important Safety instructions
This printer has been carefully designed to provide many years of safe, reliable performance. As
with all types of electrical equipment, however, there are a few basic precautions you should take
to avoid hurting yourself or damaging the device:
• Always ensure that the printer is connected to a UL rated surge protector
• Read and follow all warning instruction labels on the printer
• Place the printer on a flat, firm, solid surface
• To protect your printer from overheating, make sure all openings on the printer are not blocked
• Do not place the printer on or near a heat source
• Do not use your printer near water, or spill liquid into it
• Be certain that your power source matches the rating listed on your printer
• Do not place the power cord where it will be walked on. If the power cord becomes damaged
or frayed replace it immediately.
• Do not insert anything into the ventilation slots or openings on the printer
• Only qualified, trained service technicians should attempt printer repair
b. LoadinG The LabeL Media
Load label media into the printer as follows:
• Open the media cover and lower the Media Hub Guide and Media Guide.
• Press in on the Printhead Latch and raise the Printhead Assembly.
4
TimeMed Labeling Systems, Inc. - Call Toll Free: 800-323-4840 or visit www.timemed.com
1. Printhead Latch
2. Media Guide
3. Media Hub Guide
