- Page 1 ST-6500 Setup Guide for Windows TOSHIBA TEC CORPORATION...
- Page 2 Procedure outline to set up the ST-6500/ST-6500-C7 on Windows Setting up BIOS Installing Windows Installing the 810E2 chipset software Installing the SM712 graphic driver (for the ST-6500-C7) Installing the PnP touch panel driver Changing the serial port setting TOSHIBA TEC CORPORATION...
- Page 3 Installing the Intel PRO/100 VE Network Connection Driver Execute Chipset¥LAN¥100pdisk.exe contained in the driver kit, to extract the files onto the hard disk. Select [PCI Ethernet Controller] in the Device Manager and click on the “Properties” button. TOSHIBA TEC CORPORATION...
- Page 4 Select the folder to extract 100pdisk.exe to, as the folder containing the driver to be installed. ® Select “Intel PRO/100 VE Network Connection” to install the driver. For detailed installation procedure, refer to Intel’s documents and online help. TOSHIBA TEC CORPORATION...
- Page 5 Select [Display] on the Control Panel and display the “Display Properties” screen. On this screen, select [Settings] – [Advanced] to display the “Standard PCI Graphics Adapter Properties” screen. Select [Adapter] – [Change] this screen. Select “Display¥Chips¥Win98” in the driver kit to install “Chips And Technologies, Accelerator.” TOSHIBA TEC CORPORATION...
- Page 6 Select “Tablet¥PnPTablet¥Win9x” in the driver kit to install “SMK PnP Tablet Driver.” Reboot the machine. Select [Touch Panel] on the Control Panel to display the “Touch Panel Property” screen. On this screen, select [Calibration] – [Execute] to set up calibration. TOSHIBA TEC CORPORATION...
- Page 7 Changing the Serial Port Setting IRQ for COM4 has been set incorrectly. Change the IRQ to “11.” No additional operation for the SIO1 port is required, since it cannot be actually used due to hardware configuration. TOSHIBA TEC CORPORATION...
- Page 8 “Apply” button. The on-board VGA will be enabled. Select proper “Colors” and “Screen area”. IMPORTANT: * Windows 98/98SE/2000/XP can use the Dual Display functions supported by the However, Windows NT cannot use the Dual Display functions, since Windows NT does not support them. TOSHIBA TEC CORPORATION...
- Page 9 VGA (Intel810E2) is marked with “!”, which indicates the device is disabled. (See the screen below.) To solve this problem, remove the SM712 VGA board from the machine, then start up the PC. It will make the on-board VGA (Intel810E2) enabled. TOSHIBA TEC CORPORATION...
- Page 10 When screen is in the state of disable, as shown in a figure, it is displayed faintly. A second screen can be enabled by clicking the second display of a figure. And then the following message boxes are displayed, choose Yes. TOSHIBA TEC CORPORATION...
- Page 11 Please perform PC re-starting or PC shutdown in the state having opened the control panel. Please do not click OK button or Cancel button of a display properties control panel. (If “OK” button or “Cancel” button are clicked, error may occur.) TOSHIBA TEC CORPORATION...
- Page 12 “Intel 810/815 Chipset Family Graphics Driver.” ® w Installing the Intel PRO/100 VE Network Connection Driver Execute Chipset¥LAN¥100pdisk.exe contained in the driver kit and extract the files onto the hard disk. Select [Network] on the Control Panel and execute “Network Setup Wizard.” TOSHIBA TEC CORPORATION...
- Page 13 Explanation: The Computer Browser service depends on the Server service which failed to start because of the following error: Not enough server storage is available to process this command. To clear this error, install the service pack again. TOSHIBA TEC CORPORATION...
- Page 14 Select [Display] on the Control Panel and display the “Display Properties” screen. On this screen, select [Settings] – [Advanced] to display the “Standard PCI Graphics Adapter Properties” screen. Select [Adapter] – [Change] this screen. Select “Display¥Chips¥WinNT ” in the driver kit to install “Chips And Technologies, Accelerator.” TOSHIBA TEC CORPORATION...
- Page 15 After rebooting the machine, select [Start] – [Run] and run “tabcalNT.exe” to set up calibration. Setting up the Dual Display Since Windows NT does not support the Dual Display functions, the Dual Display functions cannot be used. TOSHIBA TEC CORPORATION...
- Page 16 Installing the 810E2 Chipset Software and the PnP Touch Panel Driver w Installing the Intel Chipset Installation Utility Execute Chipset¥Chipset¥Disk1¥Setup.exe contained in the driver kit and install “Intel Chipset Installation Utility.” The following message is displayed after the machine is rebooted. Install the touch panel driver. TOSHIBA TEC CORPORATION...
- Page 17 On the “Found New Hardware Wizard” screen, select “Search for suitable driver for my device” and click on [Next]. Then, select “Specify a location” and designate the “Tablet¥PnPTablet¥Win2K” folder in the driver kit to install the driver. TOSHIBA TEC CORPORATION...
- Page 18 Open the properties screen for the device with the “?” mark and click on “Reinstall Driver.” Install these controllers in the same manner as the PnP Tablet Driver. Designate the following folders: Ethernet Controller: Folder that 100pdisk.exe was extracted to Video Controller: “Display¥SM712¥Win2K” in the driver kit TOSHIBA TEC CORPORATION...
- Page 19 IRQs for COM4 and COM5 should be set as below: • COM4 Port address: 270-277 IRQ: IRQ11 • COM5 (SIO1) Port address: 2E8-2EF IRQ: IRQ15 Updating the Driver The driver kit contains drivers newer than those supported by Windows. Update the drivers, as required. TOSHIBA TEC CORPORATION...
- Page 20 To prevent this phenomenon from occurring, perform the following procedure : Display the “Display Properties” screen. Select [Settings] – [Advanced] – [Troubleshooting]. On the displayed screen, set the “Hardware acceleration” level to any level other than “FULL”. This phenomenon will not occur. TOSHIBA TEC CORPORATION...
- Page 21 “Apply” button. The TFT monitor is set as primary monitor. To use only the TFT monitor, set the TFT monitor as primary monitor, then disable the on-board VGA (Intel810E2). TOSHIBA TEC CORPORATION...
- Page 22 Install Windows XP. Installing the PnP Touch Panel Driver The Windows XP Device Manager indicates that “SMK PnP Tablet” is not properly installed. Open the properties screen and click on “Reinstall Driver” to install the PnP Tablet Driver. TOSHIBA TEC CORPORATION...
- Page 23 On the “Found New Hardware Wizard” screen, select “Install from list or specific location” and click on [Next]. Select “Include this location in the search” and designate the “PnPTablet¥WIN2K” folder in the driver kit to install the driver. TOSHIBA TEC CORPORATION...
- Page 24 IRQs for COM4 and COM5 should be set as be low: • COM4 Port address: 270-277 IRQ: IRQ11 • COM5 (SIO1) Port address: 2E8-2EF IRQ: IRQ15 Updating the Driver The driver kit contains divers newer than those supported by Windows. Update the drivers as required. TOSHIBA TEC CORPORATION...
- Page 25 To prevent this phenomenon from occurring, perform the following procedure : Display the “Display Properties” screen. Select [Settings] – [Advanced] – [Troubleshooting]. On the displayed screen, set the “Hardware acceleration” level to any level other than “FULL”. This phenomenon will not occur. TOSHIBA TEC CORPORATION...
