CARBON BRUSHES

The brushes and commutator in your tool
have been engineered for many hours of
dependable service. To maintain peak
efficiency of the motor, we recommend every
two to six months the brushes be examined.
Only genuine Bosch replacement brushes
specially designed for your tool should be
used.
BEARINGS
After about 300-400 hours of operation, or at
every second brush change, the bearings
should be replaced at Bosch Factory Service
Center or Authorized Bosch Service Station.
Bearings which become noisy (due to heavy
load or very abrasive material cutting) should
be replaced at once to avoid overheating or
motor failure.
If an extension cord is
W RNING
necessary, a cord with
adequate size conductors that is capable
of carrying the current necessary for your
tool must be used. This will prevent
excessive voltage drop, loss of power or
overheating. Grounded tools must use 3-wire
extension cords that have 3-prong plugs and
receptacles.
NOTE: The smaller the gauge number, the
heavier the cord.
(*= standard equipment)
(**= optional accessories)
* Allen wrench 6mm
* Auxiliary Handle
* Sanding disc
* Soft backing pad
W RNING
the power supply before cleaning or
performing any maintenance. The tool may
be cleaned most effectively with compressed
dry air. Always wear safety goggles when
cleaning tools with compressed air.
Ventilation openings and switch levers must
be kept clean and free of foreign matter. Do
not attempt to clean by inserting pointed
objects through openings.
C UTION
parts. Some of these are: gasoline, carbon
tetrachloride, chlorinated cleaning solvents,
ammonia and household detergents that
contain ammonia.
Accessories
RECOMMENDED SIZES OF EXTENSION CORDS
120 VOLT ALTERNATING CURRENT TOOLS
Cord Size in A.W.G.
Tool's
Ampere
Cord Length in Feet
Rating
25
3-6 18
6-8
18
8-10 18
10-12 16
12-16 14
* Vacuum hose adapter tube
** Vacuum hose adapter
** Extra soft backing pad
** Hard backing pad
** Vacuum hoses
** Foam buffing pad
** Sponge applicator pad
-10-
Cleaning
To avoid accidents always
disconnect the tool from
Certain cleaning agents and
solvents damage plastic
Wire Sizes in mm
Cord Length in Meters
50 100 150 15 30 60
16 16 14 0.75 0.75 1.5
16 14 12 0.75 1.0 2.5
16 14 12 0.75 1.0 2.5
16 14 12 1.0 2.5 4.0
12 — — — — —
2
120
2.5
4.0
4.0
—
—
