MY PEUGEOT 508
HANDBOOK

Advertisement

Table of Contents
loading

Related Manuals for PEUGEOT 508

Summary of Contents for PEUGEOT 508

  • Page 1 MY PEUGEOT 508 HANDBOOK...
  • Page 2 Access to the Handbook MOBILE APPLICATION ONLINE Install the Scan MyPeugeot App (content available Visit the PEUGEOT website and select the offline). ‘MyPeugeot’ section to view or download the handbook or go to the following address: http://public.servicebox.peugeot.com/APddb/ Scan this QR Code for direct access.
  • Page 3 The descriptions and illustrations are for guidance only. Right-hand drive vehicle Automobiles PEUGEOT reserves the right to modify the technical specifications, equipment and accessories without having to update this guide. If ownership of your vehicle is transferred, please ensure this Handbook is Location of the equipment / button passed on to the new owner.
  • Page 4 Contents  ■ Overview Mirrors Electronic stability control (ESC) Rear seats Seat belts Heating and Ventilation Airbags  ■ Eco-driving Dual-zone automatic air conditioning Active bonnet Front demisting - defrosting Child seats Heated windscreen Deactivating the front passenger airbag Instruments Rear screen demisting/defrosting ISOFIX child seats Digital instrument panels Additional heating/ventilation system...

  • Page 5: Table Of Contents

    Compatibility of fuels Hybrid engine Refuelling Dimensions Misfuel prevention (Diesel) Identification markings Hybrid system Charging the traction battery (Hybrid) PEUGEOT Connect Radio Towing device First steps Towing device with retractable ball joint Steering mounted controls Roof bars Menus Snow chains...
  • Page 6 10. 12 V socket or USB sockets 11. Front passenger airbag 12. Glove box 1. Hazard warning lamps Sunroof and blind controls Central locking Touch-sensitive courtesy lamp / Front touch- 2. 8" (PEUGEOT Connect Radio) or 10" HD sensitive reading lamps (PEUGEOT Connect Nav) touch screen...
  • Page 7 F. Select an audio source Steering mounted controls G. Display the list of radio stations / audio tracks Side switch panel 1. 8" (PEUGEOT Connect Radio) or 10" HD (PEUGEOT Connect Nav) touch screen controls Access to the Hybrid menu 2.
  • Page 8 Overview Rechargeable hybrid mode in case of moderate demand. It assists the petrol engine during starting and acceleration system phases. The electric power is supplied by a rechargeable traction battery. 1. Petrol engine 2. Electric motor 3. Traction battery 4. 12 V accessories batteries 5.
  • Page 9 Visit engine braking rather than the brake pedal and multimedia devices (film, music, video game, a PEUGEOT dealer or a qualified workshop press the accelerator gradually. These attitudes etc.) to help reduce consumption of electrical as soon as possible to restore your vehicle’s...
  • Page 10 Eco-driving Optimising the driving range (hybrid vehicles) Connect the vehicle as soon as possible. Favour the ECO zone of the power indicator by driving smoothly and at a steady speed. Anticipate slowing down as much as possible and, if possible, favour decelerations with regenerative braking (power indicator in the CHARGE zone).
  • Page 11 Instruments Head-up digital display Depending on the display mode selected, certain – in fixed locations: information is hidden or presented differently. • Information related to the gearbox and gear This digital instrument panel can be customised. Example with the "ÉNERGIE" display mode: shift indicator.
  • Page 12 Choosing a display colour customisable areas on the left and right. various modes on the right-hand side of the Configuring a "PERSONAL" display mode (With PEUGEOT Connect Nav) instrument panel. The instrument panel display colour depends on With 8" touch screen ►...
  • Page 13 (fixed or flashing) and/or in several colours. the ignition. The rechargeable hybrid system is faulty. Associated warnings (2): Contact a PEUGEOT dealer or a qualified Carry out (1) and then (2). workshop. The illumination of a lamp may be accompanied...
  • Page 14 Instruments Cable connected (Hybrid) Seat belts not fastened/unfastened Identify the cause of the fault using the message Fixed. Fixed or flashing, accompanied by an displayed in the instrument panel. It is not possible to start the vehicle while increasing audible signal. You can deal with certain problems yourself, for the charging cable is connected to the vehicle’s A seat belt has not been fastened or has been...
  • Page 15 Instruments Wait until the warning lamp goes off before Fixed. You must add at least 5 litres of AdBlue to its ® starting. The emissions control system has a fault. tank. When the warning lamp goes off, starting will The warning lamp should go off when the engine SCR emissions control system (BlueHDi) occur immediately if you press and hold: is started.
  • Page 16 Instruments Deactivation of the automatic functions Distance Alert/Active Safety Brake message "Parking brake fault". (with electric parking brake) The parking brake is faulty: manual and Flashing. Fixed. automatic functions may not be working. The system activates and brakes the The "automatic application" (on switching When stationary, to immobilise the vehicle: vehicle momentarily so as to reduce the speed of off the engine) and "automatic release"...
  • Page 17 Instruments Under-inflation Fixed. Carry out (3). The DSC/ASR system has a fault. Fixed. Lane positioning assist Carry out (3). The pressure in one or more tyres is too Fixed, accompanied by the Service low. Emergency brake malfunction (with warning lamp. Check the pressure of the tyres as soon as electric parking brake) The system has a fault.
  • Page 18 Instruments Automatic headlamp dipping The engine will not switch off at the next traffic The indicator lamp goes out upon reaching a stop, if the exterior temperature is: speed of approximately 3 mph (5 km/h) and Fixed. – below 0°C. lights up again when the vehicle stops moving.
  • Page 19 5 minutes for the reset to be Fixed, when the ignition is switched on. Contact a PEUGEOT dealer or a qualified registered. The next service is due in less than 620 workshop.
  • Page 20 Instruments Engine coolant temperature AdBlue range indicators ® Actions required related to a lack of AdBlue ® indicator (BlueHDi) The following warning lamps light up when the The Diesel BlueHDi engines are equipped with quantity of AdBlue is lower than the reserve ®...
  • Page 21 To be able to restart the engine, call on a Warning/ Action Remaining journeys, while the fault persists. PEUGEOT dealer or a qualified indicator range workshop. If it is a temporary fault, the alert lamps lit...
  • Page 22 Instruments are permanently displayed when the vehicle is 30 seconds after switching off the ignition. It is Optimal use of energy (internal switched on. displayed when the driver's door is opened, and combustion or electric). when the vehicle is locked or unlocked. The cursor is located in this zone With the ignition off, opening the driver's during electric driving phases and...
  • Page 23 If dashes instead of figures continue to be • Stop & Start time counter (petrol or Diesel). Displays information related to the current trip displayed when driving, contact a PEUGEOT • Percentage of the current journey travelled in (range, fuel consumption, average speed, etc.).
  • Page 24 Instruments Principles This function is only displayed at speeds above – Permanent display of the time and the exterior 19 mph (30 km/h). temperature (a blue warning lamp appears if ► Use the buttons arranged below the touch there is a risk of ice). screen for access to the menus, then press the Average fuel consumption –...
  • Page 25 Instruments Menus Activation, deactivation and settings for certain functions. The functions are organised in 2 tabs : "Driving functions" and "Vehicle settings". Telephone Refer to the “Audio equipment and telematics” section. Applications 1. Active driving mode Access to certain configurable equipment. 2.
  • Page 26 Instruments Remote features (Hybrid) 1. Average electrical consumption for the current internal combustion engine starts to ensure trip (kWh/100 km) and historical values: that the traction battery is recharged to the – Blue bar chart: directly consumed energy requested threshold - risk of downgraded supplied by the traction battery.
  • Page 27 Access Electronic key with procedures, please refer to the corresponding Selective unlocking (driver’s door, boot) is section. configured in the Driving/Vehicle touch remote control function screen menu. Integral key and built-in key, Complete unlocking The key built into the remote control can be ►...
  • Page 28 However, if the vehicle is fitted with pocket, due to the risk of unintentionally "Peugeot Adaptive LED technology" an alarm, it will be activated after 45 seconds. unlocking the vehicle. With the Full LED 3D rear lamps, the...
  • Page 29 Have the key codes memorised by a version, is confirmed by the flashing of the PEUGEOT dealer, to ensure that the keys sidelamps and/or daytime running lamps. in your possession are the only ones able to The door mirrors unfold.
  • Page 30 Make sure that no item or person could "Peugeot Adaptive LED technology" To preserve the battery charge in the prevent the correct closing of the With the Full LED 3D rear lamps, the electronic key and the vehicle's battery, windows and sunroof.
  • Page 31 ► For the rear doors, check that the child lock bearing the key code. is not on. The PEUGEOT dealer will be able to retrieve the Use these procedures in the following cases: Refer to the corresponding section. key code and the transponder code, enabling a –...
  • Page 32 Take them to an the remote control, Keyless Entry and Starting P, depress the brake pedal. approved disposal point. or the integral key to unlock the vehicle. If the fault persists after reinitialisation, contact a PEUGEOT dealer or a qualified workshop without delay.
  • Page 33 For all work on the alarm system, contact a PEUGEOT dealer or a qualified long press System which protects and provides a deterrent workshop. against theft and break-ins.
  • Page 34 Triggering of the alarm button indicates a malfunction of the system. – Transport on a ship or ferry. Have it checked by a PEUGEOT dealer or a This is indicated by sounding of the siren qualified workshop. Deactivating the interior volumetric...
  • Page 35 Access remote control or unlock the vehicle using the When the selective unlocking is The window automatically goes back up after “Keyless Entry and Starting” system. activated, the first press of the remote a few seconds and adjusts to seal the window control unlocking button permits unlocking of perfectly.
  • Page 36 Opening the tailgate experience difficulty opening or closing will remain locked. the tailgate, have it checked by a PEUGEOT In the event of a fault with the central dealer or a qualified workshop without delay, locking system, it is essential to...
  • Page 37 - risk of If using a towbar or bicycle carrier not serious injury! recommended by PEUGEOT, it is essential There are several ways of operating the tailgate: to deactivate the motorised operation of the A. Using the Keyless Entry and Starting system Anti-pinch tailgate.
  • Page 38 Access ► Briefly press the exterior tailgate control B, It is possible to interrupt the operation of with the electronic key on your person. the tailgate at any point. Pressing one of these controls again ► Briefly press the interior tailgate control C interrupts the movement that is underway.
  • Page 39 Access been detected, wait at least 2 seconds before The function may not work correctly with a to 1 metre between the low position and the repeating the movement. prosthetic leg. high position of the tailgate. Do not perform repetitive “kicking” In some circumstances, the tailgate may open or To delete the memorised position: movements.
  • Page 40 Access If the failure originates from the battery, it is the vehicle to prevent any risk of unwanted opens/closes completely when the switch is recommended to recharge it or change it with the opening. released. tailgate closed. Operating the switch again stops the movement In this situation, a significant force may be of the window.
  • Page 41 Access Precautions The rear electric windows can still be controlled Be particularly aware of children when using the driver's controls. operating the windows. Do not put your head or arms through the Be aware of passengers and/or other persons In the event of a serious impact, use of sunroof when driving - risk of serious present when closing the windows using the rear electric window controls is...
  • Page 42 Access Operation Reinitialisation ► To close the sunroof or the blind, use the part of the button located towards the front. When opening the sunroof fully, the movable Following reconnection of the battery or in the Operation of buttons glass moves to a partially open position, then event of a fault or jerky movement of the sunroof slides over the roof.
  • Page 43 Ease of use and comfort Driving position Adjust the head restraint so that its upper edge is Adjust the longitudinal position of the seat so that level with the top of your head. you are at a distance of at least 25 cm from the Adopting a good driving position helps improve Adjust the length of the seat cushion to support dashboard.
  • Page 44 Ease of use and comfort Front seats Removing a head restraint Height ► Pull the head restraint fully up. Before moving the seat backwards, ► Press the lug A to release the head restraint ensure that there is no person or object and remove it completely.
  • Page 45 Ease of use and comfort Electric lumbar adjustment Longitudinal ► Pull the handle forwards to release the cushion, then move the front part of the seat cushion forwards or backwards. Seat cushion angle The control allows independent adjustment of ► Push the control forwards or backwards to the depth and vertical position of the lumbar slide the seat.
  • Page 46 Ease of use and comfort Comfort functions You can interrupt the current movement by Do not use the function when the seat pressing button M, 1 or 2 or by using one of the is not occupied. seat adjustment controls. Reduce the heating intensity as soon as Memorising driving positions A stored position cannot be recalled while...
  • Page 47 Ease of use and comfort Steering wheel From the front seat: As a safety measure, the mirrors should ► Press this button; its green indicator be adjusted to reduce the "blind spots". adjustment lamp comes on. The objects that you see in the mirrors are The settings page is displayed on the touch in fact closer than they appear.
  • Page 48 Ease of use and comfort ► Return control A to its central position. With the engine running, on engaging reverse This system automatically and progressively gear, the mirror glasses tilt downwards. transitions between day and night modes, using Electric folding They return to their initial position: a sensor that measures the light entering from If the vehicle is so equipped, the mirrors can...
  • Page 49 Ease of use and comfort Removing a head restraint First steps: ► Lower the head restraints, or remove them ► First tilt the corresponding backrest. when carrying heavy loads. ► Pull the head restraint fully up. ► Lift up the rear armrest. ►...
  • Page 50 1. ► If the system does not produce cold air, ► Ensure that the outer seat belts were not switch it off and contact a PEUGEOT dealer trapped during the operation. or a qualified workshop.
  • Page 51 Ease of use and comfort If the interior temperature is very high Stop & Start after the vehicle has stood for a long The heating and air conditioning systems time in the sunshine, air the passenger only operate when the engine is running. compartment for a few moments.
  • Page 52 Ease of use and comfort "Air Quality System" (AQS) You can adjust the intensity of the 10. "AQS (Air Quality System)” function automatic Comfort programme by using the function (depending on version) "OPTIONS" button to select a profile: 11. Passenger compartment pre-conditioning Using a pollution sensor, this function –...
  • Page 53 Ease of use and comfort Air flow adjustment – increase the effectiveness of the demisting in It is available in the secondary page by pressing winter, above 3°C. the "OPTIONS” button. ► Press one of the buttons 2 (- or +) to ►...
  • Page 54 Ease of use and comfort On/Off Recirculating the interior air isolates the With Stop & Start, when demisting has passenger compartment from outside odours been activated, STOP mode is not and fumes and allows the desired passenger available. compartment temperature to be achieved more rapidly.
  • Page 55 Ease of use and comfort Ventilation as reducing the consumption of electrical current reduces fuel consumption. This system allows ventilation of the passenger compartment with exterior air to improve the temperature experienced on entering the vehicle Additional heating/ in summer. ventilation system Programming You can programme the heating or ventilation...
  • Page 56 The additional heating must always be Programming switched off while refuelling to avoid any risk of fire or explosion. (With PEUGEOT Connect Nav) ► Use a coin to unscrew the cap and replace In the Climate > OPTIONS menu: the battery.
  • Page 57 MyPeugeot application. With PEUGEOT Connect Radio, the Never drive with the glove box open programming can only be carried out using a when a passenger is at the front. It may smartphone, via the application.
  • Page 58 The connection of an electrical device For best results, use a cable made or approved ► Run the cable through the hole in the wall. not approved by PEUGEOT, such as a by the device manufacturer. ► Connect the cable to the USB socket...
  • Page 59 Ease of use and comfort Operating check – High fidelity woofer/mid-range speakers: The charger works with the engine running and Polyglass technology delivering balance and with the Stop & Start system in STOP mode. The state of the indicator lamp allows the precise sound.
  • Page 60 Ease of use and comfort Mats If the problem persists, have the system checked hinder the operation of the cruise control/ by a PEUGEOT dealer or a qualified workshop. speed limiter. The approved mats have two fasteners Fitting Front armrest located underneath the seat.
  • Page 61 120 W), lift the cover and plug in a suitable adaptor. Touch-sensitive reading lamps The connection of an electrical device not approved by PEUGEOT, such as a ► With the ignition on, press the corresponding USB charger, may adversely affect the reading lamp. operation of vehicle electrical systems,...
  • Page 62 9. Storage well / Tool box under the floor The stowing rings are designed to secure luggage using different types of retaining nets. These retaining nets are available as an option or as an accessory. For more information, contact a PEUGEOT dealer.
  • Page 63 Ease of use and comfort For information on installing the High When sharp deceleration occurs, objects load retaining net (SW), refer to the placed on the load space cover can turn corresponding section. into projectiles. Load space cover Load space cover (SW) (Hatchback) Access To remove part A:...
  • Page 64 Ease of use and comfort Removal ► Position the left-hand end of the load space – behind the front seats (row 1) when the rear cover roller in its location 1 behind the rear left seats are folded, seat. – behind the rear seats (row 2) when the load ►...
  • Page 65 ► Switch on the ignition. Hatchback The connection of an electrical device not approved by PEUGEOT, such as a USB charger, may adversely affect the operation of vehicle electrical systems, causing faults such as poor radio reception or interference with displays in the screens.
  • Page 66 Ease of use and comfort Storage well Boot lamp It comes on automatically when the boot is opened and goes off automatically when the boot is closed. The lighting time varies according to the circumstances: – when the ignition is off, approximately 10 minutes.
  • Page 67 68 mph (110 km/h). They only work if the dipped or main Switching on the lamps after "Peugeot Adaptive LED technology" beam headlamps are on. switching off the ignition With the Full LED 3D rear lamps,...
  • Page 68 ► Left or right: lower or raise the lighting control avoid dazzling oncoming drivers. Contact a stalk, beyond the point of resistance. PEUGEOT dealer or a qualified workshop. If you forget to cancel the direction indicators for more than 20 seconds, the volume of the audible signal will increase if the speed is above 50 mph (80 km/h).
  • Page 69 Contact a PEUGEOT dealer or a qualified an audible signal. workshop. Manual adjustment of the The system then places the headlamp beams in...
  • Page 70 Lighting and visibility Manual – when the vehicle is unlocked. traffic, and for observation of driving and – when a door is opened. vehicle regulations. – when a request to locate the vehicle is received from the remote control. The system becomes operational when They also come on with the welcome lighting the vehicle exceeds 16 mph (25 km/h).
  • Page 71 Lighting and visibility This indicator lamp goes out when the – vehicles at the top or bottom of a steep The speed of the vehicle must be less than 56 function is deactivated. slope, on winding roads, on crossroads. mph (90 km/h). This function is only available with the "Full LED"...
  • Page 72 Lighting and visibility The permanent display disappears upon Vision" mode selected) and the triggering of The image provided by the camera is displayed switching off the ignition or if the conditions are alerts are available. in shades of grey in the instrument panel; warm not met.
  • Page 73 ► Pull the stalk briefly towards you. met, accompanied by a message, indicates a Normal wiping (moderate rain) system malfunction. Front screenwash Contact a PEUGEOT dealer or a qualified Intermittent wiping (proportional to the ► Pull the wiper control stalk towards you and workshop. vehicle’s speed) hold.
  • Page 74 Lighting and visibility The front screenwash jets are integrated useful, in winter (ice, snow), to release the wiper in the tips of each arm. blades from the windscreen. Additional jets are installed below the Intermittent wipe To maintain the effectiveness of the flat midpoint of each arm.
  • Page 75 Lighting and visibility Changing a wiper blade ► Unclip the worn wiper blade closest to you Do not cover the rain/sunshine sensor. and remove it. When using an automatic car wash, ► Install the new wiper blade and clip it to the switch off the automatic wipers and the Removing/refitting at the front arm.
  • Page 76 Malfunction If a fault occurs with the automatic wipers, the wipers will operate in intermittent mode. Have them checked by a PEUGEOT dealer or a qualified workshop.
  • Page 77 They can operate with the ignition off. of which a PEUGEOT dealer is able to Automatic operation of provide. Installation of accessory radio hazard warning lamps...
  • Page 78 * In accordance with the general conditions of use of the service, available from dealers and subject to technological and technical limitations. ** In areas covered by ‘Peugeot Connect SOS’ and ‘Peugeot Connect Assistance’. The list of countries covered and telematic services provided is available from dealers or on the website for your country.
  • Page 79 Data contained in the system’s memory is not accessible from outside the system until * According to the geographic coverage of ‘Peugeot Connect SOS’, ‘Peugeot Connect Assistance’ and the official national language chosen by the owner of the vehicle. The list of countries covered and telematic services provided is available from dealers or on the website for your country.
  • Page 80 These systems enhance the vehicle’s stability After an impact, have these systems and handling during braking, and enable greater checked by a PEUGEOT dealer or a If you benefit from the Peugeot Connect control while cornering, particularly on poor or qualified workshop.
  • Page 81 Safety more wheels to return the vehicle to the desired Contact a PEUGEOT dealer or a qualified The electronic stability control system (ESC) path, within the limits of the laws of physics. workshop to have the systems checked. must not have any faults.
  • Page 82 The inertia reels are fitted with a device which When carrying heavy loads in the boot, the rear by a PEUGEOT dealer or a qualified automatically locks the strap in the event of a seat belts should be fastened.
  • Page 83 (1 to 5) comes on in red in the seat belt and positioned as low as possible on the pelvis. a textile cleaning product, sold by PEUGEOT front passenger airbag warning lamps display. The upper part must be positioned in the dealers.
  • Page 84 Safety Front airbags Impact detection zones of the seat belts equipped with a force limiting system. Electronic detectors record and analyse the front and side impacts sustained in the impact detection zones: – In the event of violent impact, the airbags deploy instantly and help better protect the occupants of the vehicle;...
  • Page 85 Malfunction All work on the airbag systems must only be performed by a PEUGEOT dealer or a This system protects the driver and front If this warning lamp comes on in the qualified workshop.
  • Page 86 Such work must only be done by a PEUGEOT incorporated in the system. The airbag centre part of the wheel. dealer or a qualified workshop.
  • Page 87 Safety Advice The active bonnet may not deploy in the event of Use a booster seat with backrest, equipped an impact. with a belt guide at shoulder level. An incorrectly installed child seat Child seats compromises the child's safety in the Additional protections event of an accident.
  • Page 88 Safety Child seat at the front ► Move the vehicle's front seat forward and The front passenger airbag must be straighten the backrest so that the legs of the deactivated before installing a rearward child in the "forward facing" child seat or the facing child seat.
  • Page 89 Safety Deactivating the front Group 0+: from birth to 13 kg passenger airbag "RÖMER Baby-Safe Plus" Installed in the "rearward facing" position. Passenger airbag OFF Groups 2 and 3: from 15 to 36 kg For your child’s safety, the front passenger airbag MUST be deactivated With the ignition off: when a "rearward facing"...
  • Page 90 Safety Groups 2 and 3: from 15 to 36 kg Groups 2 and 3: from 15 to 36 kg "GRACO Booster" The child is restrained by the seat belt. Only suitable for installation on the front passenger seat or on the rear side seats. Locations for child seats secured using the seat belt In accordance with European regulations, this table indicates the options for installing universally approved (a) child seats secured using the seat belt, based on the child’s weight and the seat position in the vehicle.
  • Page 91 Safety U: Seat position suitable for the installation of (g) Before installing the child seat in the centre a child seat secured using the seat belt and rear seat, store the right-hand side buckle in universally approved for "rearward facing" the space provided in the seat cushion.
  • Page 92 Safety An incorrectly installed child seat "RÖMER Baby-Safe Plus and its ISOFIX compromises the child's safety in the base" event of an accident. (size category: E) Strictly observe the fitting instructions provided in the user guide supplied with the Group 0+: from birth to 13 kg child seat.
  • Page 93 Safety "RÖMER Duo Plus ISOFIX" "RÖMER Duo Plus ISOFIX" (size category: B1) (size category: B1) Group 1: from 9 to 18 kg Group 1: from 9 to 18 kg Suitable for forward-facing installation only. Attached to rings A and ring B, referred to as TOP TETHER, using an upper strap.
  • Page 94 Safety In the case of universal and semi-universal ISOFIX child seats, the ISOFIX size category, as determined by a letter from A to G, is indicated on the child seat next to the i-Size logo. Weight of the child / indicative age Under 10 kg Under 10 kg From 9 to 18 kg...
  • Page 95 Safety (c) Remove the head restraints. i-Size child seats i-Size child seats have two latches that engage on the two rings A. These i-Size child seats also have: – either an upper strap that is attached to ring B. – or a support leg that rests on the vehicle floor, compatible with the approved i-Size seat position. Their role is to prevent the child seat from tipping forward in the event of a collision.
  • Page 96 Safety Locking / Unlocking Do not confuse the child lock control, i-U : Suitable for i-Size restraint systems in the which is red, with the back-up locking "Universal" category, "forward facing" and control, which is black. "rearward facing". i-UF: Only suitable for i-Size restraint systems Electric child lock in the "Universal"...
  • Page 97 Safety This system is independent and in no circumstances does it take the place of the central locking control. Check the status of the child lock each time you switch on the ignition. Always keep the electronic key with you when leaving the vehicle, even for a short time.
  • Page 98 If in doubt about the state of your vehicle, the parking brake and put the gearbox into require close attention (such as adjustments). contact a PEUGEOT dealer or a qualified neutral or position N or P (depending on the ► During long trips, take a break every two workshop.
  • Page 99 ► Check the electrical signalling on the trailer Anti-theft protection and the headlamp beam height of your vehicle. If a genuine PEUGEOT towing device is Electronic immobiliser used, the rear parking sensors will be deactivated automatically to avoid the audible The keys include an electronic engine signal.
  • Page 100 Driving For Diesel engines, when the temperature is activation of the hybrid system (confirmed by an If the vehicle is not immobilised, the below zero and/or the engine is cold, starting will audible signal). engine will not switch off. only occur once the preheating warning lamp is By default, the system starts in ELECTRIC off.
  • Page 101 ► With an automatic gearbox, select mode P, In the event of a fault with the electronic key, control lever; contact a PEUGEOT dealer or a qualified then fully depress the brake pedal. ► to release it, briefly push the control lever workshop.
  • Page 102 12%. clutch pedal. chocks against one of the wheels. With an automatic gearbox Contact a PEUGEOT dealer or a qualified Manual operation ► Press the brake pedal. workshop. ► Select mode D, M or R.
  • Page 103 Driving It is not applied automatically if the ► Switch off the ignition. ► Use the control lever to apply the parking engine stalls or enters STOP mode brake, if it is released. With an automatic gearbox, mode P is of Stop &...
  • Page 104 Driving Engaging reverse gear Gearbox selector positions If emergency braking malfunctions, the message "Parking brake control faulty" will be displayed P. Park on the instrument panel. For parking the vehicle: the front wheels are If the ABS and DSC systems blocked.
  • Page 105 Driving Push selector ► Pull the "+" or "-" paddle towards you and release to shift up or down a gear, respectively. ► Move the selector by pressing it forwards Information displayed on (N or R) or rearwards (N or D) once or twice, passing the point of resistance if necessary.
  • Page 106 Driving in order to change mode, an alert message is ► Depress the brake pedal, then press the sound. It will stop when you close the driver's displayed in the instrument panel. Unlock button. door again. Only appropriate attempted changes of mode ►...
  • Page 107 R. and regenerative braking function. Visit a PEUGEOT dealer or a qualified workshop. Then, from D or R: With the exception of manual mode and Do not drive faster than 62 mph (100 km/h), ►...
  • Page 108 Driving Hill start assist Push selector N: neutral. D1 to D8: automatic forward gear. This system keeps your vehicle briefly stationary B1 to B8: automatic forward gear with (for approximately 2 seconds) when making a hill regenerative braking function activated. start, while you transfer your foot from the brake In all-electric driving, the gear engaged is not pedal to the accelerator pedal.
  • Page 109 Operation Malfunction These warning lamps come on in the event of a malfunction. Contact a PEUGEOT dealer or a qualified workshop to have the system checked. Active Suspension Control This suspension adapts itself to the following parameters: state and profile of the road, load...
  • Page 110 Driving COMFORT unavailable” is displayed in the instrument panel. In HYBRID mode, it is possible to drive in The vehicle automatically changes to HYBRID 100% electric mode if the battery charge level (with Active Suspension Control) mode. is sufficient and acceleration requirements are Allows more comfortable driving and softer The lighting of a blue LED under the interior moderate.
  • Page 111 Driving Operation queues, etc.). The engine restarts automatically Function deactivated or malfunction. - START mode - as soon as the driver wishes to Depending on the driving situation and the move off again. vehicle's equipment, the system may advise Opening the bonnet Primarily designed for urban use, the function skipping one or more gears.
  • Page 112 All work concerning the battery must be ignition is switched on. • With the selector in position P and the brake carried out only by a PEUGEOT dealer or a pedal depressed: with the selector at R, N, qualified workshop.
  • Page 113 ► In the event of a puncture, use the function is no longer performed. Checking tyre pressures temporary puncture repair kit or the spare wheel Have the system checked by a PEUGEOT This check should be done when the (depending on equipment). dealer or a qualified workshop.
  • Page 114 Radar In the event of a windscreen replacement, The operation of the radar as well as the contact a PEUGEOT dealer or a qualified Driving and manoeuvring aids cannot, in associated functions may be impaired through workshop to recalibrate the camera;...
  • Page 115 The sensors do not systematically detect authorised locally. Sign detected Suggested speed obstacles that are too low (pavements, studs) In case of doubt, contact a PEUGEOT dealer (calculated) or too thin (trees, posts, wire fences). or a qualified workshop. Entry into an Without PEUGEOT Certain obstacles located in the sensors’...
  • Page 116 Driving For the system to operate correctly when Qualifier plate Display of the Qualifier plate Display of the you change country, the units for speed in detected speed associated detected speed associated the instrument panel must be those for the with the qualifier with the qualifier country you are driving in.
  • Page 117 Driving Information displayed on Recommendation the instrument panel In the case of suggested maximum speeds, the first time the vehicle exceeds the suggested speed by more than 3 mph (5 km/h) (e.g. 59 In addition to Speed Limit Recognition and mph (95 km/h)), the speed is displayed flashing Recommendation, the driver can select the for 10 seconds.
  • Page 118 Driving Depending on the road conditions, several The actual road signs always take priority 2. Memorise the speed setting speeds may be displayed. over the display from the system. ► Press button 2once to save the suggested The signs must comply with the Vienna Information displayed on the speed value.
  • Page 119 Driving Steering mounted control Information displayed on ► If the speed setting is suitable (last speed setting programmed in the system), press the instrument panel button 4 to switch the speed limiter on. ► Pressing button 4 again temporarily interrupts the function (pause).
  • Page 120 When the limit speed is exceeded but this is not Have it checked by a PEUGEOT dealer or a flashing). due to action by the driver (in case of a steep qualified workshop.
  • Page 121 Driving Steering mounted control Information displayed on – On slippery or flooded roads. – In poor weather conditions. the instrument panel – Driving on a speed circuit. – Driving on a rolling road. – When using snow chains, non-slip covers or studded tyres.
  • Page 122 ► Press the touch screen button for the desired Operation of the cruise control can also Have it checked by a PEUGEOT dealer or a speed setting. be paused temporarily: qualified workshop. The selection screen closes after a few –...
  • Page 123 Driving Changing a speed setting This system is especially suitable for driving on With the Stop & Go function, the system motorways and main roads. manages the braking until the vehicle comes to a Speed settings can be activated, For more information on Adaptive Cruise complete stop and the restarting of the vehicle.
  • Page 124 Driving Steering mounted control Switching on cruise control and setting • when the speed of the engine goes below the speed 1100 rpm with a manual gearbox. • by triggering of the ESC system. With a manual gearbox, your speed must be With an EAT6 gearbox, following braking that between 19 and 112 mph (30 and 180 km/h).
  • Page 125 Driving Information displayed on Messages and alerts Changing the programmed speed setting with the Speed Limit Recognition and the instrument panel To benefit from the following information on the Recommendation function instrument panel, select the "DRIVING" display The following information can be seen on the ►...
  • Page 126 Driving The system has brought the vehicle to a – Pedestrians, some cyclists, animals. – Excessively sharp deceleration by the vehicle complete stop and is holding it immobilised: – Stationary vehicles (traffic jam, breakdown, in front of you. cruise control is paused. etc.).
  • Page 127 Driving Active Lane Keeping Activation/Deactivation The system status is saved when the ignition is switched off. Assist Cruise control Refer to the General recommendations on the use of driving and manoeuvring aids. The driver must hold the steering wheel properly. When cruise control is activated, the symbol is displayed in green: by small steering actions, the system directs the vehicle and keeps it in the...
  • Page 128 Driving In response to action by the driver: control being paused will also cause the the steering wheel, you must reactivate it by suspension system to be paused. pressing the button again. – Activation of the direction indicators. Automatic pause If the system detects that the driver is not –...
  • Page 129 Driving Button indicator lamp Cruise control Symbols Display Comments thumbwheel Green CRUISE Drive Assist Plus paused. (grey) (grey) Green CRUISE Drive Assist Plus active; not all conditions required for lane positioning assist have been met. (green)/(grey) (grey) Green OFF or LIMIT Cruise control not active;...

  • Page 130: Active Safety Brake With Distance Alert And Intelligent Emergency Braking Assistance

    Driving Operating limits – Driving on racing circuits. below 0.5 m tall and objects on the road are – Driving on a rolling road. not necessarily detected. The Lane Keeping Assist system may This system is comprised of three functions: issue an alert when the vehicle is Malfunction –...
  • Page 131 ESC system in working order. automatically stops operating. Contact a indicating that the vehicle in front is very ASR system activated. PEUGEOT dealer or a qualified workshop to close. Seat belts fastened for all passengers. have the system checked. The message "Vehicle close" is displayed.

  • Page 132: Distraction Detection

    (10 km/h) (versions with camera and radar) or message and an audible signal. between 6 mph and 53 mph (10 km/h and 85 Contact a PEUGEOT dealer or a qualified km/h) (versions with camera alone) when a workshop to have the system checked.

  • Page 133: Active Lane Keeping Assistance

    Driving These systems are in no way designed As soon as the speed of the vehicle driving: take a break", accompanied by a more to keep the driver awake or to prevent drops below 40 mph (65 km/h), the pronounced audible signal. the driver from falling asleep at the wheel.
  • Page 134 Driving Operation While the direction indicators are on and for a few seconds after switching them off, the Once the system identifies a risk of the vehicle system considers that any change of trajectory is involuntarily crossing one of the lane markings intentional and no correction is triggered during detected or a lane limit (e.g.
  • Page 135 Driving Function status Indicator lamp Display and/or associated Comments message Function deactivated. (grey) System active, conditions not met: – speed below 43 mph (70 km/h), – no lane marking recognised, – ASR/DSC systems deactivated or operation of ESC (grey) system triggered, –...
  • Page 136 Driving Function status Indicator lamp Display and/or associated Comments message – If, while correcting the trajectory, the system detects that the driver has not held the steering wheel for a few seconds, it interrupts the correction and returns control to the driver.

  • Page 137: Active Blind Spot Monitoring System

    – When you overtake a vehicle with a speed that appears in the door mirror on the side in Have the system checked by a PEUGEOT difference of less than 6 mph (10 km/h). question: dealer or a qualified workshop.

  • Page 138: Parking Sensors

    If the event of a malfunction, this warning Operating limits lamp comes on in the instrument panel, accompanied by the display of a message. Contact a PEUGEOT dealer or a qualified workshop to have the system checked. The system may suffer temporary interference in certain weather conditions (rain, hail, etc.).
  • Page 139 Adjusting the audible signal vehicle is still below 6 mph (10 km/h). With PEUGEOT Connect Radio or Front parking sensor operation is suspended if PEUGEOT Connect Nav, pressing the vehicle stops for more than three seconds in...

  • Page 140: Visiopark 1 - Visiopark 2

    Driving Side parking sensors Contact a PEUGEOT dealer or a qualified workshop to have the system checked. Visiopark 1 - Visiopark 2 Refer to the General recommendations on the use of driving and manoeuvring aids. With the engine running, these systems allow The rear parking sensors system will be views of your vehicle’s close surroundings to...
  • Page 141 Driving – 180° view. An image from above your vehicle in its close To activate the camera, located near the number – Zoom view. surroundings is reconstructed (represented plate lamps, engage reverse and keep the speed AUTO mode is activated by default. between the brackets) in real time and as the of the vehicle below 6 mph (10 km/h).
  • Page 142 Driving AUTO mode 180° view The red line 2 represents a distance of 30 cm from the rear bumper; the two blue lines 3 and 4 represent 1 m and 2 m, respectively. This view is available with AUTO mode or in the view selection menu.
  • Page 143 Driving Standard view offering views from the rear of the vehicle (rear The rear vision views are similar to those for the vision) when reverse gear is engaged and views Visiopark 1. from the front of the vehicle (front vision) when For more information on the Visiopark 1, refer to the gearbox is in neutral or a gear is engaged.

  • Page 144: Park Assist

    Driving Zoom view AUTO mode see the approach of vehicles, pedestrians and cyclists. This view is not recommended for carrying out a complete manoeuvre. It consists of 3 areas: left A, centre B and right This view is available only from the view selection menu.
  • Page 145 Driving Selecting the type of The parking space search stops over this limit. The function automatically deactivates once the manoeuvre vehicle speed exceeds 31 mph (50 km/h). For ''parallel'' parking, the space must at a minimum be equal to the length of your vehicle plus 0.60 m.
  • Page 146 Driving Preparing for the The manoeuvring status is indicated by these The manoeuvre can be permanently interrupted symbols: at any time, either by the driver or automatically manoeuvre Manoeuvre in progress (green). by the system. ► Move very slowly until the request to stop Interruption by the driver: the vehicle is displayed: "Stop the vehicle“, Manoeuvre cancelled or finished (red)

  • Page 147: Full Park Assist

    In the event of a malfunction, have the system – The system may suggest an inappropriate – If one of the cameras is faulty. checked by a PEUGEOT dealer or a qualified parking space (parking prohibited, work in workshop. progress with damaged road surface, location In the event of a power steering alongside a ditch, etc.).
  • Page 148 Driving parking space and then operates the vehicle, to the performance limits inherent to the parking it with no need for driver intervention. It system. also allows you to drive out of a "parallel parking" The manoeuvre remains the responsibility space automatically.
  • Page 149 Driving For "parallel" parking, the space must at "Manoeuvre under way", accompanied by an Throughout the whole manoeuvre, least equal to the length of your vehicle audible signal. indicated by the green "AUTO" symbol, plus 1 m. Visiopark 1 or Visiopark 2 and the parking the driver must hold the selector button down.
  • Page 150 Driving Resuming the manoeuvre after resolving the – System malfunction during the manoeuvre. The gearbox automatically changes to mode conditions for suspending it: Abandoning the manoeuvre immediately P if no action is taken by the driver within 30 ► Release all controls (brake pedal, function triggers the vehicle’s brakes and automatically secondss.
  • Page 151 – If one of the cameras is faulty. deactivated. – If the brake lamps are not working. Contact a PEUGEOT dealer or a qualified workshop. Do not use the function if the vehicle has In the event of a power steering...
  • Page 152 PEUGEOT & TOTAL PARTNERS IN PERFORMANCE! For over 20 years, the PEUGEOT TOTAL partnership has set new performance standards in achieving success in the toughest conditions, with victories in the Le Mans 24 Hours, the World Rally Championship and the Dakar Rally.

  • Page 153: Practical Information

    Practical information Compatibility of fuels fuels could prevent the engine from operating and audible signal are repeated with increasing correctly. In these temperature conditions, use frequency as the fuel level drops towards 0. winter-type Diesel fuel and keep the fuel tank You must refuel as soon as possible to avoid more than 50 % full.

  • Page 154: Misfuel Prevention (Diesel)

    Misfuel prevention (Diesel) Before travelling abroad, it is advisable to check with a PEUGEOT dealer if the vehicle (Depending on country of sale.) is suitable for the distribution equipment of the This mechanical device prevents filling the tank countries visited.
  • Page 155 Stop as soon as it is safe to do so and switch off the ignition. Traction battery Contact a PEUGEOT dealer or a qualified workshop without delay. The Li-ion (Lithium-ion) traction battery stores the electrical energy of the vehicle. It is located under the rear seats.
  • Page 156 In case of impact, even light, against the cable. Status of light Meaning charging flap, do not use it. Contact a PEUGEOT dealer or a qualified guides Do not remove or modify the charging workshop to obtain the appropriate charging connector - risk of fire!
  • Page 157 – If the circuit breaker has tripped, contact a In the event of damage, do not use it and professional to check that your electrical system contact a PEUGEOT dealer or a qualified is suitable and carry out any necessary repairs. workshop to replace it.

  • Page 158: Charging The Traction Battery (Hybrid)

    Incorrect use of this charging cable may Do not expose to flammable vapours. result in fire, property damage and serious 14. Only use this charging cable with PEUGEOT Hybrid vehicles have been developed in injury or death by electrocution! vehicles.
  • Page 159 Practical information ► Have a professional check that the ► Open the charging flap by pressing the push If this is not the case, charging has not electrical system to be used complies with button and make sure that there are no foreign started;...

  • Page 160: Towing Device

    ► In the Hybrid touch screen menu, ► If the vehicle is unlocked, lock it and then If not fitted by a PEUGEOT dealer, they must select the Charge tab. unlock it. still be fitted in accordance with the vehicle ►...

  • Page 161: Towing Device With Retractable Ball Joint

    Practical information – Deactivate this function in advance in your The towball hangs, hooked onto its shaft. vehicle's configuration menu. As soon as you release the handle, it is engaged – Or remove the electronic key from the automatically in its storage case. recognition zone, with the tailgate closed.

  • Page 162: Roof Bars

    Storage position You must see a PEUGEOT dealer to obtain these roof bars and their specific fixings. When the towing system is not in use, it Observe the instructions on fitting and use is recommended to fold the towball away.

  • Page 163: Snow Chains

    Roof box Take account of the legislation specific to Consult a PEUGEOT dealer or a each country on the use of snow chains Maximum load distributed over the qualified workshop to obtain the compatible and the maximum authorised speed.

  • Page 164: Energy Economy Mode

    For more information on snow chains, contact a A flat battery prevents the engine from This system manages the duration of use of PEUGEOT dealer or a qualified workshop. starting. certain functions, in order to conserve a sufficient For more information on the 12 V battery, level of charge in the battery with the ignition off.

  • Page 165: Engine Compartment

    Practical information Opening risk of injury resulting from an automatic Because of the presence of electrical change to START mode. equipment under the bonnet, it is strongly recommended that exposure to water (rain, washing, etc.) be limited. Engine compartment Hybrid vehicles The engine shown here is an example for Before any work is carried out under the illustrative purposes only.

  • Page 166: Checking Levels

    Check all of the following levels regularly in Empty used oil into the containers reserved accordance with the manufacturer's service for this purpose at a PEUGEOT dealer or a schedule. Top them up if required, unless qualified workshop. otherwise indicated.
  • Page 167 Do not start the engine if the level is: allow the pressure to drop. – above mark A: contact a PEUGEOT dealer or Brake fluid Once the pressure has dropped, remove the cap a qualified workshop.

  • Page 168: Checks

    Practical information Diesel fuel additive (Diesel Passenger compartment Otherwise, have them checked by a PEUGEOT dealer or a qualified workshop. with particle filter) filter Only use products recommended by On reaching the minimum level in the Depending on the environment and the...
  • Page 169 The pressures indicated on the tyre pressure road-holding and braking performance. checked by a PEUGEOT dealer or a qualified label are valid for "cold" tyres. If you have driven workshop. for more than 10 minutes or more than 6 miles...
  • Page 170 (DPF) for the treatment of exhaust gases. malfunction, it is essential to visit a PEUGEOT dealer or a qualified workshop. PEUGEOT dealer or a qualified workshop. SCR System After 680 miles (1,100 km), a device is...
  • Page 171 Practical information You can also visit a service station vapours have an irritant effect on mucous electronic key into the passenger equipped with AdBlue pumps specially membranes (eyes, nose and throat). compartment. ® designed for passenger vehicles. Switch on the ignition, then wait for 10 Store AdBlue out of the reach of ®...

  • Page 172: Free-Wheeling

    Practical information Reverting to normal operation If the AdBlue tank is completely empty the engine will start, requiring you to restart ® – which is confirmed by the message the procedure. ► While depressing the brake pedal, start the "Top up AdBlue: Starting impossible" – it is engine.
  • Page 173 These substances can be highly corrosive. Never use an abrasive sponge to clean Do not clean leather using unsuitable Contact a PEUGEOT dealer or a qualified stubborn stains. Risk of scratching the cleaning agents such as solvents, workshop if you require advice on removing paintwork! detergents, petrol or pure alcohol.

  • Page 174: In The Event Of A Breakdown

    In the event of a breakdown Warning triangle Assembling and placing the For more information on Refuelling and on Misfuel prevention (Diesel), please triangle As a safety precaution, before leaving your refer to the corresponding section. vehicle to set up and install the triangle, switch on the hazard warning lamps and put on your For non-BlueHDi versions, the fuel system high visibility vest.

  • Page 175: Tool Kit

    In the event of a breakdown Non-BlueHDi engines ► Attach the floor hook to the upper boot seal. ► Open the bonnet and then, if necessary, With temporary puncture repair kit unclip the cover to access the priming pump. ► Loosen the degassing bolt. ►...

  • Page 176: Temporary Puncture Repair Kit

    With temporary puncture repair kit If the vehicle does not have its original jack, contact a PEUGEOT dealer or a qualified workshop to obtain the one that was intended by the manufacturer. The jack meets European standards, as defined in the Machinery Directive 2006/42/ The jack does not require any maintenance.
  • Page 177 In the event of a breakdown Made up of a compressor and a sealant cartridge, it allows you to carry out a temporary repair of the tyre so that you can drive to the nearest garage. It is designed to repair most punctures located on the tyre tread.
  • Page 178 After use, do not discard the bottle in ► Switch on the ignition. injecting sealant, to check and, if necessary, standard waste, take it to a PEUGEOT dealer adjust the tyre pressures. or an authorised waste disposal site. ► Remove the valve cap from the tyre and keep Do not forget to obtain a new bottle of it in a clean place.

  • Page 179: Spare Wheel

    If after 7 minutes the pressure of 2 bar is not reached, the tyre is damaged; contact a PEUGEOT dealer or a qualified workshop for assistance. ► Once the correct pressure is reached, put the Hatchback switch in position "O".
  • Page 180 In the event of a breakdown The occupants must get out of the vehicle and wait where they are safe. If necessary, place a chock under the wheel diagonally opposite the wheel to be changed. Never go underneath a vehicle raised using a jack;...
  • Page 181 In the event of a breakdown Fitting a wheel ► Fit security socket 2 on wheelbrace 5 to ► Raise the vehicle until there is sufficient slacken the security bolt. space between the wheel and the ground to ► Slacken the other bolts using the admit the spare (not punctured) wheel easily.

  • Page 182: Changing A Bulb

    Changing a bulb must only be done with Visit a PEUGEOT dealer or a qualified the ignition off and after the headlamp / workshop as soon as possible to have...
  • Page 183 – Third brake lamp. – Number plate lamps. For the replacement of this type of bulb, 1. Daytime running lamps / Sidelamps (LEDs) you must contact a PEUGEOT dealer or 2. Main beam headlamps (H7) a qualified workshop. 3. Dipped beam headlamps (H7) Do not touch the "Full LED"...
  • Page 184 In the event of a breakdown Main beam headlamps Halogen bulbs (Hx) ► Pull the connector rearwards to disconnect it. To ensure good quality lighting, check ► Push the spring forwards then to the right to that the bulb is correctly positioned in its release the bulb.

  • Page 185: Changing A Fuse

    In the event of a breakdown Model with adaptive 3D Full LED Reversing lamps lamps ► Unclip the cover by pulling at the top left, then right. Foglamps ► Remove the cover completely. These bulbs are replaced from outside the rear ►...
  • Page 186 To access the fuses, follow the same procedure designed to operate with standard or optional The fuse allocation tables and the as described for accessing the fuse replacement equipment. corresponding diagrams are available tools. from a PEUGEOT dealer or from a qualified workshop. Fuse tables Box 1...
  • Page 187 In the event of a breakdown Fuse N° Rating (A) Functions 10 A "Electrochrome" mirrors. Adaptive 3D rear lamps. 15 A Horn. 20 A Rear screenwash pump (SW). 20 A Windscreen wash pump. 10 A Rear USB ports. 20 A Rear wiper (SW).
  • Page 188 In the event of a breakdown Fuse N° Rating (A) Functions 15 A Lighter / Front 12 V socket. Box 2 Fuse N° Rating (A) Functions Heated door mirrors. 40 A Front one-touch windows. 15 A Driver’s door control panel - Memorisation of electric seats. 40 A Rear one-touch windows.
  • Page 189 In the event of a breakdown Fuse N° Rating (A) Functions 30 A Panoramic sunroof. 30 A Panoramic sunroof blind. 30 A Electric seats. 30 A Motorised tailgate unit. 25 A Additional heating. Trailer interface unit Fuse N° Rating (A) Functions 20 A Brake lamps - Reversing lamps (trailer).
  • Page 190 In the event of a breakdown Accessing the fuses ► Release the two latches A. ► Remove the cover. ► Replace the fuse. ► When you have finished, close the cover carefully, then engage the two latches A to ensure that the fusebox is properly sealed. Fuse tables Fuse N°...

  • Page 191: 12 V Battery

    In the event of a breakdown Fuse N° Rating (A) Functions 10 A Left-hand main beam headlamp. 40 A Trailer interface unit. 25 A Right-hand dipped beam headlamp - Right-hand reversing lamps - Left-hand foglamps - Rear left-hand sidelamps - Third brake lamp. 40 A Windscreen wipers.
  • Page 192 ► Connect the other end of the green or black several weeks. each other. cable to the earth point C. Contact a PEUGEOT dealer or a qualified Switch off all electricity-consuming equipment ► Start the engine on the assisting vehicle and workshop.
  • Page 193 Never try to charge a frozen battery - risk of explosion! If the battery has frozen, have it checked by a PEUGEOT dealer or by a qualified workshop who will verify that the internal components have not been damaged and that the case ►...

  • Page 194: Accessory Batteries (Hybrid)

    The hybrid system has two accessory batteries: If minor problems nevertheless persist following one at the front and one at the rear of the this operation, contact a PEUGEOT dealer or a vehicle. qualified workshop. Referring to the relevant section, reset certain...
  • Page 195 It is not necessary to disconnect the of explosion! battery. If the battery has frozen, have it checked by a PEUGEOT dealer or by a qualified workshop ► Switch off the ignition. ► Lift the boot floor. who will verify that the internal components ►...

  • Page 196: Towing The Vehicle

    – Broken down on a motorway or main road. Reconnection If minor problems nevertheless persist following – Not possible to put the gearbox into neutral, this operation, contact a PEUGEOT dealer or a unlock the steering, or release the parking Never reverse the order of the qualified workshop.
  • Page 197 In the event of a breakdown Hybrid vehicles Before any intervention, with the ignition on, depress the brake pedal and select mode N, then switch off the hybrid system (READY indicator lamp off). Always call on professionals for recovery of the vehicle on a flatbed lorry or trailer. Use the towing eye only to free the vehicle where it is stuck, or to secure it for recovery on a flatbed lorry or trailer.
  • Page 198 In the event of a breakdown Access to the tools Towing your vehicle ► Unlock the steering and release the parking brake. To access the front screw thread: ► Switch on the hazard warning lamps on both vehicles. ► Move off gently, drive slowly and only for a short distance.

  • Page 199: Technical Data

    European legislation a speed of 62 mph (100 km/h) (observe the (Directive 1999/99/EC). local legislation in force). For more information, contact a PEUGEOT dealer or a qualified workshop. Weights and towed loads The weights and towed loads relating to the vehicle are indicated on the registration document, as well as in sales brochures.

  • Page 200: Petrol Engines

    Technical data Engines and towed loads - Petrol Engines THP 150 THP 165 PureTech 180 S&S EAT8 PureTech 225 S&S EAT8 EAT6 EAT6 Gearboxes Automatic Automatic Automatic 8-speed Automatic 8-speed 6-speed 6-speed Codes EP6FDTMD EP6FDTM EP6FADTXD ATN8 STT EP6FADTX ATN8 STT AT6III AT6III Model codes...

  • Page 201: Diesel Engines

    Technical data Engines and towed loads – Diesel BlueHDi Engines BlueHDi 130 S&S BVM6 BlueHDi 130 S&S EAT8 Gearboxes Manual 6-speed Automatic 8-speed Codes DV5RC ML6C STT DV5RC ATN8 STT Model codes YHZJ YHZR Hatchback: FB... SW: FC... Body styles Hatchback Hatchback Cubic capacity (cc)
  • Page 202 Technical data Engines BlueHDi 160 S&S EAT8 BlueHDi 180 S&S EAT8 Gearboxes Automatic 8-speed Automatic 8-speed Codes DW10FCC AMN8 STT DW10FC AMN8 STT Model codes EHYR EHZR Hatchback: FH... SW: FJ... Body styles Hatchback Hatchback Fuel Diesel Diesel Braked trailer (within the GTW limit) (kg) 1,800 1,800 1,800...
  • Page 203 Technical data Engines and towed loads - Diesel Engines HDi 180 EAT8 Gearboxes Automatic 8-speed Codes DW10FC AMN8 Model codes EHZN Hatchback: FH... SW: FJ... Body styles Hatchback Cubic capacity (cc) 1,997 Max. power: EC standard (kW) Fuel Diesel Braked trailer (within the GTW limit) (kg) on a 10% or 12% gradient 1,800* 1,800*...

  • Page 204: Hybrid Engine

    Technical data Engine and towed loads - Hybrid HYBRID 225 e-EAT8 Code EP6FADTXHPD Model codes 5GQU/C Hatchback: F3... SW: F4... Body styles Hatchback Braked trailer (within the GTW limit) (kg) 1,330 1 340 on a 10% or 12% gradient Unbraked trailer (kg) Maximum authorised nose weight (kg) Petrol engine PureTech 180...

  • Page 205: Dimensions

    Technical data Dimensions (mm) These dimensions have been measured on an unladen vehicle. Hatchback...

  • Page 206: Identification Markings

    Technical data Identification markings – European whole vehicle type approval number. Various visible markings for the identification and – Vehicle identification number (VIN). research of your vehicle. – Gross vehicle weight (GVW). – Gross train weight (GTW). – Maximum weight on the front axle. –...

  • Page 207: Peugeot Connect Radio

    PEUGEOT Connect Radio PEUGEOT Connect applications interrupt their display while the At all times it is possible to display the rolling vehicle is moving). menus by pressing the screen briefly with three Radio – Changing the system settings and fingers.

  • Page 208: Steering Mounted Controls

    PEUGEOT Connect Radio Steering mounted controls Steering mounted controls - – FM/DAB/AM radio stations (depending on equipment). Type 2 – Telephone connected via Bluetooth and Steering mounted controls - Bluetooth multimedia broadcast (streaming). Type 1 – USB Memory stick. – Media player connected via the auxiliary Voice commands: socket (depending on equipment).

  • Page 209: Menus

    PEUGEOT Connect Radio Radio Media Settings Short press: confirm a selection; if nothing selected, access to presets. Radio: display the list of stations. Media: display the list of tracks. Radio (press and hold): update the list of stations received. Menus Applications Select an audio source or radio station.

  • Page 210: Applications

    PEUGEOT Connect Radio Applications Navigation Press this button to search and select a recipient. Select the "Quick messages” tab. Viewing photos Insert a USB memory stick in the USB port. Press this button to select the display settings for messages.
  • Page 211 PEUGEOT Connect Radio Enter the FM and AM waveband values Press the "OPTIONS" button to access the using the virtual keypad. Select a radio station or frequency. secondary page. Press "OK" to confirm. Press "Preset". Activate/deactivate "News". Make a long press on one of the buttons to preset the station.

  • Page 212: Dab (Digital Audio Broadcasting) Radio

    PEUGEOT Connect Radio DAB (Digital Audio Select the "Tone", "Balance", "Sound", Press in the shaded area to confirm. "Voice" or "Ringtones" tab to configure Broadcasting) radio the sound settings. If "FM-DAB Follow-up" is activated, there Press the back arrow to confirm.
  • Page 213 PEUGEOT Connect Radio Information and advice Playlists are updated whenever the ignition If play does not start automatically, it may be is switched off or a USB memory stick is necessary to start the audio playback from the The system supports USB mass storage connected.

  • Page 214: Telephone

    PEUGEOT Connect Radio Telephone MirrorLink smartphone Press "MirrorLink " to start the application in the system. connection USB sockets Once the connection is established, a page is displayed, showing the applications already Depending on equipment, for more information The "MirrorLink "...
  • Page 215 PEUGEOT Connect Radio Pairing a Bluetooth ® Press "CarPlay" to display the CarPlay Press "Android Auto" to start the ® interface. application in the system. telephone Depending on the smartphone, it may be On connecting the USB cable, the necessary to activate the "Android Auto"...
  • Page 216 PEUGEOT Connect Radio Procedure from the system Visit the Brand's website for more information Press on the name of the telephone (compatibility, additional help, etc.). selected in the list to disconnect it. Press Telephone to display the main Press again to connect it.

  • Page 217: Settings

    PEUGEOT Connect Radio Calling a new number It is always possible to make a call Press the back arrow again to confirm. directly from the telephone; as a safety Press Telephone to display the main measure, first park the vehicle.
  • Page 218 PEUGEOT Connect Radio Press the "System info" tab to display the Press the back arrow to confirm. Press the back arrow to save the settings. versions of the various modules installed in the system. Selecting the language The system may not automatically Press the "Privacy"...

  • Page 219: Frequently Asked Questions

    PEUGEOT Connect Radio Frequently asked ► Press the round arrow on the "List" tab on the The Bluetooth profile does not allow the transfer "Radio" page. of this information. questions Some radio stations send other information Telephone in place of their name (the title of the song for The following information groups together the example).
  • Page 220 PEUGEOT Connect Radio Some telephones offer display options. When the engine is off, the system switches Depending on the settings chosen, contacts can off after several minutes of use. be transferred in a specific order. When the engine is switched off, the system's ►...

  • Page 221: Peugeot Connect Nav

    PEUGEOT Connect Nav PEUGEOT Connect Nav applications interrupt their display while the Use the menu buttons on either side of or below vehicle is moving). the touch screen for access to the menus, then – Watching a video (the video stops when the press the virtual buttons in the touch screen.

  • Page 222: Steering Mounted Controls

    PEUGEOT Connect Nav Audio source selection (depending on enter standby mode (with the screen and Telephone (long press): reject an incoming call, equipment): sound off) for 5 minutes or more. end call; when no call is in progress, access – FM/DAB/AM radio stations (depending on The system will resume normal operation telephone menu.
  • Page 223 PEUGEOT Connect Nav Applications Telephone Vehicle Run certain applications on a smartphone Connect a telephone via Bluetooth , read Activate, deactivate or configure certain ® connected via CarPlay , MirrorLink messages and emails and send quick vehicle functions. ® (available in some countries) or Android Auto.

  • Page 224: Voice Commands

    PEUGEOT Connect Nav Voice commands Example of a "voice command" for the radio and media: "Play artist Madonna" Steering wheel-mounted Example of a "voice command" for the controls telephone: "Call David Miller" Voice commands: Voice commands can be issued from any The voice commands, with a choice of 17 screen page after a short press on the "Voice...
  • Page 225 PEUGEOT Connect Nav step. There's more information available in To plan a route, say "navigate to" followed by the distance" or "arrival time". To learn more "novice" mode. You can set the dialogue mode to address, the contact name or an intersection. For commands, try saying "help with navigation".
  • Page 226 PEUGEOT Connect Nav "Radio Media" voice Voice commands Media voice commands are available only with a USB connection. commands What's playing? Voice commands Help messages "Telephone" voice commands Turn on source radio - Streaming Bluetooth To choose what you'd like to play, start by saying - …...

  • Page 227: Navigation

    PEUGEOT Connect Nav David Miller, I'll be late". To display the list of From the list of quick messages, say the name of Bill Carter, I'll be late". Check the phone menu calls, say "display calls". For more information on the one you'd like to send.
  • Page 228 PEUGEOT Connect Nav To a recent destination To a contact address from the "Contact" list or the address "History". Press Navigation to display the main Press Navigation to display the main page. page. If you do not confirm the house number, Press the "MENU"...
  • Page 229 Choose the type of coordinates: Explore the map by sliding a finger on the use the Peugeot Connect Packs solution, or DMS for: Degrees, Minutes, Seconds. screen. else a "network connection provided by the DD for: Degrees, Decimals.

  • Page 230: Connected Navigation

    USB connection. all (see the "Connect-App" section). If you use the Peugeot Connect Packs The quality of services depends on the quality Wi-Fi connection solution, the system is automatically of the network connection.
  • Page 231 PEUGEOT Connect Nav Declaration: "Risk areas Press "Private mode". – “Risk areas alert" then press the warning icon (triangle) to configure alerts. alert" THEN – "Give an audible warning". Activate or deactivate: – "Advise proximity of POI 1". To send information about danger zones, –...

  • Page 232: Applications

    PEUGEOT Connect Nav Select the "Settings” tab. Press this button to display the list of CarPlay function must first be activated on ® services. the smartphone. Select the desired fuel. Select "View map". In all cases, the smartphone must be unlocked, to enable the communication Press "OK"...
  • Page 233 PEUGEOT Connect Nav Press "CarPlay" to display the CarPlay Depending on the smartphone, it may be From the system, press "Applications" to ® interface. necessary to activate the "MirrorLink " display the main page. function. Press "Connectivity" to access the "Android...
  • Page 234 PEUGEOT Connect Nav Internet Browser If the pairing procedure fails, we – “Streaming" (streaming: wireless playing of recommend deactivating and then audio files on the smartphone), Press Applications to display the main reactivating the Bluetooth function on the – "Mobile internet data".

  • Page 235: Radio

    PEUGEOT Connect Nav Radio Wi-Fi connection sharing This phenomenon is perfectly normal in the context of radio wave transmission, and Depending on equipment. in no way indicative of an audio system Selecting a station Creation of a local Wi-Fi network by the system.

  • Page 236: Dab (Digital Audio Broadcasting) Radio

    PEUGEOT Connect Nav Press "OK" to confirm. TA message can be heard. Normal play of the Press the "OPTIONS" button to access the previously playing media resumes at the end of secondary page. the message. Select "Radio settings". RDS station tracking may not be Select "Announcements".

  • Page 237: Media

    PEUGEOT Connect Nav Media Selecting the source If play does not start automatically, it may be necessary to start the audio playback from the Press Radio Media to display the main smartphone. USB port page. Control is from the portable device or by using Select "SOURCES".

  • Page 238: Telephone

    PEUGEOT Connect Nav Telephone Information and advice Procedure from the system Press Telephone to display the main The system supports USB mass storage Pairing a Bluetooth page. ® devices, BlackBerry devices and Apple players ® ® Press "Bluetooth search". via the USB ports. The adapter cable is not telephone supplied.
  • Page 239 PEUGEOT Connect Nav Managing paired telephones The ability of the system to connect just Select "End call" on the touch screen. one profile depends on the telephone. This function lets you connect or disconnect a All three profiles may connect by default.
  • Page 240 PEUGEOT Connect Nav Calling a recently used Managing quick messages Press this button to sort contacts by Surname+first name or by First number Press Telephone to display the main name+surname. page. Press Telephone to display the main Press the "OPTIONS" button to access the The "Email"...

  • Page 241: Settings

    PEUGEOT Connect Nav Access to email messages depends on The "Position” settings (All passengers, Press "OK" again to save the settings. the compatibility between the Driver and Front only) are common to all smartphone and the onboard system. sources. The location for the photograph is Activate or deactivate "Touch tones",...

  • Page 242: Frequently Asked Questions

    PEUGEOT Connect Nav Move the slider to adjust the brightness of Select "Setting the time-date". Press "OK" to confirm. the screen and/or the instrument panel. Press Settings to display the main page. Select "Date". The system may not automatically Press this button to set the date.
  • Page 243 PEUGEOT Connect Nav Navigation ► Activate the audible warning in the The altitude is not displayed. "Navigation" menu and check the voice volume On starting, GPS initialisation may take up to I cannot enter the navigation address. in the sound settings.
  • Page 244 PEUGEOT Connect Nav The aerial is missing or has been damaged There may be an extended pause after The Bluetooth telephone is not compatible with (for example while entering a car wash or inserting a USB stick. the system. underground car park).
  • Page 245 PEUGEOT Connect Nav Settings a high level) first. Then adjust the volume level on the audio system. When the treble and bass settings are When the engine is off, the system switches changed, the ambience is deselected. off after several minutes of use.
  • Page 246 Alphabetical index 180° rear vision Airbags, front 82, 84, 87 Blind 39–40 Airbags, lateral 83–84 Blind spot monitoring system, active Air conditioning 48, 51 Blind spot sensors Air conditioning, automatic BlueHDi 18, 166, 172 Air conditioning, digital Bluetooth (hands-free) 213–214, 236–237 Air conditioning, dual-zone automatic Bluetooth (telephone) 213–214, 236–237...
  • Page 247 Alphabetical index Changing a fuse 183–184, 187–188 Connection, MirrorLink 212–213, 231 Deferred charging 24, 153, 156, 158 Changing a wheel 173, 177 Connection, Wi-Fi network 232–233 Defrosting Changing a wiper blade 72–73 Connectivity Defrosting, front Changing the remote control battery Consumption figures Demisting Charge level indicator...
  • Page 248 Alphabetical index Electric automatic gearbox (Hybrid) Fitting roof bars 160–161 Gear shift indicator ~ Gear efficiency Electric windows Fittings, boot indicator 108–109 Electronic brake force distribution (EBFD) Fittings, interior Glove box Emergency braking assistance (EBA) Fittings, rear G.P.S. Emergency call Flap, charging 153, 156–158 Grab handles...
  • Page 249 Alphabetical index Key with remote control 25, 97 Loading 160–161 Kit, hands-free 213–214, 236–237 Load reduction mode i-Cockpit® amplify function Kit, puncture repair 173–174 Locating your vehicle Ignition 98, 238 Kit, temporary puncture repair 173–176 Locking 26–27 Ignition on Locking from the inside Immobiliser, electronic Locking the doors 30–31...
  • Page 250 Alphabetical index Misfuel prevention Paint colour code Radio 208–209, 211, 233 Motor, electric 108, 152, 202 Parcel shelf, rear Radio, digital (Digital Audio Motorised tailgate 34–35, 37 Park Assist Broadcasting - DAB) 210, 234 Mountings, ISOFIX Parking brake, electric 99–101, 167 Range, AdBlue 18, 166 Parking sensors, audible and visual...
  • Page 251 Alphabetical index Reset trip Side parking sensors Sunroof, panoramic 39–40 Rev counter Ski flap Sunshine sensor Reversing camera 112, 138–140 Smartphone 24, 54, 157–158 Sun visor Reversing lamps 182–183 Snow chains 111, 161–162 Suspension Roof bars 160–161 Socket, 12 V accessory 55, 59, 63 Suspension with variable vibration Running out of fuel (Diesel)
  • Page 252 Alphabetical index Trailer 79, 158 Trailer stability assist (TSA) Wallbox Trajectory control systems Warning and indicator lamps Triangle, warning Warning lamp, driver''s seat belt Trip computer 21–22 not fastened Trip distance recorder Warning lamps 11, 20 Tyres 167, 204 Warning lamp, seat belts Tyre under-inflation detection 110, 177 Warnings and indicators...
  • Page 275 Automobiles PEUGEOT declares, in accordance with the provisions of the European legislation (Directive 2000/53) relating to End-of-Life Vehicles, that it achieves the objectives set by this legislation and that recycled materials are used in the manufacture of the products that it sells.
  • Page 276 *19.R8.0040* ANG. 19.R8.0040 www.peugeot.com...

Table of Contents
