- Page 1 OPERATOR’S MANUAL BRAVO 21 Mower Model: 21- 102 BBC - Honda 21- 201 BBC - Kawasaki Operator’s Manual Read these instructions carefully and make sure you understand them before using the BRAVO 21. P/N 990010-3 Rev. 04/2013...
-
Page 2: I Ntroduction, Personal Safety
fi nd a dealer close to you by searching the internet at: www.ybravo.com Ybravo.com, will willingly be of service and provide you with advice as well as help you to use your product both effi ciently and safely. Additional manuals are available at NO CHARGE and can also be obtained on the internet site. -
Page 3: Registration Of The Product
The lawn mower model and serial number as well as the engine model number, engine type and serial number are critical in order to obtain the correct service parts. Ybravo.com has service parts available as listed in the spare parts list. All engine parts are distributed through the Honda or Kawasaki engine dealer networks. -
Page 4: Table Of Contents
17. Always wear approved personal safety equipment such as hearing protection, eye protection, and protective gloves when operating machine. 18. See manufacturer’s instructions for proper operation and installation of accessories. Only use accessories approved by Ybravo.com or the engine manufacturer. -
Page 5: Lawn Mower Safety
8. Check grass catcher components and the rear discharge IV. SAFE HANDLING OF GASOLINE: door frequently and replace only with Ybravo.com original To avoid personal injury or property damage, use extreme care parts when necessary. -
Page 6: Decals And Locations
DECALS AND LOCATIONS These labels warn you of potential hazards that can cause serious injury. Carefully read and understand them. If a label comes off or becomes hard to read, contact Ybravo.com immediately for a free replacement. Part #: 201158-1 BBC Version... -
Page 7: Assembly - Setup
Bravo 21 Operator’s Manual. NOTICE: If you are missing any of these items or if you are unsure of how to properly assemble this mower please contact Ybravo. com by e-mail or by phone: 888.ybravo1 (888.927.2861) 10 mm 10 mm... -
Page 8: Recommended Engine Oil
ASSEMBLY - SETUP STEP 6 STEP 4 To assist with the installation of the drive cable to the lower Insert the throttle cable inside the left handle tube. Install the control bar push the control bar past the spring lock (1) that cable into the throttle control. -
Page 9: Recommended Fuels
ASSEMBLY - SETUP STEP 8 Honda Engine NOTICE: Verify that the throttle control is adjusted properly as follows: The engine speed should preferably be checked and verifi ed - Move the throttle control to the Full Throttle position. with a tachometer. Normal full throttle speed of the engine should be adjusted to 3100 to 3200 RPM. -
Page 10: Controls And Operation
NEVER insert a hand or any other object in the (Step 8) on Page 9. grass discharge chute to verify that the blade has A Ybravo.com dealer can typically also verify the correct full stopped. throttle adjustment. The engine speed should be 3100 to 3200 RPM without the blade engaged (no load). - Page 11 1 With a grass catcher in place when the lower control bar is approximately 1 inch (25mm) to An original equipment Ybravo.com catcher has been tested to 1.5 inch ( 40 mm) away from the handle be used with this mower. It is important to always inspect the catcher for deterioration.
-
Page 12: Maintenance
MAINTENANCE Maintenance - Procedures Service Interval Before each use Check the engine oil level. Check the operation and integrity of the BBC control system (see page 10). Inspect the mower blade for wear or damage. Inspect the cables for any wear or damage. Inspect the grass catcher for any damage. -
Page 13: Blade Maintenance
2. Turn lawn mower on its right side. (Make sure air fi lter and always be balanced using a blade balancing device. A blade carburetor are up). balance tool is available from Ybravo.com or most lawn and 3. Use a wood block between blade and mower deck to garden dealers, and hardware stores. - Page 14 NOTES...
-
Page 15: Warranty
To obtain the benefit of this warranty, the product believed to be defective must be delivered to an authorized Ybravo dealer in a timely manner, no later than thirty (30) days from date of the operational problem or failure. The product must be delivered at the owner’s expense.
