LPV1200 DUO SYSTEM
LPV1200 DUO SYSTEM
Instruction Manual
Ver. 1 1/28/14, 2/28/14 Brian Jennett
Page 0 of 40

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LPV1200 DUO SYSTEM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Drylam LPV1200 DUO SYSTEM

Summary of Contents for Drylam LPV1200 DUO SYSTEM

  • Page 1 LPV1200 DUO SYSTEM LPV1200 DUO SYSTEM Instruction Manual Ver. 1 1/28/14, 2/28/14 Brian Jennett Page 0 of 40...

  • Page 2: Foreword

    LPV1200 DUO SYSTEM Please carefully read this manual before operating! NOTES: Page 1 of 40...

  • Page 3: Table Of Contents

    LPV1200 DUO SYSTEM Dear User; Thank you for choosing the LPV1200 DUO SYSTEM. This laminator can give you some technical services with its long-lasting reliable multiple functions. It can help you enjoy its various perfect laminating features and achieve good-quality re-making texts and drawings with simple operations.

  • Page 4: Table Of Contents

    LPV1200 DUO SYSTEM Contents Foreword Table of Contents Applications & Characteristics of the LPV1200 DUO SYSTEM Requirements for Use Safety Indications Sketches of the main machine Control Panel Specification Removal & Installation of Laminator Removal of the Stand from the Crate...

  • Page 5: I Applications & Characteristics Of The Lpv1200 Duo System

    LPV1200 DUO SYSTEM Ⅰ. Applications & Characteristics of the LPV1200 DUO SYSTEM The LPV1200 DUO SYSTEM laminator was designed for lamination of large scale computer text, drawings and prints. The DUO will perform cold laminating, hot laminating and plastic packaging. “1200” refers to the maximum width (in mm) of the machine.
  • Page 6 LPV1200 DUO SYSTEM Ⅱ. Requirements for Uses  This machine should be used in ambient temperatures of 50°F to 105°F. Avoid high temperatures and humidity.  Storage and transportation temperatures: -68°F - 140°F  Ambient humidity: 40%—70%. Perfect humidity: 55%.

  • Page 7: Safety Indications

    LPV1200 DUO SYSTEM Ⅲ. Safety Indications  Before operation ensure that the voltage of power supply you are using matches rated working voltage  The power supply wires should be connected with air switches with leakage protection and the rated current should be 20A or more.
  • Page 8 LPV1200 DUO SYSTEM Ⅲ. Safety Indications (cont’d)  During the laminating operations, please don’t place anything except materials to be laminated on the machine. Any accidental entanglements will cause damage to rollers or the machine.  Do not attempt to laminate metal materials or other hard objects. Do not put sharp objects into the machine (for example, tools, rulers and knives, etc.).
  • Page 9 LPV1200 DUO SYSTEM Ⅳ. Sketches of the machine （Figure 1） Page 8 of 40...

  • Page 10: Sketches Of The Main Machine

    LPV1200 DUO SYSTEM Left cabinet Emergency stop switch Linkage shaft for pressure adjustment Backing paper mandrel Front guard shield Right cabinet Pressure adjust hand wheel of front roller Control panel Pressure adjust hand wheel of rear roller Stand Mandrel shaft...

  • Page 11: Control Panel

    LPV1200 DUO SYSTEM Ⅴ. Control Panel Power Indicator Upper Roller Heat Indicator Lower Roller Heat Indicator Temperature adjustment for Upper Roller Temperature adjustment for Lower Roller Motor Direction Switch Speed Control Adjustment Continue/Step Switch Temperature Display For Lower Roller Temperature Display for Upper Roller ●...
  • Page 12 LPV1200 DUO SYSTEM ● Precautions during operations: When the machine is stopped by the electric eye there is a 5 second waiting period for the motor to start again. Please turn to “STEP” first after 5 seconds and then turn to “Continuous” again to restore motor operation.

  • Page 13: Specification

    LPV1200 DUO SYSTEM Ⅵ. Specifications Specifications Type LPV1200 DUO SYSTEM Maximum Laminating Width 47.2” Maximum Lift of the rollers 1.2” Speed Adjustment Range 0.3 ～ 12.5 ft/min Temperature Adjustment Range 86°F ～ 266°F Rated operating voltage and frequency AC240V 60Hz...

  • Page 14: Vii. Removal & Installation Of Laminator

    LPV1200 DUO SYSTEM VII. Removal & Installation of Laminator (I). Removal of the Machine from the Crate （Please refer to figure 3） （ ） Figure 3 Upper cover Rack column The rack shall be unpacked after all bottom plate screws tightening the top box are removed. It is required to lift the whole top box, remove the upper cover fixing the top box and then take out the rack column.
  • Page 15 LPV1200 DUO SYSTEM （ ） Figure 4 Tightening screw Rack column Upper support beam of rack Lower support beam of rack  Place the installed stand aside (on a level ground) for future use. Page 14 of 40...

  • Page 16: (Iii)

    LPV1200 DUO SYSTEM (Ⅲ).Removal of this machine (please refer to figure 5) （ ） Figure 5 Rack support beam Mainframe Feeding roller (module) Feeding roller holder Wood belt fixing the mainframe Pallet of the packing box The laminator is sealed with a plastic housing to prevent dust and moisture.

  • Page 17: (V) Installing Heat Tubes

    LPV1200 DUO SYSTEM Main machine Leveling bending plate Stand ▲ Take Care not to hurt your finger or body while moving the machine and its stand. ▲ Be careful not to injure your foot by the castor wheels. (Ⅴ). Installing Heat Tubes Warning: Do not attempt this with the power on! A.
  • Page 18 LPV1200 DUO SYSTEM supports 5. Replace left and right heater support brackets Screw Rubber cushion Heat tube Support Bracket Roller Page 17 of 40...
  • Page 19 LPV1200 DUO SYSTEM B. Connect electric wires 1. With the tube in place, remove the porcelain inserter, porcelain tube, hex nut and flat washer from both ends 2. Connect the two ends to the electric wire connectors. 3. Replace flat washer, hex nut, porcelain tube and porcelain inserter 4.

  • Page 20: Installation Of Upper Mandrel A Ssembly's And Brackets

    LPV1200 DUO SYSTEM (Ⅵ).Installations of Upper Mandrel Assembly and Brackets ( ): (please Assembly refer to figure 7) （ ） Figure 7 Mandrel (components) Fixing bolts Connecting plate of the mandrel 1．Fix the two connecting plates on the machine with the bolts.

  • Page 21: Preparations Before Starting Up

    LPV1200 DUO SYSTEM VIII. Preparations Before Starting Up  Connecting the power supply, turn on the machine, and you can choose function switches according to practical needs.  Press Cold for cold laminating work.  Press Hot for hot laminating work.
  • Page 22 LPV1200 DUO SYSTEM (Figure 8) Shaft of the mandrel Cold film with lining paper Paper tube Positioning sleeves Adjust nuts Fastening screws of positioning collar Positioning collar  Installations and Adjustment Methods for backing Paper Roller (please refer to Figure 9) 1.
  • Page 23 LPV1200 DUO SYSTEM 4. If the paper tube can’t be turned with the rotation of backing paper roller, the supporting plates should be adjusted so that the rotation of paper tube would follow the movement of the backing paper roller.

  • Page 24: Adjustment Of Roller Pressure

    LPV1200 DUO SYSTEM Ⅸ. Adjustment of Roller Pressure With the inner driving devices, the pressure-adjust hand-wheel rotates and brings along with the up and down movements of upper roller, thus the pressure between the rollers can be adjusted. When the pressure hand-wheel of front roller turns clockwise, the upper roller will go down and the pressure will increase;...

  • Page 25: Film Tension Adjustment

    LPV1200 DUO SYSTEM Ⅹ. Film Tension Adjustment A .Position adjustment A friction clutch is installed at the end of rear lower rubber roller shaft in the left cabinet. Its end nut can be adjusted to regulate film tension. As shown in the following figure: Compression nut B.

  • Page 26: Operation Instructions & Steps

    LPV1200 DUO SYSTEM Ⅺ.Operation instructions and steps This type of machine can carry out single-side cold and hot lamination work and double-side lamination work as well. Sheet and roll films can be used. (I). How To Do Continuous Cold Laminating Work:...
  • Page 27 LPV1200 DUO SYSTEM Front working penal Front upper roller Pressure-adjust linkage shaft Upper guiding roller Film Backing paper roller Backing paper Mandrel shaft Rear upper roller Rear lower roller Lining paper roller (for double side adhesive film lamination) Lining paper (double-side adhesive film)

  • Page 28: (Ii) How To Do Continuous Single Side Laminating Work With

    LPV1200 DUO SYSTEM between the two rollers. After that, press “Continue” and let go the pedal switch to complete the work. Note: ▲ The text and drawings should be fed between the upper and lower rollers with trimness and the front end of the text and drawings should be fed in at the same time so as to avoid crinkling the text and drawings during the operation.
  • Page 29 LPV1200 DUO SYSTEM the pressure-adjust hand-wheel to the lost motion----that means to the most loosen status of pressure. Note: in view that the rollers will change the pressures due to the thermal inflation, thus the temperature on the roller surface should be adjusted until certain temperature is reached, that is: put the hand-wheel at lost motion----that means to the most loosen status.
  • Page 30 LPV1200 DUO SYSTEM Front lower roller Front working panel Front upper roller Pressure-adjust linkage shaft Upper guide roller Thermo-sensitive film Film mandrel Rear upper roller Rear lower roller Lining paper roller Lining paper Lower guide roller 3. Functions Set-up: 1) Press heating switch when high temperature is needed.;...
  • Page 31 LPV1200 DUO SYSTEM 140°F. 5. Step the pedal switch and feed text and drawings in between the two rollers. Please press the switch to “Continue” and loosen the pedal switch to complete the continuous laminating process. ▲Feed text and drawings in between the upper and lower rollers while keep text and...

  • Page 32: (Iii)

    LPV1200 DUO SYSTEM (III) How To Do Continuous Single Side Laminating Work With Thermal Sensitive Adhesive Film: Front working penal Front upper roller Pressure-adjust linkage shaft Upper guide roller Upper thermo-sensitive film Upper film roller Rear Upper roller Rear lower roller...
  • Page 33 LPV1200 DUO SYSTEM 1) After having placed two rolls of adhesive film into the front and rear brackets, pull the adhesive films with hands until feeling a certain resistance. 2) Trim the upper and the lower films at the left and the right sides. If there are errors, you should turn the adjustment collars to move the film roll to either the left or the right.

  • Page 34: Common Solutions To Quality Issues

    LPV1200 DUO SYSTEM Step the pedal switch to feed text and drawings evenly in between the two rollers. Please press the button to “Continue”, let off your foot to complete the laminating process. ▲ The two sides of edges of text and drawings should be vertical with rollers, so as Note: to avoid declining during operations.

  • Page 35: (I) Checking Methods And Adjustment Of Even Pressure

    LPV1200 DUO SYSTEM methods and adjustment for pressure balance of rollers: (I) Checking The adjustment of the space between the two rollers will be completed during operations. While not in use, the asymmetry of the space between the two rollers is caused by the space of screw threads of journey adjustment structures, which does not affect the normal uses.
  • Page 36 LPV1200 DUO SYSTEM Linkage axis Transverse taper gear Pressure-adjust hand wheel Pressure Adjust bracket Pressure adjustment blocks Lower roller Upper roller Pressure-adjust orientation axis Fore-and-aft taper gear (II) Before make any repairs, if the following defaults arise, please try the following...

  • Page 37: (Ii) Troubleshooting

    LPV1200 DUO SYSTEM steps first: Malfunction Causes Settlements Indications ● Connecting with the power ● No connectivity with power supply supply ● Fuse tubes blow ● Replace the fuse tubes ● Pressure is too high Rollers don’t work. ● Reduce the pressures ●...
  • Page 38 LPV1200 DUO SYSTEM The film rolls are ● Increase the friction force on ● The friction force of the roll is too small loosening during the materials roll operation Backing paper is ● The friction force on backing paper is ●...

  • Page 39: Maintenance And Repairs

    LPV1200 DUO SYSTEM XIII. Maintenance & Repairs  Periodic cleaning should be performed after a certain period of time, particularly the front rollers which should be cleaned frequently. Otherwise, the quality of lamination will be adversely affected. Before cleaning the machine, shut off the power and allow the machine to cool.

  • Page 40: After Sale Service

    LPV1200 DUO SYSTEM ⅩⅣ: After sale service Thanks for choosing our products. If you have any problem during operations, please contact your dealers/distributor or the DryLam Tech-Line. Products and specifications are subject to changes without prior notice. Page 39 of 40...
