LPG
Operation, Safety and Maintenance

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BeaT LPG and is the answer not in the manual?

Questions and answers

Related Manuals for Chevrolet BeaT LPG

Summary of Contents for Chevrolet BeaT LPG

  • Page 1 Operation, Safety and Maintenance...

  • Page 3: Table Of Contents

    Table of contents Layout of LPG System (Side View)..............................2 Layout of LPG System (Top View)..............................3 Specification ....................................... 4 Introduction of LPG / Safety Precautions ............................5 Safety ......................................... 6 Brief Description of LPG System ............................... 7 Fuel Selection switch ..................................8 Indications of LED and Beeper ................................

  • Page 4: Layout Of Lpg System (Side View)

    Layout of LPG System (Side View) LPG Proof Case High Pressure Pipe PVC coated 13. Coolant Hose LPG Filler Valve (6 mm) 14. ECU HIGH Pressure Pipe PVC Gas Solenoid 15. Injector & Injector Rail coated (8 mm) Reducer 16. Line Clamp-Screw LPG Tank 10.

  • Page 5: Layout Of Lpg System (Top View)

    Layout of LPG System (Top View) LPG Proof Case High Pressure Pipe PVC coated 13. Coolant Hose LPG Filler Valve (6 mm) 14. ECU HIGH Pressure Pipe PVC Gas Solenoid 15. Injector & Injector Rail coated (8 mm) Reducer 16. Line Clamp-Screw LPG Tank 10.

  • Page 6: Specification

    Specification LPG Kit Identification SPARK Reducer No. Kerb Weight 885 Kg Cylinder No. Gross Weight 1270 Kg Retest Date. Seating Capacity 5 Person Multivalve No. LPG Capacity (liters) ECU ID Number. (Tank Capacity) 32.8 Liters Vehicle Details (Filling Capacity ) Engine No.

  • Page 7: Introduction Of Lpg / Safety Precautions

    LPG produces less mode, switch over to petrol mode fitted cylinder. harmful exhaust gases as compared to  Do not carry inflammable material and take your vehicle to a Chevrolet petrol & diesel. near the LPG cylinder. authorized service outlet ...

  • Page 8: Safety

     The ECU will not allow you to switch to LPG mode until the leakage is rectified.  Contact the nearest Chevrolet Authorized service station and get car repaired. Fire Extinguisher: One fire extinguisher is located below the front passenger seat.

  • Page 9: Brief Description Of Lpg System

    Brief Description of LPG System The brief description of sequential Sequential Injection is obtained by using A selection switch is provided on the HLD injection system is as under: an electronic injector in each cylinder. A Switch. This switch helps in selecting the high precision of gas dosage is obtained fuel mode for the vehicle.

  • Page 10: Fuel Selection Switch

    Forced Starting in LPG mode can be used for only 5 times. After that user for 5 seconds until fuel mode LED take his vehicle to a Chevrolet Upon changing to LPG the LED on top changes to green. authorized service outlet to extend changes to GREEN indicating that your ...

  • Page 11: Indications Of Led And Beeper

    20 seconds. At this point please press the fuel 45%-25% 2 LED Glowing selection switch to change over to petrol mode. Please get 25%-5% 1 LED Glowing your vehicle inspected/repaired at nearest Chevrolet authorized service outlet. 5%-0% 1 LED Blinking ~ 9 ~...

  • Page 12: Lpg Electrical Fuse

    LPG Electrical Fuse The LPG system is protected against short circuit / overload using 15A fuse fitted as shown in the figure. The changing of fuse should be done only at Chevrolet Authorized Outlet. CAUTION Always be sure to replace blown fuse with fuse of correct amperage.

  • Page 13: Lpg Filler Valve / Lpg Cylinder / Lpg Multivalve

    LPG Filler Valve / LPG Cylinder / LPG Multivalve LPG Filler valve LPG Cylinder LPG Multivalve The Automatic Shut Off valve is The LPG cylinder is installed in the Auto LPG Refueling valve is located at located on the Multivalve of the Auto luggage compartment.

  • Page 14: Spare Wheel Assembly

    Spare Wheel Assembly For your Spark LPG vehicle the Spare wheel is assembled to the back of your rear seat in the luggage compartment In the tool kit you will find a socket extension tool along with your other regular tools. This extension tool needs to be attached to your wheel wrench when assembling or disassembling the spare wheel from your luggage compartment.

  • Page 15: Compliance To Motor Vehicle Rules

    Your car‟s LPG tank needs to be recertified every five years as per CMVR (AIS 24, 25 and 26) Please ensure that it is done by a Chevrolet Authorized Service Outlet and the new date is engraved on the plate.

  • Page 16: Periodic Inspection & Maintenance Schedule

    Periodic Inspection & maintenance schedule Kilometer (miles) or time in months, whichever comes first INSEPECTION POINT MOUNTING OF LPG TANK & KIT LEAK CHECKING AT ALL POINTS GASEOUS FILTER GAS SOLENOID FILTER REDUCER DIAPHRAM OVERHAULING KIT WIRING HARNESS CLAMPING REPLACE TANK AFTER EVERY 15 YEARS LPG TANK** Note: * Statutory Test for Cylinder to be done as per IS-8869-1988 ** Testing of LPG Cylinder is due after 5 Years from the date of Manufacturing, which is available in the Marking Plate on the Tank.

  • Page 17: Warranty Card

    Under the warranty period only a Chevrolet authorized service outlet as mentioned in the Owner‟s Manual will carry out necessary repairs, using new, re-conditioned or re-manufactured parts with a view to correcting any defect covered by this warranty.
  • Page 18 3.6. This warranty is expressly in lieu of all warranties, whether by law or otherwise, express or implied and other obligations or liabilities on our part and we neither assume, nor authorize any person to assume on our behalf, any other liability arising from sale of the kit or any agreement in relation thereto.

  • Page 19: Change Of Ownership

    4. Warranty responsibilities of the owner: 4.1. Use the LPG system as per instructions provided in the manual. 4.2. Ensure inspection of LPG system from time to time. 4.3. Keep the Warranty Card, Service Booklet of LPG system in safe place and present it to the GMI/RAEPL dealer during your regular maintenance visit and when repair work is needed.

  • Page 20: Rohan Automotive Service Network

    Rohan Automotive Service Network Dealer’s Name of Contact Zone State City/Town Branch Address Contact No. Dealer Address Person Rohan Automotive Equipments Mr. Somen Mob: Pvt. Ltd.,EN61, Sector – East WEST BENGAL Kolkata Duta 9830210421 5,Salte Lake, Kolkata – 91 Rohan Automotive Equipments Pvt.
  • Page 21 Rohan Automotive Equipments Pvt. Ltd., Mr. Rakesh No. 11,R.O.B Main Mob: South TAMILNADU Chennai Shah Road,Nr.TVS Petrol Bunk, 9884028186 Whites Road, Royapetta, Chennai – 600 014 Rohan Automotive Equipments Pvt. Ltd., Mr. .Mahesh Mob: South A. P. Secunderabad 4-7-1121/19/ 1&2 Putli bowli, Kotak 9885019832 Hyderabad –...
  • Page 22 Pvt. Ltd., 9870041699 151, Brick Factory Compound, Opp. Dreamland Bungalows, Shastrinagar, Mulund (W), Mumbai – 400 052 Rohan Automotive Equipments Pvt. Ltd., 7, Parvati Industrial Estate, Mr. Parag Mob: West MAHARASHTRA Pune Opp. Adinath Society, Pune- Shah 9822064101 Satara Road, Pune –...
  • Page 24 General Motors India Pvt. Ltd. All information, illustrations and specifications contained in this Owner's Manual are based on the latest production information available at the time of publication. The right is reserved to make changes at any time without notice. Regd.

  • Page 25: Notes

    Notes ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ~ 21 ~...
