installing the unit
Windshield.mounting
1.. Install.the.suction.cups.and.bumper.onto.the.windshield.
mounting.bracket.by.sliding.them.into.their.holes.(if.not.
pre-installed).
2.. Press.the.bracket.base.firmly.against.the.windshield.until.
the.suction.cups.securely.take.hold.
3.. Slide.the.unit.up.to.the.bracket.until.the.bracket.arms.click.
into.the.slots.on.both.sides.of.the.unit.
4.. Bend. the. angle. of. the. windshield. mounting. bracket,. if.
necessary,.to.adjust.for.best.viewing.and.detection.angle.
5.. When.you.want.to.connect.power.from.your.vehicle,.plug.
the.small.connector.of.the.power.cord.into.the.12-volt.DC.
power.input.jack.located.on.the.side.of.the.detector.
6.. Plug.the.large.adapter.of.the.power.cord.into.the.lighter.
socket.of.your.vehicle.
