- Page 1 Audio INSTALLATION MANUAL MODEL: TAWAS100HD 100 WATT Windshield-Mount Audio System For most Harley-Davidson Non-Fairing Motorcycles...
-
Page 2: Table Of Contents
INTRODUCTION T A B L E O F C O N T E N T S K E Y F E A T U R E S Key Features ............· Easy Installation · OEM Fit and Appearance WARNINGS: ............·... -
Page 3: Tools Required
T O O L S R E Q U I R E D M O D E L C O M P A T I B I L I T Y · Philips screwdriver 1994 and later Harley-Davidson non-fairing · 3/8˝ Wrench or Socket Driver touring and Softail Models with windshields ·... -
Page 4: Installation-Radio Assembly
I N ST A LL AT I ON · RADI O A SSE M BLY Remove the five original equipment manufacturer’s The three screws indicated here across the top (OEM) windshield screws and acorn nuts from horizontal frame (a). And, the two here on the the windshield frame. -
Page 5: Optional Locking Bracket
I NS T A LLATI ON · R ADI O A SSEM B L Y windshield vertical frame members. Install screws, Use the longer screws you set aside earlier and but do not tighten (f ). use them to attach the lower radio brackets to the Now, install the two shorter screws that were supplied proper alignment as you go. -
Page 6: Installation-Electrical
Locate the four-pin accessory plug located from Twisted Audio for your installation. between the frame rails in front of the battery and remove the cap. ( k &... -
Page 7: Final Installation
FI NAL I NSTALLATI O N Secure the harness in front of the tank using Reattach the windshield — with the audio system — to the bike (q). a tie wrap (s). Take the two-pin power plug on the wiring harness Be sure to switch on the Harley-Davidson accessory and connect to the socket on the bottom of the switch located in front of the gas tank, otherwise... -
Page 8: Accessories/Notes
SYSTEM COVER ACCESSORY Use the optional Twisted Audio cover accessory to help protect your audio system against the elements. IMPORTANT NOTES The audio system is weather-resistant. However, don’t expose the system to high pressure (hose & nozzel) water spray. Detach windshield/audio system when washing the motorcycle.
