONE SHOULD REMAIN SOLID AND THE OTHER WILL BLINK RAPIDLY. THIS IS NORMAL OPERATION. IF YOUR CANBUS WIRES ARE INCORRECT, NO DAMAGE WILL OCCUR.. INTERFACE INSTALLATION ...
  • Page 10 TOUCH LAYER INSTALLATION  AGAIN, SINCE THIS PRODUCT FITS MUTIPLE VEHICLES AND THE DISASSEMBLY OF THE PLASTIC FRAME DIFFERS FROM CAR TO CAR, YOU WILL NEED TO REMOVE THE PLASTIC FRAME FROM THE MONITOR. TYPICALLY IT IS JUST A COUPLE OF SCREWS AND CLIPS. ...

  • Page 11: Interface Setup

     MOUNT GPS ANTENNA. IT CAN BE MOUNTED UNDER DASH PANEL AS LONG AS IT HAS A CLEAR VIEW OF THE SKY THROUGH PLASTIC ONLY. MOUNT SPEAKER IN DESIRED LOCATION, AND CONNECT GPS ANTENNA AND SPEAKER TO NAVI BOX. INTERFACE SETUP ...
  • Page 12 SCAN THE QR CODE FOR MORE INFORMATION ON INTRAPHEX PRODUCTS...
  • Page 13 INTRAPHEX, a division of TATMAR LLC, a Michigan Limited Liability Company, (INTRAPHEX) warrants to the original retail purchaser, that the product(s) purchased from an INTRAPHEX authorized dealer, in the original vehicle, are free from defects in materials or workmanship under normal use and conditions for a period of THREE (3) years from date of purchase.
