Summary of Contents for Olin PD-7700

  • Page 2: Precautions

    PRECAUTIONS CAUTION For Customer Use: Enter below the serial number that is located on the RISK OF ELECTRIC SHOCK bottom of the unit. Retain this information for future DO NOT OPEN reference. CAUTION: TO REDUCE THE RISK OF FIRE AND ELEC- TRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK) OF THE UNIT.
  • Page 3 PRECAUTIONS Do not make any changes or modifications to the equipment unless otherwise specified in the manual. If such changes or modifications should be made, you could be required to stop operation of the equipment. For recycling or disposal information about this product, please contact your local authorities or the Electronics Industries Alliance: www.eiae.org.

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read Instructions: All the safety and operating instructions should be read before the product is operated. Retain Instructions: The safety and operating instructions should be retained for future refer- ence. Heed Warnings: All warnings on the product and in the operating instructions should be adhered to.
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS 17. Using the unit in a Vehicle :On no account should this unit be used by the driver of a moving motor vehicle, or left unsecured in the vehicle whilst driving. If this unit is being used by a passenger in your vehicle, be sure that it is secured or held safely, and does not obstruct any safety device (i.e.
  • Page 6 IMPORTANT SAFETY INSTRUCTIONS for long periods of time. This will prevent damage to the product due to lightning or power-line surges. If at any time in the future you should need to dispose of this product please note that Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.

  • Page 7: Table Of Contents

    TABLE OF CONTENTS PRECAUTIONS ..........................2 IMPORTANT SAFETY INSTRUCTIONS ..................4 TABLE OF CONTENTS ........................7 PACKAGE CONTENTS ........................9 ABOUT OPTICAL DISCS ......................10 Disc Requirements.........................10 Disc Care and Maintenance ....................10 Handling a Disc ......................10 Cleaning a Disc ......................10 LOCATION OF CONTROLS ......................11 Front View (Main Unit) ......................11 Left View (Main Unit)......................12 Right View (Main Unit) ......................12...

  • Page 8: Table Of Contents

    TABLE OF CONTENTS PLAYER FUNCTIONS ........................22 Menu/Title ..........................22 Setup ............................22 Display ...........................22 Repeat Mode..........................22 Repeat A-B Mode ........................23 Multi-Angle/Subtitle/Audio .....................23 Zoom ............................23 Clear ............................23 Search ............................23 DVD Mode........................23 CD Mode ........................23 LCD Menu ..........................24 Program Function ........................24 USB/SD/MMC Card Access ....................24 SETUP ............................25 Language Setup ........................25 Screen Setup .........................25...

  • Page 9: Package Contents

    PACKAGE CONTENTS Please make sure the following items are included in the package. If any items are missing, please contact your local dealer. Car Adaptor with AV cable Audio & Video Cable Headrest Mounting Bags...

  • Page 10: About Optical Discs

    ABOUT OPTICAL DISCS Disc Requirements This DVD player supports playback of the following discs. Type Disc Mark Content Type Disc Size Max. Playback Time 133 min (SS-SL) 242 min (SS-DL) Audio + Video DVD-Video Discs 12 cm (moving picture) 266 min (DS-SL) 484 min (DS-DL) Audio Compact Discs (CDs) Audio...

  • Page 11: Location Of Controls

    LOCATION OF CONTROLS Main unit • • /USB/SD 5 6 7 8 Front View 16:9 or 4:3 Integrated Stereo Speakers To reset all items, select RESET by up/down direction button and then press ENTER button Power on Indicator to confi rm. Battery LED Indicator •...

  • Page 12: Left View (Main Unit)

    LOCATION OF CONTROLS Main unit Right View Left View Back View Left View Right View DC 9V IN Headphone Jack To connect to the supplied AC Adaptor/DC Car To connect the headphone. Cord for power supply. Before connection, make sure that the volume is at low level.

  • Page 13: Left View (Monitor)

    LOCATION OF CONTROLS Monitor Left View Front View Right View Left View Front View Power Switch Power On Indicator To turn on/off the unit. Mute Button To turn off / restore the audio. Right View Screen Ratio Button DC 9V In Jack To change the screen ratio to 4:3 or 16:9.

  • Page 14: Battery Installation

    LOCATION OF CONTROLS Battery Installation...

  • Page 15: Connections

    CONNECTIONS Power, Audio and Video Output Connections Before connecting the power source, ensure that all the connections are properly done. • Connecting to a wall outlet • Outputting audio and video signal from the main unit to the monitor by the DC car cord. Adaptor for main unit: Adaptor for monitor: This adaptor should be used...

  • Page 16: Using The Car Plug

    CONNECTIONS • Using the car plug • Outputting audio and video signal from the main unit to the monitor. Main Unit Monitor DC 9V in DC 9V in Video in Audio Jack Audio in Video Jack To the Cigarette Lighter Socket Audio and Video Connections (external device) Main Unit Slide the AV switch to AV IN to input the AV signal.

  • Page 17: Usb/Sd/Mmc Card Connection

    CONNECTIONS USB/SD/MMC-Card Connection Insert the USB/SD Card into the corresponding slot on the right panel of the main unit, press and hold the LCD MODE/USB/SD button to display the DVD/USB/Card selection menu. Press the up/down direction button to select USB or Card from the menu, press ENTER to access. It takes a short while for the unit’s reading data.

  • Page 18: Rechargeable Battery Pack

    CONNECTIONS Rechargeable Battery Pack • For new or exhausted rechargeable battery pack, we recommend it be recharged for 4 hours. • To charge the battery, just connect the adaptor. • If the battery does not work to your expectation, please consult the service center.Do not attempt to replace or repair the battery by yourself unless your are a qualifi...

  • Page 19: Basic Operations

    BASIC OPERATIONS Play/Pause/Stop top cover facing up. ]Close the cover manually. “Invalid Disc”. reverse Slow/Step mode.
  • Page 20 BASIC OPERATIONS Wrong Regional Disc Wrong Password Wrong Disc disc that is damaged or had a format problem, it may play the disc at lower quality or stop playback completely.
  • Page 21 PLAYER FUNCTIONS operation Each successive press of REPEAT will change the repeat mode of the player shown as below: Repeat Some DVDs do not support the repeat function.

  • Page 22: Repeat Mode

    PLAYER FUNCTIONS 1/2X 1/2X In JPEG Mode Clear Search display the search bar shown below: -- /12 --- /001 0:02:03 Current Title Repeat Mode Total Titles Elapsed Time Current Chapter Total Chapters -- /12 0:02:03 Current Track Repeat Mode Elapsed Time Total Tracks numeric Play/Pause...

  • Page 23: Dvd Mode

    PLAYER FUNCTIONS LCD Menu Press the LCD Mode button once to display the LCD menu. • Press the Up/Down direction button to select the desired item, press the Left/Right direction button to adjust. • Press the Left/Right direction button to change the screen dimension as 16:9 or 4:3. •...

  • Page 24: Setup

    SETUP Various features of the player can be adjusted in the SETUP menu 1. Press the SETUP button to show the setup menu. 2. Press the direction buttons to select the desired item. 3. Press ENTER to confi rm. Language Setup Display Auto Australia.
  • Page 25 SETUP SETUP Parental You must input the four-digit password to access the Parental settigs. The intial password is 8888. Sets the maturity rating level of the player. The player will not play any discs higher than this setting. There are eight rating levels. Level 1 will re- strict playback to discs suitable for people of all ages.

  • Page 26: Specifications

    SPECIFICATIONS SPECIFICATIONS Main Unit =10W Auto/NTSC/PAL 198 165 37 725.9g Monitor Auto/NTSC/PAL Video Input Audio Input 198 165 26 507.5g Specifi cations and manual are subject to change without prior notice.
  • Page 27 PLACEMENT Mounting in the Vehicle • The headrest mounting bags for fi tting the main unit and the monitor on to your car headrests. • The bag has 2 straps that wrap around the headrest tightly and the main unit / monitor slides in and out of the bag.

  • Page 28: Troubleshooting

    TROUBLESHOOTING Main Unit Troubleshooting There is no power to the device. • Ensure that the Power Switch on the main unit is physically set to the ON position. • Ensure that the AC adaptor cord is securely connected to the player and the proper wall outlet. The device will not play the disc.
  • Page 29 TROUBLESHOOTING • Ensure that the TV and amplifier have been turned on and properly set up. • Ensure that the TV and amplifier connections are secure and correct. • Try a different Audio track of the DVD by pressing AUDIO. •...
  • Page 30 NOTE Copyright This manual contains information protected by copyright law. No part of this document may be used or reproduced in any form or by any means, or stored in a database/retrieval system without prior written permission from us. The information of this manual is based on the current version of the product. We reserve the right to alter the content without prior notice.
