TEC POS Terminal
ST-71 SERIES
Maintenance Manual
Document No. EO18-12010
Original
Dec., 2005
(Revised
)
NOTE:
Model names that end with "-R" are RoHS compliant models. If "-R" is not
attached, that model is non RoHS compliant.
Never install non RoHS compliant optional equipment or parts on a RoHS
compliant machine which is supposed to be used in the countries that enforce
the RoHS directive, as doing this is legally prohibited.
PRINTED IN JAPAN
Advertisement
Table of Contents
Related Manuals for TEC ST-71 SERIES
Summary of Contents for TEC ST-71 SERIES
- Page 1 TEC POS Terminal ST-71 SERIES Maintenance Manual Document No. EO18-12010 Original Dec., 2005 (Revised NOTE: Model names that end with "-R" are RoHS compliant models. If "-R" is not attached, that model is non RoHS compliant. Never install non RoHS compliant optional equipment or parts on a RoHS compliant machine which is supposed to be used in the countries that enforce the RoHS directive, as doing this is legally prohibited.
- Page 2 WARNING! Follow all manual instructions. Failure to do so could create safety hazards such as fire or electrocution. NOTES: 1. Manual instructions must be followed when installing option kits or adding cables to avoid system failures and to insure proper performance and operation. 2.
-
Page 3: Table Of Contents
EO18-12010 (Revision Date: Jan. 30, 2006) TABLE OF CONTENTS Page 1. UNPACKING ......................1- 1 Procedure ........................1- 1 Checks..........................1- 1 Tapes..........................1- 2 Notes for Installation......................1- 2 2. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT........ 2- 1 Installing the Hard Disk Drive (HDD) ................2- 2 Installing the LVDS PC Board and Back Indicator Unit ...........2- 5 (KIT-71-DSP1, TFTST-71-2A/5A Series) Installing the Line Display, Pole Unit, and VFD Stand............2-10... - Page 4 2. The contents of this manual may be changed without notification. 3. Please refer to your local Authorised Service representative with regard to any queries you may have in this manual. Copyright © 2005 by TOSHIBA TEC CORPORATION All Rights Reserved 570 Ohito, Izunokuni-shi, Shizuoka-ken, JAPAN...
-
Page 5: Unpacking
1. UNPACKING EO18-12010 1.1 Procedure UNPACKING 1.1 Procedure Open the carton. Take the accessories out of the carton. Take out the POS terminal, then remove the pads. Place the POS terminal on a level surface. Ferrite Core (1 pc.) Bind Screw M-3x3 (8 pcs.) Carton ST-71 POS Terminal... -
Page 6: Tapes
1. UNPACKING EO18-12010 1.3 Tapes 1.3 Tapes Remove all the tapes from the POS terminal. 1.4 Notes for Installation WARNING! 1. Care must be taken not to get your fingers caught between the LCD Frame and the POS terminal when bending the display backward. 2. -
Page 7: Installation Procedure For Optional Equipment
2. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-12010 2.1 Installing the Hard Disk Drive (HDD) INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT WARNING! 1. Disconnect the power cord before installing the optional parts. 2. Be careful not to short-circuit the lithium battery on the ENGINE PC board. NOTES: 1. -
Page 8: Installing The Hard Disk Drive (Hdd)
1. For the specification of an HDD to be installed, please refer to the POS Optional Device (Document No. EO21-12001), POS OPTIONAL DEVICE BASIC SPECIFICATION. 2. Please use TOSHIBA TEC approved HDDs. Failure to do this may cause an error. Installation procedure for the first HDD is shown below. - Page 9 2. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-12010 2.1 Installing the Hard Disk Drive (HDD) Let the HDD Cable off the HDD Holder. Remove the two screws, then remove the HDD Holder in the direction as indicated by the arrow. (Carefully remove the HDD Holder on which the two hooks are provided.) Hook Screw M-3x3...
- Page 10 2. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-12010 2.1 Installing the Hard Disk Drive (HDD) Fit the HDD Holder Hooks into the positioning holes which are provided on the frame, then secure with the two screws. Hook Screw M-3x3 Reassemble in the reverse order of removal. After the installation is completed, perform an HDD test in the BIOS diagnostic test program.
-
Page 11: Installing The Lvds Pc Board And Back Indicator Unit
2. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-12010 2.2 Installing the LVDS PC Board and Back Indicator Unit Installing the LVDS PC Board and Back Indicator Unit (KIT-71-DSP1, TFTST-71-2A/5A Series) • Component Parts [KIT-71-DSP1-QM-R] LVDS PC Board Locking Support (2 pcs.) [TFTST-71-2A-QM-R] 12-inch TFT Display Double Sems Screw M-4x12... - Page 12 2. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-12010 2.2 Installing the LVDS PC Board and Back Indicator Unit Remove the two screws which secure the Front Cover, then remove the Front Cover. Screw Front Cover Screw Disconnect all cables from the ENGINE PC Board Assembly. ENGINE PC Board Assembly Downward slide and remove the Side Cover (L).
- Page 13 2. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-12010 2.2 Installing the LVDS PC Board and Back Indicator Unit Remove the two screws, then pull the Open Lever to draw the ENGINE PC Board Assembly. Open Lever DSM-4x8 Screw ENGINE PC Board Assembly Remove the two Locking Supports, then remove the LVDS PC Board.
- Page 14 2. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-12010 2.2 Installing the LVDS PC Board and Back Indicator Unit 10) Remove the two Hinge Holders from the Rear Cover. Rear Cover Hinge Holder 11) Secure the Back Indicator Unit onto the rear side of the POS terminal with the four screws. Back Indicator Unit DSM-4x12 Screw DSM-4x12 Screw...
- Page 15 2. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-12010 (Revision Date: Dec. 4, 2006) 2.2 Installing the LVDS PC Board and Back Indicator Unit 13) Lead the LVDS Cable as shown in the picture below, then insert this cable into the LVDS2 Connector on the front side of the POS terminal.
-
Page 16: Installing The Line Display, Pole Unit, And Vfd Stand
2. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-12010 2.3 Installing the Line Display, Pole Unit, and VFD Stand Installing the Line Display, Pole Unit, and VFD Stand (LIUST-71-BAAK, KIT-71-POLE, and KIT-71-BASE Series) • Component Parts [LIUST-71-BAAK-QM-R] Line Display Stopper [KIT-71-POLE-QM-R] POLE-L (F) POLE-L (R) POLE-S (F) POLE-S (R) - Page 17 2. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-12010 2.3 Installing the Line Display, Pole Unit, and VFD Stand • Installation Procedure (when installing the Line Display with the VFD Stand) Remove the Rear Cover. (Refer to Section 2.1 Installing the Hard Disk Drive (HDD).) Remove the two Hinge Holders from the Rear Cover.
- Page 18 2. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-12010 2.3 Installing the Line Display, Pole Unit, and VFD Stand Hook the VFD Frame as shown in the figure, then secure it with the four screws. T-3x8 Screw Hook T-3x8 Screw Secure the VFD Base Frame onto the POS terminal with the four screws. DSM-4x12 Screw VFD Base Frame DSM-4x12 Screw...
- Page 19 2. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-12010 2.3 Installing the Line Display, Pole Unit, and VFD Stand 12) Attach the Rubber Caps onto the Rear Cover and the VFD Stand. VFD Stand DSM-4x10 Screw Rubber Cap Rear Cover 13) Lead the VFD Cable as shown in the figure. VFD Cable 14) Connect the VFD Cable to COM3.
- Page 20 2. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-12010 2.3 Installing the Line Display, Pole Unit, and VFD Stand • Installation Procedure (when installing the Line Display with the Pole Unit and the VFD Stand) Remove the Rear Cover. (Refer to Section 2.1 Installing the Hard Disk Drive (HDD).) Remove the two Hinge Holders from the Rear Cover.
- Page 21 2. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-12010 2.3 Installing the Line Display, Pole Unit, and VFD Stand Attach the Pole Screw onto the bottom of the Pole, then clockwise turn the Pole Screw until the screw thread appears. Pole Screw Screw Thread Remove the four screws, then remove the VFD Frame from the VFD Stand.
- Page 22 2. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-12010 2.3 Installing the Line Display, Pole Unit, and VFD Stand 10) Fit the Stopper onto the axis of the Pole. Stopper 11) Hook the VFD Frame as shown in the figure, then secure it with the four screws. T-3x8 Screw Hook T-3x8 Screw...
- Page 23 2. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-12010 2.3 Installing the Line Display, Pole Unit, and VFD Stand 13) Secure the VFD Base Frame onto the POS terminal with the four screws. DSM-4x12 Screw VFD Base Frame DSM-4x12 Screw 14) Lead the VFD Cable as shown in the figure, then secure the Rear Cover onto the POS terminal with the two screws.
- Page 24 2. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-12010 2.3 Installing the Line Display, Pole Unit, and VFD Stand 18) Lead the VFD Cable as shown in the figure. VFD Cable 19) Connect the VFD Cable to COM3. COM3 VFD Cable 20) Reassemble in the reverse order of removal. 2-18...
