Identivision ICR-PH161i PIONEER User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
ICR-PH161i PIONEER DVR
User's Manual
Summary:
Thank you for purchasing our product with Intelligent analysis, which makes it with feature
of advanced, applicability, easiness for use, expansibility, etc.
Main Features:
 IVS(Intelligent video analysis system)
 D1 Real time recording speed ( FULL D1 400 fps )
 Informatization and Mobile
1 / 27

Advertisement

loading
Need help?

Need help?

Do you have a question about the ICR-PH161i PIONEER and is the answer not in the manual?

Questions and answers

Related Manuals for Identivision ICR-PH161i PIONEER

Summary of Contents for Identivision ICR-PH161i PIONEER

  • Page 1 ICR-PH161i PIONEER DVR User's Manual Summary: Thank you for purchasing our product with Intelligent analysis, which makes it with feature of advanced, applicability, easiness for use, expansibility, etc. Main Features:  IVS(Intelligent video analysis system)  D1 Real time recording speed ( FULL D1 400 fps ) ...
  • Page 2 Part One: Basic Operation 1. Basic installation 1.1 HDD installation Please install the Hard disk before the first time to use this product. Please connect power cable and data cable of HDD correctly, our product can support 2 HDD ( available to order 4 or 8 HDD) , how many HDD can support is depends on which kind of product that buyer purchase.(Remark: the device can run normally without HDD, but can not do record and playback) 1.2 Mouse connection...
  • Page 3 When the DVR boots up, user must login and the system provides the corresponding functions with the user purview. There are two user settings which are admin, and guest; and they have no passwords. “Admin” is the super user purview; “Guest” is the user for preview and playback. User can modify the password of Admin and Guest, but can not modify the authority of them.
  • Page 4 [Record Config] to set. The system’s default set is 24 hours continuous recording. Note: There is at least one read-write hard disk if the DVR records normally.(refer to chapter 4.5.1 HARD DISK Manage) Pic 2 Recording Config 【 Channel 】 Choose the corresponding channel number to set the channel. Choose the “all”...
  • Page 5 Stop: Click the “stop” button and make the according channel stop recording no matter it is in any state. 【 Period 】 Set the time section of common recording, The recording will start only in the set range. 【 Recording Type 】 Set recording type: regular, detect or alarm. regular ：...
  • Page 6 Pic 3 Snapshot Please refer to “6 record settings”. 8. Playback There are two methods for you to play the video files in the hard disk. 1. In the desktop shortcut menu. 2. Main Menu>Record>Playback. Enter the playback interface, you can playback video of multi-channels at the same time.
  • Page 7 Pic 4: Playback 1. back up options 2.file info 3. file searching 4 ． File backup 5.operation hint 6.play control key 【 File option 】 Choose the file to playback/backup. 【 File information 】 Start time, end time and size. Note: The storage must be large enough before the file backup.
  • Page 8 【 playback control 】 Refer to the following sheet for more information. Chart 2 Playback control key N ote ： Frame by frame playback is only performed in the "pause" playback state. Special functions: Accurate playback Input time (h/m/s) in the time column and then click playback. Local zoom: When the system is in single-window full-screen playback mode, you can drag your mouse in the screen to select a section and then left click mouse to realize local zoom.
  • Page 9 Pic 5: Network setting Make the equipment’s IP address and the router in the same network segment. For example, the router IP address is 192.168.1.1, and the subnet mask is 255.255.255.0. According to the default setup, generally the default gateway is the router IP address, so enter IP address 192.168.1.10 in the IE browser to achieve visiting LAN equipment such as operating image surveillance in the public network remote access equipment for monitoring.
  • Page 10 Pic 6 Motion Detect Motion detection setup. Set DVR equipment making it alarm, linkage record and make the PTZ turn to preset position when there is a moving object in designated areas during Monday to Friday. Step1. Choose 【 Main Menu 】 > 【 Alarm 】 > 【 Motion Detect 】 ,then enter the setup interface; Step2.
  • Page 11 Pic 7 Video analysis 【 Video analysis function 】 : can set in two rules: picket line and picket area Picket line rules: can set to forbid bidirectional, from up to down (from left to right), from down to up(from right to left), 2 forbidden directions, when the moving objects meet the picket line rules, alarm will occurred.
  • Page 12 Pic 8 Rule setting Step 3: enable show track function, adjust level of sensibility and minimum image distance. Set picket mode, choose picket line or picket area, click setting to enter the config interface, right click the mouse and choose add, use mouse to set two or more points then connect to form a line or a irregular area, after that will come out an option box of forbidden direction, choose one of them and right click mouse, then click yes return to pre-interface, click yes to finally finish alarm rules setting.
  • Page 13 1. Perimeter detection （ PEA ） (1). touch line detection : bidirectional touch line, single-direction touch line (2). Area detection: enter alarm , leave alarm 2.Items Care （ OSC ） 13 / 27...
  • Page 14 Detect the change of goods status will alarm in time. The change can be goods left in the scene, or the goods be moved or lost. Main function: items left and stolen or moved. (1). Detect something was dropped from the motor bike. (2).
  • Page 15 3.Flowmeter count(CPC) The head count of people passing in and out of duty room, which is fit for flow statistic in simple indoor narrow passage . 4.Abnormal video signal diagnosis (AVD) Auto-detect that there is mess of skid bars, ripple, or a burst of flying spot, thorn or thread type of interference in the video image that lead to image fuzz, twisted, snow, flicker, scrolling, etc.
  • Page 16 11. PTZ Control To do simple PTZ control via below steps: Step 1: 【 Main Menu 】 > 【 System 】 > 【 PTZ 】 ,to set parameter of channel, protocol, etc. Step 2: under preview status to enter single window of PTZ control ； Step 3: single click right button, choose PTZ control to control the normal function, or choose high-speed , click left button can operate PTZ directly, the moving of mouse is to control the direction of PTZ, use the rolling can zoom in or zoom out of the camera.
  • Page 17 To do remote control at the interface of pic 9 2.1 Screen Split To choose the mode of preview 2.2 Playback Enter playback area, can support multi-channel playback at the same time. 2.3 Log Show with log information 2.4 Local config To set device alarm, enable to linkage function on the remote network client side.
  • Page 18 Part Three: Special Function This serie trend towards humanize design, visualize operation key, partial enlargement in any region of preview interface, regular boot and shutdown, FTP upload, support WIFI function, etc, greatly meet user’s need. Here specially introduce encode setting, multi-channel playback, mobile monitor settings.
  • Page 19 Pic 10 Encode 1.1 Encode of separated channel setting Step 1: Local operation, 【 Main Menu 】 > 【 System 】 > 【 Encode 】 （ Remote setting is right click on the window and then choose Device Config at 【 System 】 > 【 Encode 】）； Step 2: Choose channel one, set resolution with D1, frame rate with 20, byte rate value 1024;...
  • Page 20 1.2 Extra stream config Extra stream is used for client side monitor and mobile monitor Step 1: Enable extra stream Step 2: Config frame rate, code stream value, the setting way is the same as separated channel parameter. 2. Multi-channel playback at the same time 4ch device can achieve 4ch playback at the same time, 8ch device can achieve 8ch playback at the same time, channel no.
  • Page 21 3. Multi-channel real-time transfer via network Use extra stream technology, to real-time remote monitor multi-channel under the narrow bandwith(or poor network condition) Pic 12 Step 1: same as “1.2 extra stream config”, enable extra stream. Step 2: open CMS, login software Step 3: after add related device, choose window, select related channel at device list, right click, choose to connect all the video (can choose main stream or extra stream, base on network environment to choose)
  • Page 22 Pic 13 Mobile client side interface Step4: click device list on above, input the IP address, user name, password, port no. of the device that need to be monitored. Device Name: user can set it as he like. User name: login name of device Password: password of device Server: IP address of device Port: 34567 (Remark: the port no.
  • Page 23 After added device, click yes, will see pic 14, choose the channel you want to monitor, the preview image will be displayed. Pic:14 mobile monitor interface Remark: when the DVR is in local area network, the mobile should connect to wireless router to access the device, each kind of mobile related to different client software ( due to different version, should be follow the version in the CD) Symbian...
  • Page 24 ICR-PH161i PIONEER series is with HDMI output as a standard configuration. 6.1 SPOT output function ICR-PH161i PIONEER series product have 2 BNC output port, one of them support SPOT output, user can shift SPOT output split image mode through right click menu. Note: if connect this BNC, no matter how you operate on VGA output, TV side always show the preview screen, can not show he GUI interface.

  • Page 25: Appendix 1. Remote Controller Operation

    6.2 Standard HDMI output The product is standard configured with HDMI output, no need add additional HDMI module. Appendix 1. Remote controller operation Name Function Multi-channels butto Multi-channels preview Number button Password input/number input/ channel switch 【 Esc 】 Back to up window Direction button Direction and OK button Playback operate...

  • Page 26: Appendix 2.Mouse Operation

    Appendix 2.Mouse operation *Take right hand as an example Operation Function Double click one item in the file list to playback the video Double left click Double click the playback video to zoom in or out the screen Double click the channel to make it full screen display in preview double click again to resume the multi-channel display Left click Choose according option in the menu...
  • Page 27 27 / 27...
