Bellingham 5kW
Multi-fuel stove
(BLM5SE)
Please hand these instructions to the stove user when installation is complete.
Leave the system ready for operation and instruct the user in the correct use of the
appliance and operation of controls.
Installation should only be carried out by a suitably qualified installer.
Dimplex recommend using an installer who is registered with HETAS (UK) or with INFO
(Republic of Ireland). Installation must comply with all current Building Regulations.
UK
IE
08/52386/0 - Issue 1
29 May 2014
The product complies with the European Safety Standards EN13240 for room heaters fired by solid fuel.
Advertisement
Table of Contents
Related Manuals for Dimplex Bellingham 5kW BLM5SE
Summary of Contents for Dimplex Bellingham 5kW BLM5SE
- Page 1 Installation should only be carried out by a suitably qualified installer. Dimplex recommend using an installer who is registered with HETAS (UK) or with INFO (Republic of Ireland). Installation must comply with all current Building Regulations.
-
Page 2: Dimensions
- 2 - K (Dia) Table 1 - Dimensions Bellingham 5kw Note: All Dimensions in mm. Dimensions stated may be subject to a slight ± variation. ( 25.4mm = 1”) Table 2 - Technical Specification Bellingham 5kw Wood Nominal heat output Solid Fuel (Ancit) Wood 84.8... - Page 3 - 3 - Solid, non-combustible material e.g. masonary or concrete See Table 3 150mm 125mm Table 3 - Position of Hearth & Appliance from adjacent walls Hearth distance ‘X’ from wall Appliance distance from walls Min Wall Thickness ‘T’ Min Wall height ‘H’ 0 - 50mm 200mm Height of appliance +300mm...
- Page 4 - 4 - CLOSURE Fire proof seal 150mm max SEAL PLATE or fire cement 150mm max...
-
Page 5: Important Safety Advice
- 5 - Bellingham 5kW (BLM5SE) IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE Health and Safety Precautions Important Safety Advice Handling: This product is heavy and should be handled with care to avoid the possibility of personal injury when moving or servicing. Please read these instructions carefully before installing Adequate facilities must be available for the unloading and handling or using this appliance. - Page 6 - 6 - Floor Protection & Installation Clearances Connect the flue pipe to the stove making sure that it fits snugly into the base of the flue collar . Seal the collar and flue connection In all instances the stove must be positioned on a non-combustible with fire cement or with other suitable high temperature sealant.
-
Page 7: Operating Instructions
- 7 - Operating Instructions baffle plate. The stove must not be operated with the door left open. The stove is not suitable for overnight burning, however it can be Warning: This appliance and its operating handles become banked up to burn for extended periods. Before refuelling, empty hot when the stove is in use and for some time afterwards. -
Page 8: General Maintenance
- 8 - Safety Notes for Your Guidance Chimney: Check your chimney each year before starting to use FIRES CAN BE DANGEROUS. your stove for the winter. Birds may have nested in the chimney Always use a fire guard in the presence of children, the elderly or masonry may have cracked. -
Page 9: The Clean Air Act 1993 And Smoke Control Areas
It is a condition of the guarantee that only genuine Dimplex spare The Secretary of State for Environment, Food and Rural Affairs parts are used. Parts that may need occasional replacement are has powers under the Act to authorise smokeless fuels or exempt fire bricks, ashpan, grate and log retainer. - Page 10 - 10 -...
- Page 11 - 11 - Bellingham 5kW (BLM5SE) BELLINGHAM 5KW STOVE (BLM5SE) - SPARE PARTS Item Description Part Number Item Description Part Number DOOR 1/70099/0 GRATE BAR 1/70420/0 HINGE 1/70095/0 BAFFLE PLATE 1/70108/0 DOOR PIN 1/70188/0 LINER BRICK PACK (2xREAR, 2xSIDE) 3/23128/0 DOOR HANDLE ASSEMBLY 4/19089/0 GRATE FRAME...
- Page 12 Great Britain: Northern Ireland: Republic of Ireland: GDC Group Ltd Glen Dimplex Northern Ireland Dimpco Ltd Millbrook House 5 Charlestown Avenue Old Airport Road Grange Drive Charlestown Industrial Estate Cloghran Hedge End Craigavon Co Dublin Southampton Co. Armagh Ireland SO30 2DF...
