MA1111-EA
•
Your watch may differ somewhat from the one shown in the illustration.
Day
Hour hand
Minute hand
Crown
(Normal position)
Second hand
To set the day
1.
Pull the crown out to the first click.
2.
Set the day by rotating the crown.
3.
Push the crown back in to the normal position.
•
Avoid changing the date setting while the current time is between 9:00 p.m. and
3:00 a.m.
Using the Stopwatch
Stopwatch minute hand
Stopwatch second hand
The stopwatch lets you measure elapsed time up to 59 minutes, 59.95 seconds.
To measure elapsed time
1.
Press
A to start the stopwatch.
2.
Press
A to stop the stopwatch.
•
You can resume the measurement operation by pressing
•
The 1/20-second hand stops moving after the first 30 seconds, but timing
continues internally. The 1/20-second hand will move to the current timing
value when the stopwatch is stopped.
3.
Check the elapsed time.
•
The example below shows an elapsed time of two minutes, 24.15 seconds.
Stopwatch minute hand
[2 minutes]
•
Press
B to reset the stopwatch.
This will enter the Timekeeping Mode.
Notes:
•
Do not try to perform stopwatch operations while the crown is pulled out either
to the first or second click. If you try to press a button, you might accidentally
cause the crown to rotate and change the current time or day setting.
•
If the starting positions of the stopwatch second hand and 1/20 second hand
become misaligned, use the following procedures to adjust the positions of the
hands so they point to 12 o'clock when the stopwatch is reset.
To adjust the positions of the stopwatch hands
1.
Press
B to reset the stopwatch, and check the stopwatch second hand,
1/20 second hand, and minute hand. They all should be at 12 o'clock.
2.
To adjust the hands, pull out the crown to the second click.
3.
Press
A to move the stopwatch second hand to 12 o'clock.
•
Holding down
A will move the second hand at high speed, until you release
the button.
4.
Press
B to move the stopwatch 1/20 second hand to 12 o'clock.
•
Holding down
B will move the 1/20 second hand at high speed, until you
release the button.
5.
After making the adjustments you want, push the crown back in to its normal
position.
6.
Press
B to reset the stopwatch minute hand.
•
Note that pulling the crown out also stops the timekeeping second hand. After
performing the above procedure, you should also adjust the timekeeping setting.
For a watch with an elapsed time bezel
■
Rotate the elapsed time bezel to align the
minute hand.
After certain amount of time elapsed, read the graduation on
the elapsed time bezel which the minute hand points to.
The elapsed time is indicated.
•
Some water resistant models are equipped with a screw
lock crown.
•
With such models, you must unscrew the crown in the
direction noted in the illustration to loosen it before you can
pull it out. Do not pull too forcibly on such crowns.
•
Also note that such watches are not water resistant while
their crowns are loosened. Be sure to screw the crowns
back in as far as they will go after making any setting.
Operation Guide 5268
To set the time
1.
When the second hand is at
12 o'clock, pull out the crown
to the second click to stop it.
2.
Set the hands by rotating the
crown. Rotate the crown to
First click
move the hands clockwise.
(Setting Day)
Move the minute hand four or
five minutes past the time you
want to set, and then back it
up to the proper setting.
Second click
3.
Push the crown back in to
(Setting Time)
the normal position to restart
timekeeping.
Stopwatch 1/20 second hand
*
This hand rotates and
indicates the second count
during the first 30 seconds.
A again.
Stopwatch 1/20 second hand
[.15]
Stopwatch second hand
[24 seconds]
mark with the
Elapsed time bezel
Specifications
Accuracy at normal temperature: ± 20 seconds a month
Display: 3 analog hands (timekeeping hour and minutes, stopwatch seconds),
3 dials (timekeeping seconds, stopwatch minutes and 1/20 seconds), day
Stopwatch function: Measuring capacity: 59'59.95"
Measuring unit: 1/20 second
Measuring mode: Elapsed time
Battery: One silver oxide battery (Type: SR927W)
Approximately 3 years on type SR927W (assuming one stopwatch operation 60 min./day)
