SAFETY PRECAUTIONS IMPORTANT SAFETY NOTICE Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in the Schematic Diagram and Replacement Parts List. It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent Shock, Fire, or other Hazards.
SERVICING PRECAUTIONS CAUTION: Before servicing receivers covered by this service unit under test. manual and its supplements and addenda, read and follow the 2. After removing an electrical assembly equipped with ES SAFETY PRECAUTIONS on page 3 of this publication. devices, place the assembly on a conductive surface such as NOTE: If unforeseen circumstances create conflict between the aluminum foil, to prevent electrostatic charge buildup or...
Page 5
IC Remove/Replacement Some chassis circuit boards have slotted holes (oblong) through Circuit Board Foil Repair which the IC leads are inserted and then bent flat against the Excessive heat applied to the copper foil of any printed circuit circuit foil. When holes are the slotted type, the following technique board will weaken the adhesive that bonds the foil to the circuit should be used to remove and replace the IC.
SPECIFICATION NOTE : Specifications and others are subject to change without notice for improvement. 1. Specification 2. Test method Each part is tested as below without special appointment. A. Temperature : 20±5°C F. Performance : LGE TV test method followed B.
Page 7
4. Chroma (SET With 45% Filter) Item Unit Remark White peak brightness cd/m 47LB1DA-UB (Center 1-point / Full White Pattern) White average brightness cd/m Brightness uniformity Full white Color coordinate Typ. 0.638 Typ. -0.03 0.340 +0.03 GREEN 0.279 0.611 BLUE 0.146...
Page 9
Wooden Indi Wooden Stand Assy Type Attached ( detachable ) Size(W x D x H) Tilt Degree Tilt force Swivel Degree +30°(±1) / -30°(±1) Swivel Force 2.0 ~ 2.3 kgf Appearance General Refer to Standard of LG(55)G1-1020 - 9 -...
ADJUSTMENT INSTRUCTION 1. Application Object 4. Gemstar VBI Micom Download These instructions are applied to all of the LCD TV, LA61B. 4-1. Preparation for Adjustment (1) As shown below, connect the MPLAB ICD2 equipment, PC and Digital Connector. 2. Notes (2) Turn on the MPLAB ICD2 POWER Supply.
Page 11
(4) Select "Programmer -> Connect". 5. POD Certificate Download 5-1. Preparation for Adjustment (1) Connect the MEMORY JIG and PC. (2) Turn on the JIG MAIN POWER SWITCH. (3) After turn on the PC and MONITOR, execute the ‘Certificate Downloader v1.4’ from the screen. 5-2.
Page 12
(5) After clicking ENTER, the ‘opens Private key' window 6-2. Preparation for Adjustments appears and select the Private key applied to the SET. (1) In case of with VBI Inserter(TES3): Signal uses Cable input The Private Key file name is on the Label of the Digital and set as below.
Page 13
(2) Preparation for Adjustments & 7. Cable Operation Confirmation Setting of Device (1) Confirm that the Cable Card is inserted in the slot. 1) Set devices as below and turn on the PC and JIG. (2) Enter the EZ adjust menu by pressing the Adjust key on 2) Open S/W for writing DDC (EDID data write &...
Page 14
(2) ADC 1080i Component2/RGB Adjustment EDID for RGB Check the connection Component2, RGB to the Test Equipment 00 FF FF FF FF FF FF 00 1E 6D 5D 9C 01 01 01 01 (MSPG-925FA : -> model : 223, pattern : 65) 10 00 10 01 03 18 73 41 96 0A CF 74 A3 57 4C B0 23 20 09 48 4C AF CE 00 01 01 01 01 01 01 01 01 01 01 (1) Select Component1 as the input with 100% Horizontal...
Page 15
11-2. Adjustment of White Balance Operate the Zero-calibration of the CA-210, then attach sensor to LCD module surface when you adjust. Manual adjustment is also possible by the following sequence. (1) HEAT RUN at least 30 minutes by pressing the Power only Key on the Service Remote Control and adjust.
SVC REMOCON To turn the TV on or off POWER To turn the TV on automatically if the power is supplied to the TV. (Use the POWER ON POWER key to deactivate): It should be deactivated when delivered. To activate the mute function. MUTE To check TV screen image easily.
Base Assembly, STAND 47LB1R-ZH(CKD) LP62H BLACK 3043900027A Base Assembly, 47LB1 . . EBR30403401 PCB Assembly,Sub, SUB T.T LA61B 47LB1DA-UB ALL CONTROL KEY TOTAL ASSY EBR30403501 PCB Assembly,Sub, SUB T.T LA61B 47LB1DA-UB ALL INDEX TOTAL ASSY AGU30990804 Plate Assembly, ASSY METAL MAIN FRAME(47LB1,UB,CKD)
REPLACEMENT PARTS LIST For Capacitor & Resistors, the CC, CX, CK, CN, CH : Ceramic RD : Carbon Film charactors at 2nd and 3rd digit in the CQ : Polyestor RS : Metal Oxide Film P/No. means as follows; CE : Electrolytic RN : Metal Film CF : Fixed Film RH : CHIP, Metal Glazed(Chip)
