Summary of Contents for Confidence Vibration plate power plus
- Page 2 SAFETY TIPS Do not use your Confidence Vibration Plate Power Plus with wet hands. Always turn off the power at the mains socket after use. Not to be used by pregnant woman. DO NOT drink alcohol and then use the Vibration machine.
- Page 6 PARTS LIST 1. Console 2. Heart Rate Sensor 3. Right Heart Rate Sensor Handle 4. Right handrail tube 5. Support tube 6. Vibration Plate 7. Base Board 8. Left Heart Rate Sensor Handle 9. Left handrail tube 10. Yoga straps...
- Page 7 1. Place the base board on an even surface 2. Remove the four screws and washers from the back of the base board 3. Connect the signal cable (A) with the wire (B) from the base board 4. Push the Support tube down into the hole on the back of the base board – hold the support tube diagonally away from the base board to insert it (See IMAGE A below) 5.
- Page 8 1. Remove the four screws and washers from the holes on either side of the base board (two on either side) 2. Insert two handrail tubes into the holes on the sides of the base board, Please make sure the top of the handrail tubes are angled away from the main unit. 3.
- Page 9 HEART RATE SENSOR HANDLES 1. Remove the screw from the top of each Heart Rate sensor handle and the two screws from the bottom of each Heart Rate sensor handle 2. Take one of the Heart Rate sensor handles and insert the top end onto the support tube and reinsert the screw (repeat on other side) See FIG 3 3.
- Page 10 1. Remove the three screws from the bottom of the console 2. Connect the signal cable (A) of the support tube with wire (B) from the console 3. Connect the Heart Rate sensors (D) of the support tube with the Heart Rate sensors (C) from the console 4.
- Page 12 Placing the Vibration Plate Power Plus on an uneven floor can cause it to wobble during use and may cause the incline adjustment to function incorrectly. To prevent this from happening, two stabilizers have been installed underneath of the base board and these should be adjusted correctly prior to use.
- Page 13 6. If you want to stop the machine at any time, press the START/STOP button, otherwise the machine will automatically stop when the exercise time reaches zero. DO NOT USE THE VIBRATION PLATE POWER PLUS FOR MORE THAN 20 MINUTES IN ANY ONE EXERCISE SESSION.
- Page 19 Specifications Dimensions (L x W x H) : 735 x 695 x 1220mm Weight : 39 kg Maximum power : 1.5HP Input voltage : 200-240V Frequency Range : 50-60Hz Speed range 1-50 Maximum User Weight : 150 kg...
