Summary of Contents for Technische Alternative WNA
-
Page 1: Wireless Router
Version 2.00 EN Wireless Router Setup Guide... -
Page 2: Package Contents
Package Contents The following parts are shipped: Wireless Router WNA (TL-MR3020) Power cord and adapter USB-Cord (Y-Port) Ethernet-LAN-Cord Quick Installation Guide (English, German, Spanish, Greek, French, Italian, Portuguese, Finn- ish, Dutch, Swedish, Norwegian, Danish) Indicators, Buttons, Ports... -
Page 3: 4G Router Mode
3G/4G-USB-Port Mini-USB-Port (DC) RJ45 Ethernet-Port Mode Switch 3G/4G-USB-Port: Port for 3G/4G sticks. Mini-USB-Port: For power supply RJ45 Ethernet-Port: For ethernet connection via LAN. Mode Switch: To choose the mode of operation. Changing the mode while the device is in use will trigger a restart. - Page 4 Router configuration 3G/4G Open a web browser and enter the address 192.168.0.254 into the address bar and hit enter. The login window below will appear. Enter admin as both username and password. Click Login or hit enter. Before continuing the configuration, please check the status of the device by clicking status to ensure that your 3G/4G modem can be identified.
- Page 5 The page Internet Access will appear. Choose the option 3G/4G Only (Recommended) and click Next. Enter your access data and click Next. If your provider is not listed, tick Set the Dial Number, APN, Username and Password manually to enter the data of your ISP (=Internet Service Provider) yourself.
- Page 6 The Wireless options are now being displayed. You can leave the data as it is or change your Wireless Network Name and/or your Pass- word. Either way, click Next to proceed. Click Reboot to accept the changes to the Wi-Fi configuration and finish your Quick Setup. (If no changes to the Wi-Fi configuration have been made, click Finish to close your setup.) After the reboot, reconnect to the network.
- Page 7 Router Configuration AP-Client Open a web browser and enter the address 192.168.0.254 into the address bar, then hit enter. Enter admin as both username and password. Click Login or hit enter. Navigate to Quick Setup in the menu on the left and hit next in the window that follows. Choose the Wireless Operation Mode Type “Client”...
- Page 8 The window pictured below will appear. Enter the Wireless Network Name (SSID) and choose a Security Mode, then click next. Click Survey to scan for available networks, should you not know your network’s name. The Security Mode and its properties must be the exact same as the mode and properties of the existing Wi-Fi network.
-
Page 9: Eu Declaration Of Conformity
EU Declaration of conformity Document- Nr. / Date: TA17058 / 02/02/2017 Company / Manufacturer: Technische Alternative RT GmbH Address: A- 3872 Amaliendorf, Langestraße 124 This declaration of conformity is issued under the sole responsibility of the manufacturer. Product name: Product brand:... -
Page 12: Guarantee Conditions
1. The company Technische Alternative RT GmbH provides a two-year guarantee from the date of purchase by the end consumer for all the devices and parts which it sells. Defects must be reported immediately upon detection and within the guarantee period.
