  • Page 1 Identivision ICR-E42-83-163 Installer Manual EN ver 1.2 Page 1...

  • Page 2: Important Safeguards And Warnings

    Welcome Thank you for purchasing our DVR! This manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about this series DVR features and functions, as well as a detailed menu tree.

  • Page 3: Table Of Contents

    Directory 1 Production Introduction ..........................5 1.1 Product overview ........................... 5 1.2 Main functions ..........................5 2 Open-package check and cable connections ..................7 2.1 Open-package check ........................7 2.2 Hard disk installation ........................7 2.3 Front panel ............................. 8 2.4 Rear panel .............................
  • Page 4 4.3.4 Alarm input ........................38 4.3.5 Alarm output ........................39 4.3.6 Abnormal ........................... 39 4.4 System ............................40 4.4.1 General ..........................40 4.4.2 Encode ..........................41 4.4.3 Network ..........................43 4.4.4 NetSevice .......................... 43 4.4.5 GUI Display ........................50 4.4.6 PTZ ............................ 51 4.4.7 RS232 ..........................

  • Page 5: Production Introduction

    1 Production Introduction 1.1 Product overview The series DVR is designed specially for security and defense field which is an outstanding digital surveillance product. It introduces embedded LINUX operating system which is more stable. It introduces standard H.264mp video compressed format and G.711A audio compressed format which insures the high quality image, low error coding ratio and single frame playing.
  • Page 6 - Multi language : English,Finnish, French, German, Greek, Hungarian, Italian, Polish, Portuguese, Russian, Spanish, Turkish. Czech coming soon. - Silent operation - Small size & weight = save freight cost ( 310x215x45 mm , 3 kg ) - Professional service and after sales support - 3 year warranty ICR-E83 stand-alone H.264 DVR - 8 video input channel: D1 recording on all channel...
  • Page 7 ·individual real-time video recording as well as searching, playback, network surveillance, recording check,6 downloading and so on ·multi-playback mode ·zoom at arbitrary region Net operating ·through net tele-surveillance in the real time ·tele-PTZ control ·tele-recording check and real-time playback Alarm linkage ·multi-route relay alarm output which is convenient for the alarm linkage and light control at the spot ·protecting circuits at the alarm input and output interface which protects the main machine...

  • Page 8: Open-Package Check And Cable Connections

    2 Open-package check and cable connections 2.1 Open-package check When you receive the DVR, please check first . First, please check whether there is any visible damage to the package appearance. The protective materials used for the package of the DVR can protect most accidental clashes during transportation. Then, please open the box and get rid off the plastic protective materials.

  • Page 9: Front Panel

    ④ fix the screw of hard disk ⑤ connect the data wire ⑥ connect the power wire ⑦ cover the machine ⑧ fix the cover 2.3 Front panel (1) Shift indicator light (2) System indicator light (3) Alarm indicator light (4)Record indicator light (5) Outside operation indicator light (6) Network indicator light (7) HDD indicator light (8) Next File...

  • Page 10: Rear Panel

    2.4 Rear panel (1) audio input (2) video input (3) VGA output (4) switch (5) alarm input (6) alarm output (7) 12V power output (8) video output (9) audio input (10) audio output (11) network (12) USB2.0 (13) RS485 (14) power supply 2.5 Audio and video input and output connections 2.5.1 Video input connections The video input port is BNC connector plug.

  • Page 11: Video Output Connections And Options

    Insure the connection stable and credible The signal and shield lines should be firm and connected credible which avoid false and joint welding and oxidation. 2.5.2 Video output connections and options ,75Ω) and VGA output(selective The video output is divided into PAL/NTSC BNC(1.0V configuration).

  • Page 12: Alarm Input And Output Connections

    4、 Adjust the layout of the sound box and the tone arm. 2.6 Alarm input and output connections １、Alarm input A. Alarm input is grounding alarm input. B. Alarm input demand is the grounding voltage signal. C. When the alarm is connected with two DVRs or connected with DVR and other equipments, it should be isolated by relay.

  • Page 13: Alarm Input Port Specification

    (1) alarm input (2) grounding (3) RS232 (4) alarm output (5) RS485 parameter meaning grounding C1、NO1 Alarm output interface(constant open type) T、R RS232 port 485communication interface which is connected with the A、B recording control equipments such as the decoder 2.6.1 Alarm input port specification 1 channels alarm input.

  • Page 14: Alarm Output Port Relay Parameters

    Please refer to the relay relevant parameters to avoid the overload that damages main machine. 2.6.3 Alarm output port relay parameters Type：JRC-27F Interface material silver rating Rating switch capacity 30VDC 2A, 125VAC maximal switch power 125VA 160W (resistance load) maximal switch voltage 250VAC, 220VDC maximal switch current isolation...

  • Page 15: Basic Operation

    3 Basic operation Note: The button in gray display indicates nonsupport. 3.1 Turn on Plug the power supply and turn on the power supply switch. Power supply indicator light shining indicates turning on the video recorder. After the startup you will hear a beep. The default setting of video output is multiple-window output mode.

  • Page 16: System Login

    will lose. 3.3 System Login When the DVR boots up, the user must login and the system provides the corresponding functions with the user purview. There are three user settings. The names are admin, guest and default and these names have no password. Admin is the super user purview; guest and default’s permissions are preview and video playback.

  • Page 17: Desktop Shortcut Menu

    3.5 Desktop shortcut menu In preview mode you can right click mouse to get a desktop shortcut menu. The menu includes: main menu, record mode, playback, PTZ control, High Speed PTZ, Alarm Output, color Setting, Output adjust, Logout, view1/4/8/9/16 screens. Picture 3.2 Shortcut Menu 3.5.1 Main menu When you login, the system main menu is shown as below.

  • Page 18: Playback

    3.5.2 Playback There are two methods for you to play the video files in the hard disk. 1、 In the desktop shortcut menu. 2、 Main menu>Record->Playback Note: The hard disk that saves the video files must be set as read-write or read-only state.(4.5.1) Picture 3.4 video playback 1.
  • Page 19 Picture 3.5 detect the storage Detect: Detect the storage connected with the DVR such as hard disk or universal disk. Erasure: Choose the file to delete and click erasure to delete the file. Stop: Stop the backup. Backup: Click backup button and the dialog box is popped up. You can choose the backup file according to the type, channel and time.
  • Page 20 【File searching】Search the file according to the searching parameter. Picture 3.7 file searching File type: Set the searching file type. Channel: Set the searching channel. Start Time: Set the searching time scan. 【Playback control】Refer to the following sheet for more information. Button Function Button...

  • Page 21: Record Mode

    3.5.3 Record Mode Please check current channel status: “○” means it is not in recording status, “●” means it is in recording status. You can use desktop shortcut menu or click [main menu]> [recording function]> [recording set] to enter the recording control interface. Picture 3.8 Record Mode 【Schedule】Record according to the configuration.

  • Page 22: Ptz Control

    state. 【Stop】 Click the stop button and the according channel stops alarming no matter the channel in any state. 3.5.5 PTZ control Operation interface is as followed. The functions include: PTZ direction control, step, zoom, focus, iris, setup operation, patrol between spots, trail patrol, boundary scan, assistant switch, light switch, level rotation and so on.
  • Page 23 Special functions： 1、Preset Set a location for the preset, calls the preset points, PTZ automatically turns to the setting position 1）Preset option Set a location for the preset, procedure is as follows: Step1: in Picture 3.10, click the Direction button will turn into preset position , click the Settings button to enter Picture 3.11.
  • Page 24 Value input blank Picture 3.12 PTZ Control 2、Cruise between Points Multiple preset points connected cruise lines, call cruise between points, the PTZ run around on the line 1）Cruise Between Points Settings Cruise lines is connected by multiple preset points, setting procedure is as follows: Step1: In Picture 3.10, the Direction key will turn PTZ to designated location , click Settings button to enter Picture 3.13, Step 2: click Cruise buttons, the write proper value into the Cruise Line and Preset Points blank，...
  • Page 25 Preset Points Blank Cruise Button Cruise Line Blank Picture 3.13 Cruise Between Points Settings 2）The Calls of Cruise between Points In Picture 3.10, click Page Shift button, enter PTZ control menu as shown in Picture 3.12. Please input the number of cruise in the value blank, then click Cruise between Points button, PTZ begins to work on the cruise line.
  • Page 26 In Picture 3.10, click Page Shift button, then enter PTZ control menu as shown in Picture 3.12. Please input the number of scan in the value blank , then click Scan button，PTZ begins to work on the scan line . Click Stop button to stop. 4、Boundary Scan 1）Boundary Scan setup Step1：In Picture 3.10, click Direction button to turn the PTZ to preset direction, then click Setup...

  • Page 27: Color Setting

    PTZ restart, all the data clears to 0.。 8、Page Shift In Picture 3.12, click Page Shift button into Picture3.16, setting auxiliary function. Auxiliary number auxiliary switch on the decoder. corresponding to Picture 3.16 Auxiliary Function Control 【Intuitive Auxiliary Operation】 choose auxiliary equipment, select Open or Close button, switch control；...

  • Page 28: Output Adjust

    3.5.7 Output Adjust Adjust TV output area parameters. You can use the desktop shortcut menu or enter [main menu]> [management tools]> [Output adjust]. Picture 3.19 Output Adjust 3.5.8 Logout Logout, shut down the system or reboot up. You can use the desktop shortcut menu or enter [main menu].

  • Page 29: Main Menu

    4 Main menu 4.1 Main menu navigation Main menu Sub menu Function Config Set the recording configuration, recording type, recording time section Record playback Set recording look-up, recording play, video file storage backup Detect or format backup equipment, back the selective files Motion Set motion detect alarm channel, sensitivity, area, linkage parameters: detection...
  • Page 30 Set channel, PTZ protocol, address, baud rate, date bit, stop bit, check configuration Serial port Configuration Set serial port function, baud rate, date bit, stop bit, check (RS232) Tour Set patrol mode and interval time Hard disk Set appointed hard disk as read-write disc, read-only disc or redundant management disc, clear data, resume date and so on User...

  • Page 31: Record

    4.2 Record 4.2.1 Record Config Set the recording parameters in the surveillance channel. The system is set 24 hours consecutive recording in the first startup. You can enter [main menu]> [recording function]> [recording setup] to set. Note：There is at least one read-write hard disk.（refer to chapter 4.5.1） Picture 4.1 Record Config 【Channel】Choose the corresponding channel number to set the channel.

  • Page 32: Snapshot Storage

    channel in any state. 【Period】Set the time section of common recording, The recording will start only in the set range. 【Record type】Set recording type: regular, detection or alarm. Regular:Perform the regular recording in the set time section. The video file type is “R”. Detect:Trigger the “motion detect”, “camera mask”...

  • Page 33: Playback

    Schedule:Realise snapshot according to record type(regular,detect and alarm) and period. Manual:No matter what the present channel is in a state,once choose "manual" button,it will have snapshot at related channels. Stop:No matter what the present channel is in a state,once choose "stop" button,it will stop snapshot at related channels.

  • Page 34: Alarm

    【Detect】Detect the storage connected with the DVR such as hard disk or universal disk. 【Erase】Choose the file to delete and click erasure to delete the file. 【Stop】Stop the backup. 【Backup】Click backup button and the dialog box is popped up. You can choose the backup file according to the type, channel and time.
  • Page 35 Picture 4.4 Motion Detect 【Channel】Choose the set motion detect channel. 【Enable】■ means that the motion detect function is on. 【Sensitivity】Choose in the six options according to the sensitivity. 【Region】Click setup and enter the set area. The area is divided into PAL22X18. Green block means the current cursor area.
  • Page 36 Picture 4.6 set the time section 【Interval】Only one alarm signal is turned on even there are several motion detect signals in the set interval. 【Alarm output】 Start the external equipment of corresponding linkage alarm when the motion detect alarm is turned on. 【Delay】Delay a few moments and stop when the alarm state is turned off.

  • Page 37: Video Blind

    Picture 4.8 PTZ Activation 【Delay】When alarm is over,recording will last some seconds(10~300sec),then stop. 【Show message】Pop the alarm information dialog box in the local host computer screen. 【Send EMAIL】■ means sending an email to user when the alarm is turned on. Note:Set in the [NetService] and send email.

  • Page 38: Video Loss

    4.3.3 Video Loss When the equipment can not obtain the channel video signal, the video loss alarm is turned on and the linkage function is turned on. Picture 4.10 Video loss Set method: refer to chapter 4.3.1. Motion detect Note:"Advanced" button is the same as rightclick. 4.3.4 Alarm input When the equipment obtains the external alarm signal, the alarm function is turned on.

  • Page 39: Alarm Output

    Set method: refer to chapter 4.3.1. Motion detect Note:"Advanced" button is the same as rightclick. 4.3.5 Alarm output Refer to chapter 3.5.4. 4.3.6 Abnormal Analysing and inspecting current software and hardware of the device: When some abnormal events happen,the device will make a relative answer such as show message and buzzer. Picture 4.12 Abnormal 【Event Type】...

  • Page 40: System

    4.4.1 General Picture 4.13 General setup 【System time】Set the system data and time. 【Date format】Choose the data format: YMD, MDY, DMY. 【Date Separator】Choose list separator of the data format. 【Time Format】Choose time format: 24-hour or 12-hour. 【Language】English,French,Portugueses,Russian,Italian,S-Chinese, T-Chinese,Spanish,Thai,Greek,Japanese,German,Polish. 【HDD full】Choose stop record: Stop recording when the hard disk is full. Choose overwrite: Cover the earliest recording files and continue recording when the hard disk is full.

  • Page 41: Encode

    Picture 4.14 DST (week) Picture 4.15 DST (date) 4.4.2 Encode setup Set the video/audio code parameter: video file, remote monitoring and so on. Set every independent channel’s coding parameter in the left part, and set the combine encode parameter in the right part. Note: Combine encode introduces video compression technique which combines and compresses multi-channel’s video to a special channel.Applying for multi-channel playback simultaneously, Dial-up multi-channel real-time monitor, mobile monitor and so on.

  • Page 42: Network

    【Channel】Choose the channel number. 【Compression】Standard H.264 main profile. 【Resolution】Resolution type:D1/ HD1/CIF / QCIF. 【Frame Rate】P:1 frame/s~25 frame/s; N: 1 frame/s~30 frame/s 【Bit Rate Type】You can choose limited code stream or variable code stream. When you choose the variable code stream there are six image quality options. 【Bit Rate】Set the code stream value to modify the image quality.
  • Page 43 【Net Card】You can choose cable network card or wireless network card. 【DHCP Enable】Obtain IP address automatically(not suggested) Note：DHCP server is preinstalled. 【IP address】Set the IP address. Default: 192.168.1.10. 【Subnet mask】Set the subnet mask code. Default: 255.255.255.0. 【Gateway】Set the default gateway. Default: 192.168.1.1. 【DNS setup】Domain Name Server.
  • Page 44 【PPPoE setup】 Picture4.19 PPPOE Input the user name and password that ISP（Internet service provider）provides. After saving it reboot up your system. Then the DVR will build a network connection based on PPPoE. The IP address will change into dynamic IP address after above operation is well done. Operation：...
  • Page 45 Update Period: The same with the NTP server check interval. Default: 10minutes. 【EMAIL setup】 If the alarm is turned on or the alarm linkage photos are taken, send an email about the alarm information and the photos to appointed address. Picture 4.21 EMAIL Snapshot and Email Setting procedure Refer to chapter Appendix 5.
  • Page 46 When choosing the black list, the listed IP address can not connect the DVR. The 64 IP addressed are supportive in the list. You can delete the set IP address by √ in the options. Note： When the same IP address is in the white and black list at the same time, the black list precedence is higher.
  • Page 47 Picture 4.23 DDNS setup 【FTP setup】FTP is available only when alarm happens,or alarm activates record and snapshot,it will upload related record and snapshot pictures to FTP server. Picture 4.24 FTP setup 【Enable】Click Enable,then all settings will be available 【Server IP】 IP address for FTP server 【Port】...
  • Page 48 Picture 4.25 Wireless Config 【Enable】Choose Enable to make all settings available 【Type】Dial type,default AUTO 【Wireless AP】3G access point 【Dial Number】3G Dial Number 【User Name】User name of 3G 【Password】Password of dial user 【IP Address】IP address,got from dial 【Mobile Monitor Setup】 To visit the device by mobile,pls make a router mapping of this port and use CMS to monitor and operate it by protocol.

  • Page 49: Gui Display

    【UPNP】UPNP protocol can auto port forwarding on router,make sure UPNP is running on router before use it. Picture 4.27 【Enable】Choose Enable to make sure all UPNP settings available 【HTTP】Route will automatically distribute HTTP port for the device,when IE viewing,it need this port(eg.
  • Page 50 Picture 4.28 GUI Display 【Channel Title】Click the channel name modify button and enter the channel name menu. Modify the channel name. The 16 Chinese characters and 25 letters are supportive. 【Time Display】means the selective state. Display the system data and time in the surveillance window.

  • Page 51: Ptz

    4.4.6 PTZ setup Picture 4.29 PTZ setup 【Channel】Choose the dome camera input channel. 【Protocol】Choose the corresponding dome protocol. (PELCOD as an example) 【Address】Set as the corresponding dome address. Default: 1.（Note：The address must be consistent with the dome address.） 【Baudrate】 Choose the corresponding dome baud rate length. You can control the PTZ and vidicion. Default: 115200.

  • Page 52: Tour

    Picture 4.30 RS232 setup 【Serial Port Function】Common serial port is used to debug and update program or set up specific serial port. 【Baud rate】Choose the corresponding baud rate length. 【Data bits】Include 5-8 options. 【Stop bits】Include 2 options. 【Parity】Include odd, even, mark, space. 4.4.8 Tour setup Set the patrol display.

  • Page 53: Advanced

    Picture 4.31 tour setup 【interval】Set the patrol switch interval. The set range is 5-120 seconds. Note： means turn off/on the patrol. 4.5 Advanced 4.5.1 HDD Manage Configure and manage the hard disk. The menu displays current hard disk information: hard disk number, input port, type, status and overall capability.

  • Page 54: Account

    Picture4.32 HDD Manage 4.5.2 Account Manage the user purview. Note：1. The character length is 8 bytes at most for the following user and user team name. The blank ahead or behind the character string is invalid.The middle blank in the character string is valid. Legal characters include: letter, number, underline, subtraction sign, dot.
  • Page 55 Picture 4.33 Account 【Modify User】Modify the existed user attribute. 【Modify Group】Modify the existed team attribute. 【Modify Password】Modify the user password. You can set 1-6 bit password. The blank ahead or behind the char string is invalid. The middle blank in the char string is valid. Note：The user who possess the user control purview can modify his/her own or other users password Picture 4.34 Modify Password...
  • Page 56 We recommend that the common user’s purview is lower than the advanced user. Picture 4.35 add user 【Add Group】Add a user team and set the purview. There are 36 different purviews: shut down the equipment, real time surveillance, playback, recording setup, video file backup and so on. Picture 4.36 Add Group 【Delete User】Delete the current user.

  • Page 57: Online User

    Picture 4.37 Delete Group 4.5.3 Online User Look up the network user information in the local DVR. You can choose the network user and cut the connection. Then the user is locked until next boot-strap. Picture 4.38 Online User 4.5.4 TV adjust Refer to chapter 3.5.7 .

  • Page 58: Auto Maintain

    4.5.5 Auto Maintain The user can set the auto reboot time and auto file deleting time limit. Picture 4.39 Auto maintain 4.5.6 Restore The system restore to the default setup. You can choose the items according to the menu. Picture 4.40 Restore Page 58...

  • Page 59: Upgrade

    4.5.7 Upgrade Upgrade Picture 4.41 【 Upgrade】choose USB interface. 【Upgrade file】choose the file which needs upgraded. 4.5.8 Device Info Provide device interface info like audio in,alarm in/out to be conveniently used for user. Picture 4.42 Device Info. 4.6 Info 4.6.1 HDD info Display the hard disk state: hard disk type, overall capability, residual capability, the recording time and so on.

  • Page 60: Bps

    Picture 4.43 HDD Info Clue:○ means that the hard disk is normal. X means that the hard disk is broken-down.- means that there is no hard disk. If the user need to change the damaged hard disk, you must shut down the DVR and take up all the damaged hard disks,then install a new one.

  • Page 61: Log

    Picture 4.44 BPS 4.6.3 LOG Look up system log according to the set mode. Log information include: system operation, configuration operation, data management, alarm affair, recording operation, user management, file management and so on. Set the time section to look up and click the look up button.

  • Page 62: Version

    4.6.4 Version Display the basic information such as hardware information, software edition, issue data and so on. Picture 4.46 Version 4.7 Shut down system Refer to chapter 3.5.8. Page 62...

  • Page 63: Faq And Maintenance

    5 FAQ and maintenance 5.1 FAQ If the problems are not listed, please contact the local service or call the HQ service. We are willing to offer the service. 1、 The DVR can not boot up normally. Possible reasons are as followed: The power supply is not correct.
  • Page 64 Possible reasons are as followed: The program is not matched. Please update the program. The image brightness is all 0. Please restore the default setup. There is no video input signal or the signal is too weak. The channel protection or the screen protection is set. The hardware of the DVR is damaged.
  • Page 65 It is not an active tone arm. It is not an active sound box. The audio lines are damaged. The hardware of the DVR is damaged. 9、 There is audio signal in the surveillance window but mo audio signal in the playback state.
  • Page 66 The sensitivity is too low. Limited by some hardware edition. 13、 I can not login via web or CMS. Possible reasons are as followed: The system is windows 98 or win me. We recommend updating to windows 2000sp4 or higher Version or installing the software for low edition. ActiveX is hold back.
  • Page 67 The data is too much. Please stop recording and backup. The data exceeds the backup storage. The backup equipment is not compatible. The backup equipment is damaged. 17、 The keyboard can not control the DVR. Possible reasons are as followed: The serial port of the DVR is not set correctly.

  • Page 68: Maintenance

    Possible reasons are as followed: Front vidicon quality is bad. The lens is too dirty. The vidicon is in backlighting installation. The hard disk capability is not enough. The hard disk is damaged. 22、 The downloading files can not play. Possible reasons are as followed: There is no media player.

  • Page 69: Appendix 1.Remote Controller Operation

    Appendix 1.Remote controller operation Serial Name Function number Multi-window Same function as Multi-window button in the front button panel Numeric button Code input/number input/channel switch 【Esc】 Same function as【Esc】button in the front panel Direction button Same function as direction button in the front panel Record control Control the record Same function as “Record mode”...

  • Page 70: Appendix 2.Mouse Operation

    Appendix 2.Mouse operation *Take right hand as an example The mouse in USB connection is supported. Operation Function Double click one item in the file list to playback the video Double click the playback video to zoom in or out the Double left click screen Double click the channel to make it full screen display...

  • Page 71: Appendix 3.Hard Disk Capability Calculation

    Appendix 3.Hard disk capability calculation Make sure the hard disk installed to the DVR for the first time. Pay attention to the IDE hard disk lines connection. 1、 Hard disk capability There is no limit for recording machine. We recommend 120G~250G size to keep better stability.

  • Page 72: Appendix 4.Technique Parameters

    Appendix 4.Technique parameters Type 16ch Main processor High performance embedded microprocessor Operation system Embedded LINUX operation system System System resource synchronous multi-channel recording, synchronous multi-channel sub-code stream, synchronous multi-channel playback, synchronous network operation Operation interface 16 bit true color graphical menu interface, mouse operation supportive Interface display...
  • Page 73 Recording mode manual >alarm>motion detect>timing Record Playback Any channels playback, multiple channels playback Search mode Time searching, calendar searching, affair searching, channel Playback searching, information searching Space Occupation Audio: 28.8MB/H Video:25～450MB/H Storage Recording storage Hard disk, network backup Backup mode Network, USB flash,USB movable HDD,USB DVD-RW Video input 4 BNC...
  • Page 74 Weight 3kg（without hard disk） Installation Desktop Page 74...

  • Page 75: Appendix 5.E-Mail Setting

    Appendix 5. Email Setting 1.Email Setting 1) Go to Main Menu->System->NetService to double click “EMAIL”,see below picture: 2) To write the EMAIL settings,for example gmail,see below picture: Page 75...
  • Page 76 3.Motition Detection setting. Go to Main Menu->Alarm->Motion Detect,select “Enable “Send Email”,then click “OK”,see below picture: After finishing all above operations,pls go to make some motion detect, you will receive emails without snapshot. See below the forwarded email. Page 76...

  • Page 77: Appendix 6.Mobile Monitoring

    Appendix 6.Mobile Monitoring The Mobile client software is useful for live preview you can switch between the cameras if you use speed dome you could be able to control it. The software not be able to record and take snapshot. Supported mobile operating systems: Symbian, Window mobile, Android, BlackBerry Page 77...

  • Page 78: Appendix 7.Cms

    Appendix 7. CMS (Controll management software) - The CMS software you could find on the CD - You could be able to controll numerius of DVRs liveview & playback - With the CMS you could be able to program the DVR from different locations. Page 78...

  • Page 79: Appendix 8.Ftp Setting

    Appendix 8.FTP Setting 12-14 minutes long videos Page 79...
  • Page 80 Service: LDSZ Kft. 1117 Budapest Nádorliget u.7/b www.identivision.hu/en Page 80...
