Page 1: Wireless Router
Version 1.00 EN Manual version 1 Wireless Router Installation manual... -
Page 2: Delivery Scope
Delivery scope The delivery scope of the device includes the following parts: Wireless Router WNA (TL-MR3020) Power pack USB cable Ethernet LAN cable A CD with: Operating instructions (English) Installation manual (English) Displays, operating elements, connections... - Page 3 3G/4G-USB- modem connection Mini USB port (DC) Ethernet port Operating mode selector switch 3G/4G USB port: Connection for the USB modem. Mini USB port: Connection to the power supply. Ethernet port: This port is used as a LAN connection. ...
-
Page 4: Connection To The Network
Connection to the network A WLAN connection is used to configure the router in the example. (You can also use a LAN connec- tion for the configuration.) Windows XP and Windows 7 On the task bar, click on the icon (Windows XP) or (Windows 7/8) Click on Update network list and select the WLAN network of the router and click on Con-... -
Page 5: Router Configuration
Tap or click on the name of the network that you want to establish a connection with and then tap or click on “Establish connection”. The network name of the router is here: TP-LINK_POCKET_3020_xxxxxx Router configuration Open a web browser and enter the address http://192.168.0.254 in the address line and per Enter. - Page 6 Click on Next. The Internet access page appears. Select 3G/4G Only (recommended) and click on Next. Enter your access data in this page and click on Next. If you cannot find your provider in the menu, set Set the Dial Number, APN, user name and password manually to manual entry and enter your access data according to the information of your provider (ISP).
- Page 7 Click on Reboot to accept the new WLAN configuration and to complete the Quick Setup. (If the WLAN settings were not changed, click on Finish to complete the quick installation”.) After the restart, connect with the network again (see chapter “Connection to the network”) You can now connect the C.M.I.
-
Page 8: Tcp/Ip Configuration
Operation in AP (“Access Point”) mode Configured as Client, the router how behaves like a WLAN card and thus does integrates non-WLAN- capable Ethernet devices in a wireless network. TCP/IP configuration A LAN connection is used to configure the router in the example. (You can also use a WLAN connec- tion for the configuration.) Windows XP: Start →... - Page 9 Select the following IP address and enter an IP address with the format 192.168.0.x. x is a number from 1 to 253 and the subnet mask is 255.255.255.0. Click on OK. Router configuration Open a web browser and enter the address http://192.168.0.254 in the address line and per Enter.
