I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Display Cart with Storage Shelf
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
MSP-CSC11
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CHIEF MSP-CSC11
Summary of Contents for CHIEF MSP-CSC11
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Display Cart with Storage Shelf Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description MSP-CSC11...
-
Page 2: Installation Instructions
It is the installer’s responsibility to make sure the combined weight of all components located between the MSP-CSC11 up to (and including) the display does not exceed 75 lbs (34 kg). The combined weight of all components stored within or on the storage shelf cannot exceed 25 lbs (11.3 kg). - Page 3 Installation Instructions MSP-CSC11 36.07 34.06 916.3 865.2 14.44 366.8 20.00 508.0 36.09 916.6 77. 9 APPROX CENTER 1979.7 OF MONITOR 73.3 1862.8 TO FLOOR 69. 9 MAX/MIN [1775.5] 1.74 65.3 68.5/60.5 44.1 [1658.6] (MX300) 4X 0.10 54.53 1.57 1385.0 R0.14 39.8...
- Page 4 MSP-CSC11 Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 5: Tools Required For Installation
Installation Instructions MSP-CSC11 TOOLS REQUIRED FOR INSTALLATION 3/16" (included) 3/16" (included) 5/32" (included) M5 (included) 1/8" (included) PARTS A (1) [right leg] B (1) [left leg] C (2) [end cap] D (1) [column assembly] H (4) E (4) G (1) 1/4-20 x 3/4"... -
Page 6: Display Installation
It is the installer’s responsibility to make sure the combined weight of all components located between the MSP-CSC11 up to (and including) the display does not exceed 75 lbs (34 kg). Figure 3... - Page 7 Installation Instructions MSP-CSC11 Hand tighten two M6x40mm socket head cap screws (J) into top two holes on display and interface plate. (See (MX300 install) Figure 4) Hand tighten two M6x40mm socket head cap screws (J). into lower two holes on display and interface plate. (See Figure 4) Tighten all four screws.
-
Page 8: Cable Management
MSP-CSC11 Installation Instructions Hand tighten two M6x50mm socket head cap screws (K) into Storage Shelf Installation top two holes on display and interface plate. (See Figure 10) Use four 1/4-20 x 3/4" button head cap screws (H) to secure IMPORTANT ! : Top two screws must be installed prior pole attachment plate (G) to storage shelf (F). -
Page 9: Cable Cover Installation
Installation Instructions MSP-CSC11 Any accessory power cords can be run through the opening on column behind storage shelf and down through the post to exit out the back. (See Figure 13) Route signal cables from display to corresponding devices back cover in storage shelf. - Page 10 MSP-CSC11 Installation Instructions Adjusting Cart Height Cart Use and Maintenance NOTE: The column assembly contains a gas spring which allows for safe and easy height adjustment after the CAUTION: This cart is intended for use only with the display has been mounted. Adjusting the height when products and maximum weights indicated.
- Page 11 Installation Instructions MSP-CSC11 Always place cart on level surface. Always lock the wheels when the cart is not moving. Use cable clips on column to hang cables as needed when moving cart. (See Figure 17) cable clips cable (example) Figure 17...
- Page 12 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
