- Page 2 KX350.2 / KX450.2 / KX550.2 / KX850.2 Two Channel Models: Attention: Please record your purchase information in the area below. We recommend attaching the original sales receipt to this manual for future reference. If you require service on this speaker during the...
- Page 3 EndKaps Cast aluminum, custom, removable covers to protect and hide all your wiring connections to the amplifier. Can be prepped and painted any custom color you choose. Two Year Warranty When purchased from an Authorized KICKER Dealer. KX AMPLIFIERS...
- Page 4 Mounting When selecting a location to mount your Kicker amplifier be sure it is structurally sound and that there are no items behind the area where the screws will be driven that could be damaged. Check for wire harnesses, brake lines, fuel lines, gas tanks, etc.
- Page 5 When working with power connections it is always recommended that you disconnect the battery to prevent accidents. Note: To get the best performance from your new Kicker Amplifier, we recommend using genuine Kicker Accessories and Wiring. The ground should be connected to the amplifier first before making any of the other connections.
- Page 6 USING THE SIGNAL OUTPUT JACKS (PAST) The Output (Pre Amp Signal Transfer) RCA jacks allow you to send the incoming signal from one Kicker KX series amplifier to another amplifier or processor without the need for Y cables. The signal from the PAST jacks is identical to the signal fed to the amplifier via its RCA input jacks or the High Level inputs and is not affected by the amplifier’s built in crossover.
- Page 7 System Diagram The following diagrams show the most common configurations for your Kicker KX series amplifier. TWO CHANNEL OPERATION (STEREO) KX.2 series amplifiers are capable of operating into a minimum impedance of 2 ohms per channel in stereo operation. GROUND...
- Page 8 STEREO AND MONO SIMULTANEOUSLY (SAMS) KX.2 series amplifiers are capable of operating into a minimum impedance of 4 ohms mono and 2 ohm stereo simultaneously with the use of passive crossovers. GROUND REMOTE TURN-ON 18" or less +12V FUSE BATTERY System Diagram KX AMPLIFIERS RIGHT SPEAKER(S)
-
Page 9: Gain Control
Navigation On your Kicker amplifier there are three rotary controls on top and one switch on the end panel. These controls ensure the reli- ability and performance of the amplifier, so they need to be set correctly. CROSSOVER SWITCH NEVER CHANGE THE CROSSOVER SWITCH SETTING WITH... -
Page 10: Troubleshooting
There are two LEDs on the end panel of your Kicker KX series amplifier, one green and one red. When the green LED is lit this indicates the amplifier is turned on and no trouble exists. If the green LED turns off and the red LED is lit this indicates that the protection circuitry (SORT) is engaged. - Page 11 NOTE: All specifications and performance figures are subject to change. Please visit the support section at www.kicker.com for the most current information. Please Note: Modern high performance speakers have a lower DC Resistance than what used to be available.
-
Page 12: Specifications Common To All Models
KX AMPLIFIERS KX850.2 295 x 2 425 x 2 180 x 2 360 x 2 Model KX350.2 110 x 2 @ 4 ohms, 14.4Vdc, 1% THD, CEA-2006 (Watts) Signal to Noise Ratio -98 CEA-2006 (ref: 1W, A-weighted) Model KX450.2 150 x 2 @ 4 ohms, 14.4Vdc, 1% THD,... -
Page 13: What Is Not Covered
ELECTRONICS LIMITED WARRANTY Kicker warrants this product to be free from defects in material and workmanship under normal use for a period of THREE (3) MONTHS from date of original purchase with receipt. When purchased from a Authorized KICKER Dealer it is warranted for TWO (2) YEARS from date of original purchase with receipt. - Page 14 Notes Tech Lines KX AMPLIFIERS...
