NEC EXPRESS5800/R320d-M4
Configuration Guide
Windows Server
model
Introduction
This document contains product and configuration information that will enable you to configure your system. The
guide will ensure fast and proper configuration of your NEC EXPRESS5800 server.
April 2014
Revision 4.0
NEC Corporation
Advertisement
Table of Contents
Related Manuals for NEC EXPRESS5800/R320d-M4
Summary of Contents for NEC EXPRESS5800/R320d-M4
-
Page 1: Configuration Guide
Configuration Guide Windows Server model Introduction This document contains product and configuration information that will enable you to configure your system. The guide will ensure fast and proper configuration of your NEC EXPRESS5800 server. April 2014 Revision 4.0 NEC Corporation... -
Page 2: Table Of Contents
– CONFIGURATION GUIDE NEC EXPRESS5800/R320d-M4 / Windows Server model Contents TECHNICAL SPECIFICATION ..................3 Key Features ............................3 Specification ............................3 EXTERNAL VIEWS ......................5 Front and Rear Views ........................... 5 Dimensions (mm) ..........................7 CONFIGURATION DIAGRAM ..................8 SERVER CONFIGURATION ................... 9 Base Models ........................... -
Page 3: Technical Specification
– CONFIGURATION GUIDE NEC EXPRESS5800/R320d-M4 / Windows Server model Technical Specification Key Features Fault tolerant technology based on GeminiArchitecture Full manageability by integrated EXPRESSSCOPE Engine 3 High performance with the latest Intel® Xeon® processor E5-2600 v2 product family ... - Page 4 – CONFIGURATION GUIDE NEC EXPRESS5800/R320d-M4 / Windows Server model Model R320d-M4 Power (Max. Config, 1,300 VA / 1,290 Watt Consumption Operating) Dimensions (W x D x H ) 483.0 x 736.0 x 178 mm / 19.0 x 29.0 x 7.0 in (4U) Weight (Minimum / Maximum) 45 kg / 51 kg, 99.21 lbs.
-
Page 5: External Views
– CONFIGURATION GUIDE NEC EXPRESS5800/R320d-M4 / Windows Server model External Views Front and Rear Views Front View Legend Drive Bays CPU Fault LED UID Button Memory Fault LED DVD Super Multi Drive Module Power LED System Power LED SAFE TO PULL LED... -
Page 6: Rear View
– CONFIGURATION GUIDE NEC EXPRESS5800/R320d-M4 / Windows Server model Rear View Legend USB Connectors AC Inlet Management LAN Connector PCI Slots (Low-Profile) Module ID LED PCI Slots (Full-Height) Serial Port Connector Data LAN Connectors (10GBase-T) Data LAN Connectors (1000Base-T) VGA Connector For service personnel only. -
Page 7: Dimensions (Mm)
– CONFIGURATION GUIDE NEC EXPRESS5800/R320d-M4 / Windows Server model Dimensions (mm) Rack mount 748.5 688.5 Tower Conversion (Optional) NEC Corporation Revision 4.0, April 2014... -
Page 8: Configuration Diagram
– CONFIGURATION GUIDE NEC EXPRESS5800/R320d-M4 / Windows Server model Configuration Diagram Server CHASSIS CHASSIS Optical Drive Bay REAR FRONT CPU/IO Module CPU/IO Module CPU/IO module #0 : CHASSIS CHASSIS DIMM #1 DIMM #2 FRONT REAR DIMM #3 DIMM #4 Processor... -
Page 9: Server Configuration
– CONFIGURATION GUIDE NEC EXPRESS5800/R320d-M4 / Windows Server model Server Configuration 1 Base Models Product Name / Description Part Number EXPRESS5800/R320d-M4 N8800-185F no RAM, no 2.5-inch HDD Including: Intel Xeon Processor E5-2670 v2, 1 x DVD Super Multi, EXPRESSBUILDER DVD... - Page 10 – CONFIGURATION GUIDE NEC EXPRESS5800/R320d-M4 / Windows Server model Memory Configuration Guideline See the table below for the number of memory kits required in accordance with logical main memory size and number of logical processors. Memory configurations which are not listed below are not supported in the system.
-
Page 11: Internal Hard Disk Drives
– CONFIGURATION GUIDE NEC EXPRESS5800/R320d-M4 / Windows Server model 4 Internal Hard Disk Drives Available bays: 8 Category Product Name / Description Part Number SAS HDD 600GB 10K Hot Plug 2.5-inch SAS HDD : 1 x 600GB N8850-047 900GB 10K Hot Plug 2.5-inch SAS HDD : 1 x 900GB N8850-048 1.2TB 10K Hot Plug 2.5-inch SAS HDD : 1 x 1.2TB... -
Page 12: Optical Drive
LSI SAS9212-4i4e Host Bus Adapter NOTE: Up to one controller per module NOTE: For supported NEC Storage products to connect with N8803-038, contact your sales representative or refer to the NEC Storage WEB site. (http://www.nec.com/global/prod/storage/) 7 Other Add-in Components 7.1 Input Devices... -
Page 13: Add-On Components
– CONFIGURATION GUIDE NEC EXPRESS5800/R320d-M4 / Windows Server model 8 Add-on Components 8.1 17-inch LCD Console Drawer Category Product Name / Description Part Number Drawer Drawer 17inch LCD Console Unit (1U/8port) N8143-77F w/ KVM 17-inch LCD, US 83-keys Keyboard, Optical mouse, 8 port KVM... -
Page 14: Flash Fdd
– CONFIGURATION GUIDE NEC EXPRESS5800/R320d-M4 / Windows Server model Switch Unit Connection Cable Set (USB,3m) K410-118(03) 3 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin USB A Switch Unit Connection Cable Set (USB,3m) -
Page 15: External Tape Drives
– CONFIGURATION GUIDE NEC EXPRESS5800/R320d-M4 / Windows Server model 8.7 External Tape Drives 8.7.1 Tape Drive Selection Refer to the section in accordance with your type of tape drives. LTO3 Refer to 8.7.2 LTO4 Refer to8.7.2 LTO5 Refer to 8.7.2... - Page 16 – CONFIGURATION GUIDE NEC EXPRESS5800/R320d-M4 / Windows Server model 8.7.2 LTO / SAS Category Product Name / Description Part Number Controller SAS Controller N8803-039 Required LSI SAS9212-4i4e Host Bus Adapter 6Gb/s SAS, Int. 4 / Ext. 4, 7-pin SATA / SFF-8088, PCIe 2.0 x8,...
- Page 17 Disaster Recovery Option is not supported on the ft server system. It is not supported to backup from NEC Express5800/ft series to a backup device directly using NetBackup. However, NEC Express5800/ft series can be a backup-client machine of NetBackup.
-
Page 18: References
– CONFIGURATION GUIDE NEC EXPRESS5800/R320d-M4 / Windows Server model References Server Management The EXPRESSSCOPE Engine 3, integrated into the server, provides superior remote control and system management features listed in the table below. Hardware Temperature/voltage/power/ monitoring fan /degeneration (memory/hard drive) ... -
Page 19: Supported Pci Cards And Installable Slots
– CONFIGURATION GUIDE NEC EXPRESS5800/R320d-M4 / Windows Server model Supported PCI Cards and Installable Slots Part Number Product Name Slots Notes Slot # : PCI Slot: Card height: Slot type: N8804-009 1000BASE-T 2ch board kit ... -
Page 20: Notes For Using Hyper-V
8 sec 14 sec 27 sec About Guest OS Guest operating systems supported on NEC Express5800/ft series are the same as other Express5800 Servers. The tables below show the supported guest OS. For Windows Server 2008 R2 Hyper-V Edition Windows Server 2012 (x64) - Page 21 Hyper-V. For backup patterns, refer to each backup software company's web site. NEC ESMPRO Agent For monitoring guest operating systems, NEC ESMPRO Agent for Guest OS is required. Contact your sales representative for this software. Active Upgrade (For Windows Server 2008 R2 only) A team assigned to the virtual network by Hyper-V Virtual Network Manager cannot be used in Active Upgrade.
-
Page 22: Copyright Notice And Liability Disclaimer
All other products, brands, or trade names used in this document are trademarks or registered trademarks of their respective holders. NEC shall not be liable for technical or editorial errors or omissions contained herein. For hard drive capacity measurements, 1 GB = 1 billion bytes. Actual formatted capacity is less. -
Page 23: Revision History
– CONFIGURATION GUIDE NEC EXPRESS5800/R320d-M4 / Windows Server model Revision History Revision Date Description 2015.4.28 New products added: 17-inch LCD Console Drawer (8port) N8143-106F 17inch LCD Console Unit 1U N8143-105F 17inch LCD Console Drawer (1port) N8143-108F Keyboard Unit (JP) N8143-109...
