Kidde Pro line Service Manual page 14

Dry Chemical Extinguisher Parts Diagram - Aluminum Valve
KIDDE PRO LINE STORED PRESSURE DRY CHEMICAL
PORTABLE EXTINGUISHER DIAGRAM (ALUMINUM VALVE)
The following spares parts are available for the Kidde
Pro Line:
(1) Hose/nozzle assembly
(2) Syphon tube assembly (excludes o-ring)
(3) Valve assembly (includes handle & lever attached & valve body
excludes o-ring)
(4) O-ring kit (includes valve o-ring, syphon tube o-ring, stem
assembly, stem assembly spring)
(5) Wall hanger
(6) Retention bracket
(7) Pull pin
(8) Pressure gauge
(9) Hanger loop and screw
(10) Hose strap
Model
Part Number
1
2
3
4
5
6
7
8
9
10
Model
Part Number
1
2
3
4
5
6
7
8
9
10
Pro 10 TCM-5 Pro 10 TCM-6
466204 466204
440329 440329
21005738 21005738
21005739 21005739
21005740 21005740
340791 340791
366242 366242
320213 320213
294063 294063
340173 340173
Pro 20 TCM-4 Pro 20 TCM-5
466206 466206
440126 440330
21005553 21005553
21005739 21005739
21005740 21005740
14260 14260
292474 292474
320213 320213
294063 294063
8516, 321049 8516, 321049
340175 340175
14
Pro 20 RM- Pro 20 RM-4 Pro 20 RM- Pro 20 RM-5 Pro 20 RM- Pro 20 RM-
46620 46620 466207 7 7 466207
440127 440127
21005553 21005553
21005739 21005739
21005740 21005740
14260 14260
292474 292474
320213 320213
294063 294063
8516, 321049 8516, 321049
340175 340175
