Summary of Contents for Provision GIP-WHDMI-1001
- Page 1 Package Contents 1. HD Video Streamer :Transmitter Unit 2. HD Video Streamer: Receiver Unit 3. Wall Plug Mains Power Adaptors (x2) 4. IR Transmitter (Blaster) 5. IR Receiver (Eye) 6. Vertical Mount Stands(x2) 7. Wall Mount Brackets (x2) 8. Quick Set Up Guide.
- Page 2 USB: Connect USB DC Input- Only use the supplied stick and power cycle wall plug power adaptors. for software upgrades Connection of wrong power supply may cause damage to the unit or Power Indicator LED prevent it working correctly Green: Normal Amber: Flashing IR activity Steady: USB upgrade...
- Page 3 Installation and Connection Diagram Installation and Connection Diagram Page Page 3...
- Page 4 Remove all parts from packaging and identify each part Transmitter Rear View Receiver Rear View 2 HDMI Connectors 1 HDMI Connector On the Transmitter Unit: Connect a good quality HDMI cable from source HDMI output to the transmitter HDMI (input) connector. If you are going to view the content on a main TV connect another good quality HDMI cable between the transmitter HDMI output (TV) connector and the TV HDMI input.
- Page 5 Technical Specification Dimensions mm (inches) 135x145x30 (5.25x5.75x1.2) Supported HD Resolutions 1080p60/50/24, 1080i60/50, 720p60/50, 576p50, 480p60, 480i60. Supported Audio Formats Stereo PCM Compression : Video H.264/MPEG4-AVC High profile : Audio MPEG2 Wireless Standard 802.11n Wi-Fi compliant and certified 5.2GHz Content Security Paired receivers with WPA2 AES HDCP HDMI Connectors :Transmitter...
-
Page 6: Troubleshooting Guide
Troubleshooting guide General note: Check all connections between transmitter and receiver units with the source and TV are correct and not damaged. Please refer to the set up configuration instructions if unsure I do not see a picture on the remote TV Check that the TV is switched on •... - Page 7 I get a HDCP warning on the HDTV but no video Some sources have Content Protection & Authentication issues; please • check with the manufacturers for software upgrades. Disconnecting then reconnecting the HDMI connectors can sometimes solve the problem. No sound on the remote TV Check the volume setting on the TV.
-
Page 8: Frequently Asked Questions
Frequently Asked Questions Are all makes of HDTV supported? • The HDMI standards imply that complete interoperability should be possible but some products may implement these rules slightly differently to others leading to complications with some combinations. See the specification page for the list of resolutions and frame rates supported. - Page 9 Will the units allow gaming? • The HD Video Streamer is not optimised for fast moving gaming applications. The encoding and compression techniques used are targeted at efficient and stable video transmission which introduces a small latency (delay) between the source and the remote location.
- Page 10 Safety Points Please read these instructions fully. Do not operate near water or where there is a risk of spilling any liquids into the units. Remove the units from the power supply or wall plug before cleaning. Clean with a dry cloth. Do not place near any heat source.
- Page 11 This equipment incorporates High-Definition Multimedia interface (HDMI™) technology. HDMI, the HDMI Definition Multimedia interface (HDMI™) technology. HDMI, the HDMI logo and High Definition Multimedia Interface are all trademarks or registered trademarks of HDMI logo and High Definition Multimedia Interface are all trademarks or registered trademarks of HDMI licensing, LCC.
- Page 12 Unit Serial Numbers Transmitter unit Receiver Unit Date of Purchase Useful Links Company Websites www.globalinvacom.com • www.provision-comm.com • GIP-WHDMI-QSG V1.00 Copyright GI Provision Ltd 2012 Page 12...
