- Page 1 F200 Dual Mic-Pre and Compressor Operating Manual...
-
Page 2: Rear View
Fredenstein F200 Dual Mic-Pre and Compressor The F200 is a two channel microphone preamplifier and a two channel FET compressor with Stereo link capability. The mic-pre and compressor are connected in series. The output mixer allows the user to select only the mic-pre or the compressor . In addition, a wet/dry (compressed/ uncompressed) mix can be performed. - Page 3 Compressor CH1 and CH2 Stereo synchronization. Both channels will have identical gain reduction to avoid shifting in Stereo balance. Connectors: TRS High Impedance Direct Input accepting balanced and unbalanced signals, normally used for instruments. Fredenstein F200 Manual V1.2 July 18, 2014 Page 2...
-
Page 4: Detailed Description
DI – Direct Input: The most common use for the DI input is to connect instruments like guitars directly to the F200. The input impedance is greater than 100 KOhm to insure compatibility with most instrument pickups. - Page 5 If you put the COMP LEVEL fully counter clockwise to zero and the MIC LEVEL fully clockwise to 10, you are using the F200 as a straight microphone preamplifier. In the opposite case, putting MIC LEVEL to zero and set COMP LEVEL in the middle position (0 dB gain) or add make-up gain by turning the knob clockwise up to a maximum of 19 dB.
- Page 6 Contact Info: Fredenstein Professional Audio by Orion Communication 7F-1, No. 582, Ruei Guang Rd. Neihu District Taipei 114 Taiwan Phone : + 886-2-2657-2618 Email : info@fredenstein.com www.fredenstein.com...
