Casio 2925 Operation Manual

MO0410-EA
About This Manual
(Light)
General Guide
• Press C to change from mode to mode.
• In any mode, press L to illuminate the display.
Timekeeping
PM indicator
Hour : Minutes
Year
Seconds
Day of week
Month – Day
3. When the setting you want to change is flashing, use D and B to change it as
described below.
Setting Screen
Seconds
Hour, Minutes
12/24-Hour
Format
Year, Month, Day
4. Press A to exit the setting screen.
• The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is
applied in all modes.
• The day of the week is automatically displayed in accordance with the date (year,
month, and day) settings.
Stopwatch
Remaining memory
Hours
Minutes
Seconds
Timekeeping Mode time
1/100 second
How the Stopwatch Works
There are two ways you can use the stopwatch: to measure elapsed time and lap/split
times like a standard stopwatch (see "To measure times with the stopwatch"), and to
keep track of the distance you cover while jogging or running. In order to use the
stopwatch to keep track of distance, you must first perform the steps listed below.
1. Set your basic data. See "Basic Data".
2. Turn on the pacer signal. See "To turn the pacer signal on and off".
Note
• In order to obtain accurate distance calculations, you must set accurate basic data
and keep your exercise pace in accordance with the pacer signal emitted by the
watch.
• See "How Stopwatch Data is Stored" for information about the type of data the watch
stores in memory when you use the stopwatch.
• Use the Recall Mode to view data stored in memory.
• You can view distance covered data only by recalling it in the Recall Mode. It does
not appear on the Stopwatch Mode screen.
Operation Guide 2925
• Button operations are indicated using the letters shown
in the illustration.
• Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the "Reference" section.
Timekeeping Mode
Press C.
Use the Timekeeping Mode to set and view the current
time and date.
To set the time and date
1. In the Timekeeping Mode, hold down A until the
seconds start to flash, which indicates the setting
screen.
2. Press C to move the flashing in the sequence shown
below to select other settings.
12/24-Hour
Seconds Hour Minutes
Day Month
Button Operation
Press D to reset to 00.
Use D (+) and B (–) to change the setting.
Press D to toggle between 12-hour (12H) and
24-hour (24H) timekeeping.
Use D (+) and B (–) to change the setting.
The 1/100-second stopwatch can measure elapsed time
and lap/split times. The stopwatch uses the basic data you
input and a pacer signal to calculate the distance you
cover while jogging or running. Stopwatch times and your
distance are also stored in memory.
• The stopwatch measurement operation continues even
if you exit the Stopwatch Mode.
• Exiting the Stopwatch Mode while a lap/split time is
frozen on the display clears the lap/split time and returns
to elapsed time measurement.
• Stopwatch measurements are performed in the
Stopwatch Mode, which you enter by pressing C.
Stopwatch Mode
Dual Time Mode
To measure times with the stopwatch
Note
• Pressing D to perform a lap/split time operation freezes the lap/split time at that
point on the display for about eight seconds. After that, the display returns to normal
Format
stopwatch time measurement.
• During a stopwatch time measurement operation, the upper part of the display
shows the current lap/split number and the hour digit, the center part shows the
current split time, and the lower part shows the current lap time.
Year
• When the pacer signal is turned on, it sounds for the first 30 seconds after you start
a stopwatch time measurement operation. After that, the pacer signal sounds for 30
seconds whenever you press A.
• If the pacer signal does not sound even though you have it turned on, press A to
change the positions of the lap time and split time on the display. This should cause
the pacer signal to sound.
Selecting the Stopwatch Screen Format
The following shows how you can control the position of the lap time and split time on
the stopwatch screen.
Lap/Split number
Split
time
Lap time
• The Lap/Split indicator uses arrows to indicate the location the lap time and split
(elapsed) time.
• When you first start a stopwatch operation by pressing B, both the center part and
the lower part of the display show minutes, seconds, and 1/100 second. Whenever
the time shown in the lower part of the display is greater than 60 minutes, the display
format changes to show hours, minutes, and seconds. Whenever the time in the
center part of the display is greater than 10 hours, the display format changes to
show hours, minutes, and seconds.
Basic Data
The term "basic data" refers to the pacer signal setup, and information about your
stride length.
Important!
• You cannot change basic data settings while a Stopwatch Mode time measurement
operation is in progress. Stopwatch operation must be stopped and the Stopwatch
screen must be cleared to all zeros before you can change basic data settings.
• Whenever you want to change the stride length unit, you must first reset the
Cumulative Total screen to zero. See "To reset the cumulative total screen" for
information about how to do this.
• Be sure to update basic data values whenever the person using the watch changes.
Pacer Signal
The pacer signal of this watch beeps in accordance with a pacer value (rate) set by
you. You can use the pacer signal to maintain a constant pace while jogging or
running. You can also turn off the pacer signal when you do not want to use it.
• The pacer value you set specifies the number of beeps per minute.
• Turning on the pacer signal causes the watch to beep at the rate specified by the
pacer value.
• You can set a pacer value in the range of 100 to 200 beats per minute, in units of 5.
• You can disable the pacer function by setting a pacer value of xxx. While the pacer
value is set to xxx, the watch does not calculate distance covered.
Recall Mode
Alarm Mode Countdown Timer Mode
Elapsed Time
➤ ➤ B ➤ B
B B
Start Stop Re-start Stop
Lap/Split Times
B ➤ D ➤ D ➤ B
Start Lap/Split Next Lap/ Stop
Split
Lap time Hours
Press A.
➤
Lap/Split
Split time More than 10 hours
indicator
➤ D
Clear
➤ D
Clear
Minutes
Seconds
1
