Fredenstein ramDI Operating Manual

Re-amplification and direct input

Table of Contents

Download this manual

ramDI

Re-Amplification and

Direct Input

Operating Manual

Table of Contents

Need help?

Do you have a question about the ramDI and is the answer not in the manual?

Page 1 Re-Amplification and Direct Input Operating Manual...
Page 2: Important Safety Instructions
The Federal Communication Commission warns the user that changes or modifications to the unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Fredenstein ramDI Manual V1.0 Mar 11, 2019 Page 1...
Page 3: Rear View
Please connect an input of your audio interface or console to the DI OUT XLR and an output to the AMP IN XLR connector. Connect the mains cable to the ramDI and then to a grounded mains outlet. The power ON/OFF switch is located on the back panel as well near the IEC power cable connector.
Page 4 The DI function is still available to record. Connectors: Instrument In TS high impedance input (2 M Ohms) to connect an instrument Amp Out TS output to the instrument amplifier (guitar amp, etc) Detailed Description: Fredenstein ramDI Manual V1.0 Mar 11, 2019 Page 3...
Page 5 90 VAC to 240 VAC, 50 – 60 Hz Power Consumption 10W max. Dimensions: L x H x D 140 mm x 44 mm x 120 mm 5.5” x 1.75” x 4.75” Weight 500 g, 17.5 oz Fredenstein ramDI Manual V1.0 Mar 11, 2019 Page 4...
Page 6 Contact Info: Fredenstein Professional Audio by Orion Communication 7F-1, No. 582, Ruei Guang Rd. Neihu District Taipei 11492 Taiwan Phone : + 886-2-2657-2618 Email : info@fredenstein.com www.fredenstein.com...
