- Page 1 Video Streamer Quick Set Up Guide Model: GIP-HDVR-2001 Provision live video streaming allows you to view your favourite programmes from anywhere in the home using your smart phone or tablet device connected through your home router.
-
Page 2: Package Contents
- Requires installation of a third-party app Android tablets and smart phones - Android 3.01 and above - Requires installation of a Provision app (alternative apps are available) For an up-to-date list of devices that have been tested, and are known to work, go to http://www.provision-comm.com/support. -
Page 3: Rear Panel
Home Router Requirements The Provision Video Streamer connects to the wireless broadband router of the home network using the supplied Ethernet dongle and cable. Any broadband wireless router should be suitable, but verify that – - it has a spare Ethernet socket - the tablet or smart phone can connect by WiFi to the home router. -
Page 4: Quick Start
Quick Start STEP 1 - Install the Video Streamer Connect the HDMI output of the set-top box to the HDMI input of the Video Streamer using a good quality HDMI cable. Connect the TV output of the Video Streamer to an HDMI input of the TV using a good quality HDMI cable. -
Page 5: Step 2 - Connect Power
STEP 2 - Connect power Connect the power supply to the power input of the Video Streamer. Plug the power supply into a mains socket and switch on. Turn on power to the TV and set top box. Verify that programs can be seen on the TV. The Video Streamer will automatically connect to your home network router. - Page 6 Note that it is not possible to connect to the Video Streamer via a mobile network. Go to the Device List of the AirPlayer App, and tap to select the Provision Video Streamer. It will have a name in the form Provision-nnnT.
- Page 7 See Frequently Asked Questions, page 10, for guidance on using alternative Android apps. Install Provision HDlive Streamer. This is a free App from the Google Play store. Ensure that the tablet or phone is connected via WiFi to your home router. The WiFi symbol should be displayed in the status bar at the top of the screen - Note that it is not possible to connect to the Video Streamer via a mobile network.
- Page 8 Alternative Android App – BubbleUPnP The recommended App for Android is Provision HDlive Streamer, see Step 5 Install the free App BubbleUPnP from the Google Play Store Ensure that the tablet or phone is connected via WiFi to your home router. The WiFi symbol should be displayed in the status bar at the top of the screen - Note that it is not possible to connect to the Video Streamer via a mobile network.
-
Page 9: Troubleshooting Guide
For Android devices: Provision HDlive Streamer app Exit the Restart the Provision HDlive Streamer app There is no picture on the TV Check both HDMI cables are connected correctly, using the correct sockets In and TV of the Video Streamer (see diagram page 4) Check that the Video Streamer is on. -
Page 10: Frequently Asked Questions
Frequently Asked Questions How do I set-up the units? This is a simple procedure. See Quick Start, page 4. Are all home WiFi routers supported? The tablet or phone needs to connect to the router via WiFi, so check that this is possible. Other than that, the router should have a free Ethernet socket. - Page 11 Which alternative Android Apps are available? Provision HDlive Streamer. The preferred App for Android is Provision has tested the combination of BubbleUPnP and the default media player on a range of devices. Other combinations of UPnP app, plus media player, may work but have not been tested.
-
Page 12: Software Update
The factory default settings of the Video Streamer are correct for most home networks, mobile devices and tablets, and should not normally be changed. However, video streaming and network settings can be adjusted from the Provision HDlive Streamer App, or using a web- browser. -
Page 13: Technical Specification
Technical Specification Dimensions mm (inches) 135x145x30 (5.25x5.75x1.2) Video input resolutions 1080p60/50/24, 1080i60/50, 720p60/50, 576p50, 480p60, 480i60. Audio input format Stereo PCM Compression Video: H.264 / MPEG4-AVC Audio: AAC Mobile Streaming HTTP Live Streaming (HLS) protocol Ethernet interface 100Base-T, using supplied USB-Ethernet adaptor HDMI connectors one input one output - loop through for TV... - Page 14 This equipment incorporates High-Definition Multimedia interface (HDMI™) technology. HDMI, the HDMI Definition Multimedia interface (HDMI™) technology. HDMI, the HDMI logo and High Definition Multimedia Interface are all trademarks or registered trademarks of HDMI logo and High Definition Multimedia Interface are all trademarks or registered trademarks of HDMI licensing, LCC.
- Page 15 Page 15...
-
Page 16: Unit Serial Number
This information will be required to register the purchase and gain access to the support pages of the website if required. Unit Serial Number Date Purchased GIP-HDVR-2001-QSG V0.30 Copyright GI Provision Ltd 2013 Page 16...
