GENERAL CARE AND MAINTENANCE
The 711 telephone does not require any regular maintenance.
To clean the telephone wipe with a damp cloth.
Do not use any abrasive cleaners on the telephone as this
may cause the product to become discoloured.
Distributed by:-
DAC Limited
214a Lomeshaye Business Village
Turner Road
Nelson, Lancashire, UK
BB9 7DR
T +44 (0) 1282 447000
F +44 (0) 845 2801915
www.daclimited.co.uk
DAC LIMITED
USER GUIDE
Vandal Resistant Telephones
711 Full Keypad Telephone
Advertisement
Table of Contents
Related Manuals for DAC Limited 711
Summary of Contents for DAC Limited 711
- Page 1 GENERAL CARE AND MAINTENANCE DAC LIMITED The 711 telephone does not require any regular maintenance. To clean the telephone wipe with a damp cloth. Do not use any abrasive cleaners on the telephone as this may cause the product to become discoloured.
- Page 2 CONTENTS Page 2 Approved Facilities Page 3 Electrical Installation THIS PAGE LEFT BLANK INTENTIONALLY Page 4 RA711 PCB [Key components] Page 5 Installation Page 7 Set Up Features Page 8 Setting up Expansion Board Page 11 General Care and Maintenance Page 1...
- Page 3 *1*nn Where nn represents the PIN/command Approved Facilities mode timeout value 01-99 seconds (10 seconds default) This telephone is designed to operate via a standard analogue telephone PBX or exchange. Any other usage will *2*nn Where nn represents the voltage free invalidate the approval of the apparatus and as a result it contact energise time value 01-99 seconds then ceases to comply with the standards against which...
- Page 4 SETTING UP THE EXPANSION BOARD. ELECTRICAL INSTALLATION Overview. The DAC DTMF controller expansion board product consists of a Line Terminal Connections and Selections Printed Circuit Board (PCB) which can be attached to the DAC range of telephone products which feature an expansion port. The PCB provides a DTMF decoder and controller which allow a The number of telephones that can be connected to a direct voltage free contact to be energised.
- Page 5 SETTING UP THE 711 FEATURES. RA711 Printed Circuit Board Volume. To adjust the volume of the speaker use the V+ and V- keys on the rear of the phone. The volume once set will remain at the HKSW HANDSET ON HK user set level until it is re adjusted.
- Page 6 INSTALLATION Wall Surface Installation The following information is provided for use by the approved Fix the surface installer or telephone network supplier only. The RA711 mounting back box to the telephone can be either wall mounted or top-of-pole mounted. wall, with cut-out at the bottom, Wall mounting can be surface, flush or inset into the wall.
