Xblue Networks X-25 Quick Start Manual

Powering up
1. Plug the X-25 in and allow it to power up without connecting any Telephones.
When the power LED stops flashing the X-25 will be fully powered up and
operational.
2. Use an Ethernet cable to connect your Personal Computer, Laptop or Desktop
running Windows XP, Vista or Windows7, to the LAN port of the X-25 System.
3. Open Internet Explorer and enter 192.168.10.1 in the address bar, and press enter.
When prompted enter the user name, which is "admin2583" and password which is
the word "admin" plus the last 6 alphanumeric characters (lower case only) of the
system's "WAN MAC" address, which is found on the label on the back of the system.
4. Attention: To secure your system against unwanted outside intrusion (hacking)
we strongly recommend that the first thing you do is change all of the
System's Passwords! Before you begin programming you should change all
three levels of passwords, admin2583, support and user. A password of up to 16
alphanumeric characters may be used and we recommend that you use at least 10.
The best passwords consist of upper and lower case characters and punctuation.
MAKE SURE TO MAKE A NOTE OF YOUR PASSWORD!
Download more information from www.xblue.com/x25-support.html
To change the password, log in as the Administrator go to:
Management --> Access Control --> Password
Default Login and Passwords:
Level/Rights Login
Administrator admin2583
Administrator support
User (Limited) User
xxxxxx = The last 6 alphanumeric characters (lower case) of the system's WAN MAC Address
5. Although the X-25 system comes up fully operational you may want to make some
Programming changes. You can do this manually or use the Wizard to walk you
through the most common programming parameters.
6. Use the provided Ethernet cable to connect the X-25 WAN port to your network
router or network switch, depending on your network configuration choice.
7. Connect your X-2020 telephones, one at a time, allowing each of them to
authenticate. The first one will be assigned extension 101. Each additional X-2020
telephone will automatically authenticate and be assigned the next available
extension number.
8. Change the Extension Password - The X-25 system allows your X-2020
Telephones to automatically authenticate with your system. The password will be a
randomly generated 10 digit number. It is a good idea to change the password on all
24 extensions to a unique 6 to 10 digit alphanumeric password that has both upper
and lower case letters, even if you are not using all of them at this time.
BE SURE TO MAKE A NOTE OF YOUR NEW PASSWORDS!
At Default:
•
Extension 101 is the Attendant Extension (dial 0)
•
All incoming telephone line calls will ring at all registered extensions
•
The buttons labeled 1-4 on the phone are pre-programmed as telephone lines 1-4
A list of additional security steps is available at
info@xblue.com
Product Support is available at
Default Password New Password
adminxxxxxx
Supportxxxxxx
Userxxxxxx
www.xblue.com or by request at
www.xblue.com or call 866-925-8312

Quick Start Guide

System Components
24 Button Sidecar
X-2020
Power Supply Ethernet Cable
Component Quantities may vary

Getting Started

The can be installed several different ways but the best way
X-25
is to connect the Wide Area Network (WAN) port of the
and all of your telephones to your existing data network;
X-2020
leaving the Local Area Network (LAN) port unused.
Installing the this way will allow the system to synchronize
X-25
the time and date from the Internet and if wanted connect low cost
Internet SIP Telephone lines.
Get the most current documentation from
www.xblue.com/x25-support.html
© Copyright XBLUENetworks Revision 1
Product Support is available at
X-25 Components
Power Supply
Ethernet Cable
X-25
Telephone
Power Supply
Line Cords
8 Port Switch
Telephone Lines
www.xblue.com or call 866-925-8312
X-25
