Page 1: Power Amplifiers
POWER AMPLIFIERS FL400.2-F1, FL800.4-F1, FL1200.1-F1... -
Page 2: Owners Manual
OWNERS MANUAL Congratulations on purchasing your FLI amplifier. Please read this manual in order to fully understand how to get the best results from this product and ensure that all advice on how to look after the product is followed. Thank you for buying FLI, we hope you enjoy listening to your product as much as we enjoyed creating it. -
Page 3: Limited Warranty
FLI. Graphics and logos are trademarks or trade dress of FLI audio or its subsidiaries. FLI’s trademarks and trade dress may not be used in connection with any product or service that is not FLI’s, in any manner that is likely to cause confusion among customers or in any manner that disparages or discredits FLI. -
Page 4: Mounting Guidelines
MOUNTING GUIDELINES Your FLI amplifier is designed with a swift installation routine in mind. Please mount the amplifier in a dry location on a solid surface. NEVER mount the amplifier upside down as this will cause the amplifier to over heat and will eventually damage the amplifier. -
Page 5: Ground Cable
CONNECTIONS Length of Run Current demand 0 – 4 Ft 4 – 7 Ft 7 – 10 Ft 10 – 13 Ft 13 – 16 F 16 – 19 Ft 19 – 22 Ft 22 – 28 Ft 0–20 amps 20–35 amps 35–50 amps 50–65 amps... - Page 6 FL400.2-F1 TERMINALS AND CONNECTIONS 1. Low level input For connection to any source (headunit) with a low level output. This is your RCA output from the source (headunit) 2. Gain control This control is used to match the input signal of the source to the amplifier. See the setup guide for more details.
- Page 7 FL400.2-F1 STEREO WIRING CONFIGURATION 2Ω minimum impedance per channel BRIDGED WIRING CONFIGURATION 4Ω minimum impedance bridged...
- Page 8 FL800.4-F1 TERMINALS AND CONNECTIONS 1. Power LED If the amplifier is operating normally the green LED will illuminate. 2. Front crossover frequency control This control is used to set the HPF crossover frequency for the front amplifier channel. The frequency is adjustable between 50Hz and 300Hz. 3.
- Page 9 FL800.4-F1 4 CHANNEL WIRING CONFIGURATION 2Ω minimum impedance per channel 2Ω minimum impedance per channel 3 CHANNEL WIRING CONFIGURATION 2Ω minimum impedance per channel 4Ω minimum impedance bridged...
- Page 10 FA1200.1 TERMINALS AND CONNECTIONS 9 10 1. Low level input For connection to any source (headunit) with a low level output. This is your RCA output from the source (headunit) 2. High level input For connection to the speaker output of your source (head unit). This is to be used if the source (head unit) does not have a low level output.
- Page 11 FA1200.1 SINGLE SUBWOOFER WIRING CONFIGURATION 2Ω minimum impedance DUAL SUBWOOFER WIRING CONFIGURATION 2Ω minimum impedance total...
-
Page 12: Setup Guide
SETUP GUIDE To correctly set the gain control of the amplifier to match that of the source (headunit) use the following setup routine: • Turn the gain control to minimum on the amplifier. • Ensure the bass boost is set to 0 dB. •... -
Page 13: Specifications
SPECIFICATIONS MODEL: FL400.2-F1 FL800.4-F1 FL1200.1-F1 20 amp 25 amp x 2 25 amp x 2 FUSE RATING: MAX POWER: 400 watts 800 watts 1200 watts 2 x 80 watts RMS 4 x 80 watts RMS 4Ω STEREO: 2Ω STEREO 2 x 100 watts RMS 4 x 100 watts RMS 4Ω... - Page 14 UK TECHNICAL ENQUIRIES Call 09067031420 Calls cost 50p per minute. Call costs correct at date of publication (01/02/12) Hours of business 9.00am - 5.30pm GMT Monday - Friday. All calls are recorded for training purposes. MIDBASS Distribution PO Box 11000 B75 7WG INTERNATIONAL TECHNICAL ENQUIRIES For international technical support please contact the distribution agent for your country.
- Page 15 NOTES:...
- Page 16 WWW.FLIAUDIO.COM www.facebook.com/fliaudio...
