Summary of Contents for Floorpul ROXY
- Page 1 Operator’s Manual ROXY Noise-static Vacuum Cleaner ● Please read this Operator’s Manual carefully and make sure fully understand before using the appliance. ● Please keep this Manual for future reference.
-
Page 2: Table Of Contents
CONTENTS Operate Safety Instruction………………………………..…………….2 Machine Introduction…………………………………….……………...4 Technical Specifications……………………………….……………….4 Spare parts name…………………………………….…………………..5 Accessory…………………………………………….…………………...6 Preparation before operation……………………….………………….7 How to operate machine………………………………….……………..8 Service manual and spare parts Daily maintenance……………………………………………..……….10 Special attention…………………………………………….………….12 Rubbish empty method…………………………………..……………13 Common malfunction diagnosis……………………………..………14... -
Page 3: Operate Safety Instruction
Operate safety instruction Please read this manual carefully before using this appliance In this manual, there are common safety instructions in details on appliance preparing, operating and maintenance. And operator must obey these accident preventive regulations when use this machine. Any accident aroused by regulations disobey, producer will not bear any liability. - Page 4 Only the authorized service center or the technician who is familiar with related safety instruction can maintain the machine, or will cause person injury and damage to machine Electrical components of this machine can “short-out” if exposed to water or moisture.
-
Page 5: Machine Introduction
Machine instruction ROXY noise-static vacuum cleaner, it is FLOORPUL’s latest product, which gathers all advantages of congeneric products in worldwide. It is an excellent performance machine with smooth outlook, special wheel arrangement (two are active wheels, the other two are stable ones) which make the following ability of machine much better, non-static operation. -
Page 6: Spare Parts Name
Spare parts name hose cord hook crevice nozzle lock handle air inlet small round brush Combination tool cord 2 separated stainless steel tube switch stainless steel telescopic tube(optional) -
Page 7: Accessory
Accessory Combination tool ⑩ ⑩ ⑩ ⑩ It is the professional accessory for carpet and floor dust suction. This brush is the European standard brush. Equipped with dual situation control bar, you can choose the working style of the brush based on floor and carpet two different situations freely, and achieve the best efforts. when you press the button, same as the right picture, the brush is suitable for carpet dust suction. -
Page 8: Preparation Before Operation
Prepare jobs before operation 1. Before your power connection, check whether the power you use is the same as the machine nameplate shows 2. match the brush with one head of stainless steel (telescope) tube, also connect the other head to the handle 3. -
Page 9: How To Operate The Machine
4. Switch is on one side of the machine, press “on” to start the machine, while press “off” close the machine. 5. ROXY adopts HEPA filter design , so dust will be sucked into tank directly. Please empty the tank after your operation in time, which is healthful and good for machine protection. - Page 10 How to operate the machine Note: When you sense the suction power is decreased during your operation, please soon check whether the hose is blocked or not? the dust in the tank is too much? the filter contains too much dust or not? If you use the machine in this situation for long time, the motor will be damaged.
-
Page 11: Daily Maintenance
Daily maintenance A professional vacuum cleaner is your production tool, please protect and maintain it during your operation and after operation, which will not only lengthen the production life, but also make your operation much more comfortable. So daily maintenance is a very important job, please pay more attention to it. - Page 12 Daily maintenance Insert the hose, and check the suction is normal or not both on the stainless steel connection and on the air inlet mouth of brush, confirm the hose is blocked or not, if it is un-normal, please check where the block is, and clean it in time. 4, If you can not clean the dust on the filter cover and HEPA filter when they are dry, you can wash them with water,as the picture shows 4.1 Rinse with water against the dust enter direction, do not knead it, do not use detergent,...
-
Page 13: Special Attention
Pay special attention to following matters 1. This machine is suitable to suck building powder, such as cement, gesso powder and other kinds of extremely small powder, which will severely block the filter. And the block increases the motor temperature rapidly, which will make big effect to motor life. 2. -
Page 14: Rubbish Empty Method
Danger: This machine is just for inside use only. It is forbidden to leave the machine in oust open air, also it is forbidden to operate this machine in the rainy outside. Note: When the motor automatic system start, please check and find out the malfunction reason. -
Page 15: Common Malfunction Diagnosis
Common malfunction diagnosis If your machine has problem, please check the following file. If your machine still works unproperly, stop the machine! Please ask for help from ROXY agency or service centre, let the professional person repair the machine PROBLEM...
