Bosch LHM 0606/10 Instructions For Use

Technical performance data acc. to IEC 268-5
Max. power
Rated power (PHC)
Sound pressure level at 6W/1W
(at 1kHz, 1 m)
Effective frequency range (-10 dB)
Opening angle
(at 1 kHz/4 kHz, -6 dB)
Rated voltage
Rated impedance
Speaker size
Ambient temperature range
Safety
Dimensions (dia x max. depth)
Mounting cut-out dia.
Colour
Weight
Dimensions (dia x max. depth)
Certified B15
Colour
Weight
LHM 0606/10
9 W
6 W (6-3-1.5 W)
92 dB/ 84 dB (SPL)
80 Hz to 18 kHz
175˚ / 55˚
100 V
1667 ohm
6"
-25˚ to +55˚C
acc. to EN 60065
199 x 70.5 mm
165 mm
White (RAL 9010)
620 g
LBC 3080/01
147 x 87 mm
acc. to DIN 4102
White (RAL 9010)
360 g
Black
COMMON 0
Red
6W
PHASE
Blue
3W
Yellow
1.5W
Circuit diagram
10dB
90dB
31.5 63 125 250
Frequency response
500 1000 2k 4k 8k 16k 20k
(Hz)
