Operating Instructions
Touch-Panel

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Touch-it XPC and is the answer not in the manual?

Questions and answers

Summary of Contents for Christ Touch-it XPC

  • Page 1 Christ-Elektronik GmbH. Technical changes Christ-Elektronik GmbH reserves the right to change specifications, exe- cutions and technical data held within this document without prior notice. Trademarks Brand and product names are trademarks or registered trademarks of their respective owners.
  • Page 2: Table Of Contents

    Table of contents Page Pointers........................2 1.1. Used symbols......................2 1.2. General pointers......................2 1.3. Safety pointers ......................2 General........................4 Housing Types.......................5 3.1. VESA........................5 3.2. Front Panel......................5 3.3. In Wall ........................6 3.4. Open Frame ......................6 Commissioning .....................7 4.1. Equipment .......................7 4.1.1. Power Supply for VESA Housing ................7 4.1.2.
  • Page 3: Pointers

    Pointers 1.1. Used symbols Symbols The following symbols are used in this instruction manual: DANGER! Denotes a direct threat of danger. Not observing this pointer may be life threatening or lead to serious injuries. CAUTION! Denotes a possibly dangerous situation. Not observing this pointer can cause minor injuries or lead to material damages.
  • Page 4 CAUTION! If the device is used for other purposes or incorrectly operated, Christ Elektronik GmbH will not hold damages liable. Do not operate the touch-sensitive surface of the screen with any abra- sive or sharp-edged objects.
  • Page 5: General

    Intel® 945GSE + ICH7M 7. Memory 2 GB, DDRII 8. Storage Compact Flash 8 GB, 133x Hard Disk Drive 250 GB, 2,5”, SATA 9. Operation Foil touch Table 1: overview Touch-it XPC Please refer to the order number for further information. E461201...
  • Page 6: Housing Types

    Housing Types In order to mount the touch panel, the following variants are available: 3.1. VESA Picture 1: VESA mounting variants front view desk stand surface mounting individual holder-system 3.2. Front Panel Picture 2: Front Panel mounting front view with fan fanless fasting clamp E461201...
  • Page 7: In Wall

    3.3. In Wall Picture 3: wall mounting housing front view in the wall 3.4. Open Frame Picture 4: open frame (with front USB) front view reverse view E461201...
  • Page 8: Commissioning

    The Touch-Panel contains the following equipment: 4.1.1. Power Supply for VESA Housing Picture 5: power supply The Touch-it XPC VESA housing needs a power supply with Hirose connector (see chapter 4.3). A 24VDC power supply is included in the delivery. 4.1.2.
  • Page 9: Supply Voltage Application

    Picture 8: connector side Touch-it XPC In Wall/ Front Panel housing Ethernet COM1 Supply EIA-232 voltage The interfaces are described in the chapter 7. 4.3. Supply voltage application Picture 9: connection supply voltage VESA housing Pin 1: 24 V DC nominal...
  • Page 10: Software

    Software 5.1. System Test and Initialization These routines test and initialize board hardware. If the routines encounter an error during the tests, you will either hear a few short beeps or see an error message on the screen. There are two kinds of errors: fatal and non-fatal.
  • Page 11: Changing Display Resolution

    Integrated Peripherals Use this menu to specify your settings for integrated peripherals. (Primary slave, secondary slave, keyboard, mouse etc.) Power Management Setup Use this menu to specify your settings for power management. (HDD power down, power on by ring, KB wake up, etc.) 5.3.1.
  • Page 12: Touch Panel Driver

    Touch Panel Driver 1. Click on [Start] [All Programs] [Pen Mount Universal Driver] [Pen Mount Control Panel] 2. Click on [Pen Mount 6000 USB] E461201...
  • Page 13 3. Click on [Standard Calibration] 4. Pressing the [Standard Calibration] button on the main window activates the calibration screen to carry out calibration of the Touch Panel. Briefly touch the centre of the red square splayed on the screen in order as they appear. Once calibration is carried out, the calibrated value is saved.
  • Page 14: Interfaces

    Connection of the supply voltage, see chapter 4.3. 7.1. USB connection The Touch-it XPC offers two USB ports. The USB connections are pro- vided for the connection of storage media as well as peripheral equip- ment (USB Mouse or Keyboard).
  • Page 15: Ethernet (Lan)

    6: D2- pin 3: D2+ pin 7: D4+ pin 4: D3+ pin 8: D4- The Touch-it XPC offers two Ethernet network interfaces. 7.3. COM1 (EIA-232 interface) Picture 14: pin assignment EIA-232 interface (DB9 male socket) COM1 pin 1: DCD...
  • Page 16: Maintenance And Servicing

    Maintenance and servicing 8.1. Maintenance plan INFORMATION! Only the manufacturer (Christ-Elektronik GmbH) is allowed to replace the internal lithium battery. The calibration of the touch may be required from time to time. 8.2. Repairs DANGER! Only the qualified staffs are allowed to carry out the repairs. The incorrect repair may lead to serious danger for the user.
  • Page 17: Error Treatment And Disturbance Removal

    Clock does not work Battery empty Only the manufacturer (Christ- Elektronik GmbH) is allowed to replace the internal lithium battery Operating system does CF card damaged or the file sys-...
  • Page 18: Technical Specifications

    Technical Specifications Touch-it XPC Display 10,4“ (26,4 cm) 15” (38,1 cm) Screen Size Display Dimensions [mm] 215 x 162 304 x 228 Native Resolution (Pixel) 800 x 600, 1024 x 768 1024 x 768 Technology Colours 262.144 Backlight CCFL Luminance [cd/m²]...
  • Page 19 Touch-it XPC Material Front anodised aluminium Chassis (wall, front panel) galvanised metal Chassis VESA anodised aluminium Weight [kg] User Environment Operating Temperature 0 to +50 ° C Storage Temperature -10 to +70 ° C Humidity 5% to 80% (non condensing)
  • Page 20: Scale Drawing

    Scale Drawing 11.1. VESA Housing Picture 16: dimensions Touch-it XPC 10,4” E461201...
  • Page 21 Picture 17: dimensions Touch-it XPC 15” E461201...
  • Page 22: 11.2. Front Panel Housing

    11.2. Front Panel Housing Picture 18: dimensions Touch-it XPC 10,4” with fan E461201...
  • Page 23 Picture 19: dimensions Touch-it XPC 10,4” fanless E461201...
  • Page 24 Picture 20: dimensions Touch-it XPC 15” with fan E461201...
  • Page 25 Picture 21: dimensions Touch-it XPC 15” fanless E461201...
  • Page 26: 11.3. In Wall Housing

    11.3. In Wall Housing Picture 22: dimensions Touch-it XPC 10,4” E461201...
  • Page 27: Open Frame With Front-Usb

    Picture 23: dimensions front frame for Touch-it XPC 10,4” E461201...
  • Page 28 Picture 24: dimensions In Wall Box for Touch-it XPC 10,4” E461201...
  • Page 29 Picture 25: dimensions Touch-it XPC 15” E461201...
  • Page 30 Picture 26: dimensions front frame for Touch-it XPC 15” E461201...
  • Page 31 Picture 27: dimensions In Wall Box for Touch-it XPC 15” E461201...
  • Page 32 11.4. Open Frame with Front-USB Picture 28: dimensions Touch-it XPC 10,4” E461201...
