Related Manuals for PEUGEOT 508
Summary of Contents for PEUGEOT 508
- Page 1 Handbook APp-W2_01_2010_anglais_cag_pdf_Hcouv1 couv1 APp-W2_01_2010_anglais_cag_pdf_Hcouv1 couv1 03/11/2010 14:19:56 03/11/2010 14:19:56...
-
Page 2: Keyless Entry And Starting
Familiarisation Exterior Keyless Entry and Starting This system allows you to unlock, lock and start your vehicle while keeping the key on your person and in the defined zone. 39, 94 Stop & Start Parking space sensor This system puts the engine temporarily into This system measures the size of a space and standby during stops in the traffic (red lights, traffic advises whether parking is possible. - Page 3 Familiarisation Exterior Front and rear parking sensors Motorised tailgate (SW) This system provides a warning when This system provides motorised opening and manoeuvering forwards and backwards by closing of the tailgate, by pressing a button. detecting obstacles located in front of or behind the vehicle.
-
Page 4: Remote Control Key
Familiarisation Open Remote control key Fuel tank A. Unfolding/Folding the key. Unlocking B. Unlocking the vehicle. Opening the fuel filler flap. With the electronic key on your person and in the defined zone, pass your hand behind the door handle to unlock the vehicle, then pull on the handle to open the door. -
Page 5: Head-Up Display
Hi-Fi audio system, ... do not need to take their eyes off the road. Satellite navigation system Audio system If your 508 is fitted with a JBL Hi-Fi audio system, this is designed specifically for the passenger compartment of your vehicle. -
Page 6: Switch Panels
Familiarisation Switch panels Deactivation of the ESP/ASR system. Electric child lock. Lighting of the indicator lamp indicates the state of the corresponding function. Massage. Electric parking brake. Programmable heating warning lamp. Starting/stopping using the Smartbeam. Deactivation of parking sensors. electronic key. Parking space sensor. -
Page 7: Sitting Comfortably
Familiarisation Sitting comfortably Front seats Manual adjustments Head restraint height and angle adjustment. 2. Backrest angle adjustment. 3. Seat cushion height adjustment. 4. Lumbar support adjustment. 5. Seat forwards-backwards adjustment. 6. Cushion adjustment. Electrical adjustment Angle, seat height and seat forwards- backwards adjustment. -
Page 8: Instruments And Controls
Familiarisation Instruments and controls Cruise control/speed limiter controls. Fusebox. 18. Central adjustable air vents. 2. Headlamp height adjustment. 10. Front door window demisting/defrosting 19. Passenger's airbag. 3. Lighting and direction indicator stalk. vent. 20. Side adjustable air vents. 4. Instrument panel. 11. - Page 9 Familiarisation APp-W2_01_2010_anglais_cag_pdf_H11 11 APp-W2_01_2010_anglais_cag_pdf_H11 11 03/11/2010 14:20:16 03/11/2010 14:20:16...
-
Page 10: Head Restraint Adjustment
Familiarisation Sitting comfortably Head restraint adjustment Steering wheel adjustment Heated seats control 0 : off. To lower it, press button A . Release the adjustment mechanism. 1 : low. To raise it, guide the head restraint upwards to 2. Adjust for height and reach. 2 : medium. -
Page 11: Door Mirrors
Familiarisation Sitting comfortably Door mirrors Rear view mirror Front seat belts Adjustment Manual day/night type Selection of the mirror. Selecting the "day" position of the rear Fitting the belt. 2. Adjusting the position of the mirror glass. view mirror. 2. Fastening. 3. -
Page 12: Seeing Clearly
Familiarisation Seeing clearly Lighting Wipers Ring A Control stalk A: windscreen wipers 2. Fast wipe. Lighting off. Switching on "AUTO" mode Normal wipe. Briefly push the stalk downwards. Int. Intermittent wipe. Automatic illumination of headlamps. 0. Park. Sidelamps. Switching off "AUTO" mode AUTO Automatic wiping. - Page 13 Familiarisation Ventilation Advice on interior settings Heating or manual air conditioning I would like... Air recirculation/ Air distribution Air flow Temperature Manual A/C Exterior air intake COLD DEMISTING DEFROSTING Digital air conditioning: use of the fully automatic mode by pressing the "AUTO" button is recommended. APp-W2_01_2010_anglais_cag_pdf_H15 15 APp-W2_01_2010_anglais_cag_pdf_H15 15 03/11/2010 14:20:21...
-
Page 14: Instrument Panel
Familiarisation Monitoring Instrument panel Warning lamps On switching on, the dial needles go to the C. With the ignition on, the instrument panel With the ignition on, the orange and red extent of their travel then return to 0. screen should indicate the level of oil. warning lamps come on. -
Page 15: Passenger Safety
Familiarisation Passenger safety Front passenger's airbag Front seat belts and passenger's front airbag A. Front seat belts not fastened or unfastened warning lamp. Open the glove box. B. Front passenger's airbag deactivation 2. Insert the key. indicator lamp. 3. Select position: C. -
Page 16: Driving Safely
Familiarisation Driving safely Stop & Start Going into engine STOP mode Going into engine START mode The "ECO" warning lamp comes The "ECO" warning lamp goes off on in the instrument panel and the and the engine restarts with an engine goes into standby;... -
Page 17: Display In The Instrument Panel
Familiarisation Driving safely Speed limiter "LIMIT" Cruise control "CRUISE" Display in the instrument panel The cruise control or speed limiter mode appears in the instrument panel when it is selected. Cruise control Selecting speed limiter mode. Selecting cruise control mode. 2.
