This book has important information for the use and safe operation of this machine. Failure to read
this book prior to operating or attempting any service or maintenance procedure to your Clarke
American Sanders machine could result in injury to you or to other personnel; damage to the machine
or to other property could occur as well. You must have training in the operation of this machine
before using it. If your operator(s) cannot read this manual, have it explained fully before attempting
to operate this machine.
All directions given in this book are as seen from the operator's position at the rear of the machine.
For new books write to: Clarke
Form No. 71073A 4/06
Vacuum 12 Gallon
Operator's Manual
Manual del operador
Manuel de l'utilisateur
®
, 2100 Highway 265, Springdale, Arkansas 72764
EN
English (2 - 6)
ES
Español (8 - 12)
FR
Français (14 - 18)
Advertisement
Chapters
Table of Contents
Related Manuals for Clarke CAV 12
Summary of Contents for Clarke CAV 12
- Page 1 This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting any service or maintenance procedure to your Clarke American Sanders machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well.
-
Page 2: Table Of Contents
Grounding Instructions ..................... 5 Maintenance and Repair ..................6 Troubleshooting ....................... 6 Section II Parts and Service Manual Assembly Drawing #1 ..................... 20 Assembly Drawing #2 ..................... 21 Assembly Drawing #3 ..................... 22 ® Clarke American Sanders Operator's Manual (EN) - CAV 12... -
Page 3: Important Safety Instructions
- Use extra care when cleaning on stairs. - Connect to properly grounded outlet. See “grounding Instructions”. - Do not use unless all filtering elements are present. Clean filtering elements frequently. SAVE THESE INSTRUCTIONS. ® Clarke American Sanders Operator's Manual (EN) - CAV 12 - 3 -... -
Page 4: Specifications
25 25/32 Weight (lbs.) INTRODUCTION AND INSTRUCTIONS The CAV 12 comes fully assembled. It is specifically designed for dry pick-up of fine dust made from the grindings of wood or gypsum. Intalled are three filtering elements (see figure 1). The... -
Page 5: Grounding Instructions
WARNING: If you use an extension cord, use an extension cord with minimum wire size 14 AWG. Do not use an extension cord longer than 50 feet. Do not join two extension cords. ® Clarke American Sanders Operator's Manual (EN) - CAV 12 - 5 -... -
Page 6: Maintenance And Repair
CAUTION: Before cleaning and servicing the machine, always remove the power cord. Carry out only maintenance operations described in these operating instructions. Use only original Clarke service parts. CAUTION: Do not make any technical modifications to the machine. Your safety... - Page 7 ENGLISH NOTES ® Clarke American Sanders Operator's Manual (EN) - CAV 12 - 7 -...
- Page 8 Este manual contiene información importante acerca del uso y la seguridad de la máquina. Si no lee el manual antes de utilizar su máquina Clarke American Sanders o de intentar realizar los procedimientos de reparación o mantenimiento de la misma, usted o el resto del personal podrían sufrir lesiones;...
-
Page 9: Instrucciones De Seguridad Importantes
Conecte a una toma de corriente adecuadamente puesta a tierra. Lea las Instrucciones para conexión a tierra. No utilice a menos que estén presentes todos los elementos filtrantes. Limpie los elementos filtrantes de manera frecuente GUARDE ESTAS INSTRUCCIONES. ® Clarke American Sanders Manual del operador (ES) - CAV 12 - 9 -... -
Page 10: Especificaciones
25 25/32 Peso (libras) INTRODUCCIÓN E INSTRUCCIONES La máquina modelo CAV 12 viene totalmente ensamblada. Ha sido diseñada para aspiración en seco de polvo fino resultante de pulverización de madera o yeso. Hay tres elementos filtrantes instalados (ver figura 1). Los elementos incluyen el revestimiento interior del depósito... -
Page 11: Instrucciones De Conexión A Tierra
14 AWG. No utilice un cable de extensión que sea más largo de 50 pies. No una dos cables de extensión ® Clarke American Sanders Manual del operador (ES) - CAV 12 - 11 -... -
Page 12: Mantenimiento Y Reparaciones
3. Elemento filtrante obstruido No hay potencia de aspiración 1. Vacíe el depósito. 1. Depósito lleno (el interruptor de flotación durante limpieza bloquea la abertura de aspiración). materiales líquidos. -12- Clarke ® American Sanders Manual del operador (ES) - CAV 12... - Page 13 ESPAÑOL ® Clarke American Sanders Manual del operador (ES) - CAV 12 - 13 -...
- Page 14 La non-lecture de ce manuel avant d’utiliser ou d’entretenir votre machine Clarke American Sanders risque de provoquer un accident ou d’endommager la machine ou son environnement. Vous devez avoir été formé à l’utilisation de cette machine avant de l’utiliser.
-
Page 15: Importantes Instructions De Sécurité
- Brancher sur une prise correctement mise à la terre. Voir "Instructions de mise à la terre". - Ne pas utiliser tant que tous les filtres ne sont pas installés. Nettoyer les filtres fréquemment. CONSERVEZ CES INSTRUCTIONS Clarke ® American Sanders Manuel de l’utilisateur (FR) - CAV 12 - 15 -... -
Page 16: Spécifications
Poids 14 kg INTRODUCTION ET INSTRUCTIONS Le CAV 12 est livré entièrement assemblé. Il est spécialement conçu pour le ramassage à sec de fines poussières provenant du ponçage du bois ou du plâtre. Trois éléments de filtration sont installés (cf. Figure 1). Ces éléments intègrent la Toile de Cuve (pièce référencée 53856A), le... -
Page 17: Instructions De Mise À La Terre
14 AWG. Ne pas utiliser de rallonge d'une longueur de plus de 15 mètres. Ne pas raccorder deux rallonges. ® Clarke American Sanders Manuel de l’utilisateur (FR) - CAV 12 - 17 -... -
Page 18: Maintenance Et Réparation
3. Nettoyer et remettre le filtre en place. 3. Filtre bouché. Absence d'aspiration pen- 1. Vider la cuve. 1. Cuve pleine (le contacteur à flotteur dant le nettoyage par voie condamne l'ouverture permettant humide l'aspiration). -18- Clarke ® American Sanders Manuel de l’utilisateur (FR) - CAV 12... -
Page 19: Parts And Service
Section II Parts and Service (71073A) Page -19- Clarke ® American Sanders Operator's Manual - CAV 12... -
Page 20: Plano De Montaje #1
Assembly Drawing #1 4/06 Ref. Part No. Description 909100084 302000380 302000378 c t i 302000612 c t i 18274 9868 302000382 Hose Hanger (optional accessory) Label 302002531 302000435 ® Page -20- Clarke American Sanders Operator's Manual - CAV 12... -
Page 21: Plano De Montaje #2
Screw, 3.5 x 18 5697 Strap, 3 x 8 x 33 909100138 Screw, 5 x 20 MP 302000490 Filter Element 302000472 Filter Support 302000379 Deflector 61174 Static Strap 61156112 Filter Liner Page -21- Clarke ® American Sanders Operator's Manual - CAV 12... -
Page 22: Plano De Montaje #3
Tank, CAV 12 302000349 Latch 302000682 Caster 909100164 Screw 302000636 Axle 909100085 Screw, 50 x 35 30637A Wheel 53857A Ring, Clamping 53856A Tank Liner 302000527 Filter Bag (optional accessory 5 pcs.) ® Page -22- Clarke American Sanders Operator's Manual - CAV 12... - Page 23 29815 John R. +49 0180 5 37 37 37 (810) 544-6300 ALTO Cleaning Systems (UK) Ltd., Penrith ® American Lincoln / Clarke, Marietta, Georgia 30066 Gilwilly Industrial Estate 1455 Canton Road Penrith (770) 973-5225 Cumbria CA11 9BN +44 1768 868 995 ALTO France S.A.
- Page 24 (b). Return the product to the nearest Clarke American Sanders repair location. Transportation charges to and from the repair location must be prepaid by the purchaser. (c). Clarke American Sanders will repair the product and or replace any defective parts without charge within a reasonable time after receipt of the product.
