DCVR12 / DCVR10 / TCVR10
Models:
Attention:
Please record your purchase information in the area
below. We recommend attaching the original sales
receipt to this manual for future reference.
If you require service on this speaker during the
warranty period, you will need to provide this
information and a copy of the original sales receipt to
Kicker for validation of warranty repairs.
ALWAYS KEEP YOUR RECEIPT!
_____________________________________________
Authorized Kicker Dealer:
_____________________________________________
Purchase Date:
_____________________________________________
Enclosure Model Number:
2
CompVR Subwoofer Enclosures
Page 4
CompVR
Subwoofer Enclosure
Manual
Congratulations!
You have purchased one of the most
versatile subwoofers systems in car
audio. The CompVR Enclosure was
designed by the award-winning KICKER
speaker design team, tested in the
judging lanes of International Sound
Competitions, and proven on the Street to
deliver the ultimate in low bass output,
durability and outrageous SPL.
™
This is your "fuel for Livin' Loud
Features
Injection Molded Polymineral Cone with ISD
(Inverted Structural Dome)
composite, which remains rigid, minimizes cone flex and lowers
harmonic distortion. The CompVR's cone consists of a unique
one-piece, aluminum vapor-deposit material that moves as a
light weight piston, exhibiting power and control.
integrates into the CompVR's cone with a
Rear Cone Brace
continuous contact perimeter weld, which offers unmatched
strength and resistance to deformation under pressure.
Double Stitched Surround
the chemical adhesives. This duo prevents the cone and
surround from separating in the harshest conditions.
Optimized Polyfoam Ribbed Surround Radius
extended cone excursion for additional bass output and higher
SPL, and couples the suspension into a conjoined linear-
motion body.
"!
High-Temp Polyimide Film Voice Coil Former
improves sonic and conductive properties, and prevents
thermal-electrical meltdown.
Dual Ultra-Length Voice Coils
excursion and provide flexible impedance matching options.
Sleeved High-Power Tinsel Lead Wires
broken leads and power loss, due to the common use of
"insufficient-gauge" lead wires. The lead wires are terminated
™
with polymer-based strain-relieving mechanical fasteners.
is a high performance
Human Fine-Tuned Enclosures
allow Kicker's award winning CompVR subwoofers to offer
bass performance that surpasses most custom made boxes.
™
One-Piece Uniplate
Pole Piece and Backplate
1. Optimizes heat transfer efficiency for cooler operation
and maximum power handling ability.
adds a mechanical fastener to
2. Eliminates erratic magnetic flux from the voice-coil gap.
3. Releases pressure under the suspension for uniform
cone movement and responsive low bass.
allows
4. Prevents the voice-coil from bottoming out and
corresponding damage.
New Enhanced BAM (Basket and Motor) Assembly
utilizes a high strength steel basket, features a low-profile open
design, and provides a solid foundation for the precision-
aligned motor assembly.
sustain enormous cone
Perimeter Venting in the BAM
under the spider, supports a linear excursion, and helps
dissipate heat from the voice coil and motor structure.
CompVR Subwoofer Enclosures
eliminate
and computer-modeling
with Vented Hyper-Extended
relieves pressure from
3
