Panasonic TH-85PF12U Service Manual

Panasonic TH-85PF12U Service Manual

High definition plasma display
Hide thumbs Also See for TH-85PF12U:
Table of Contents

Advertisement

Quick Links

See also: Installation Manual

TABLE OF CONTENTS

1 Safety Precautions----------------------------------------------- 3
1.1. General Guidelines---------------------------------------- 3
2 Warning -------------------------------------------------------------- 4
2.2. About lead free solder (PbF)---------------------------- 5
3 Service Navigation ----------------------------------------------- 6
3.1. Service Hint ------------------------------------------------- 6
3.2. Applicable signals ----------------------------------------- 8
4 Specifications ----------------------------------------------------10
5 Operating Instructions-----------------------------------------11
6 Service Mode -----------------------------------------------------13
sample data) -----------------------------------------------16
7 Troubleshooting Guide ----------------------------------------17
7.1. Self Check--------------------------------------------------17
7.2. No Power ---------------------------------------------------19
7.3. No Picture --------------------------------------------------19
High Definition Plasma Display
Model No.
GPF12D Chassis
PAGE
7.4. Local screen failure-------------------------------------- 20
8 Service Fixture & Tools --------------------------------------- 21
8.1. Service Stand --------------------------------------------- 21
8.2. SC jig-------------------------------------------------------- 22
9.1. Rear Cover and Board---------------------------------- 23
9.2. Location of Rear Cover screws----------------------- 24
9.3. Removal of HHH-Board -------------------------------- 26
9.4. Removal of HA-Board----------------------------------- 26
9.5. Removal of H5-Board ----------------------------------- 26
9.6. Removal of DS-Board ---------------------------------- 27
9.7. Removal of HX-Board----------------------------------- 27
9.8. Removal of DN-Board ---------------------------------- 28
9.9. Removal of PB-Board----------------------------------- 28
9.10. Removal of D-Board------------------------------------- 28
9.11. Removal of P-Board (MAIN_1) ----------------------- 29
9.12. Removal of P-Board (MAIN_2) ----------------------- 29
9.13. Removal of P-Board (SUB)---------------------------- 29
9.14. Removal of F-Board ------------------------------------ 30
© Panasonic Corporation 2009
Unauthorized copying and distribution is a violation
of law.
Order Number ITD0910145CE
TH-85PF12U
B34 Canada: D10
PAGE

Advertisement

Table of Contents
loading

Related Manuals for Panasonic TH-85PF12U

Summary of Contents for Panasonic TH-85PF12U

  • Page 1: Table Of Contents

    9.12. Removal of P-Board (MAIN_2) ----------------------- 29 7.2. No Power ---------------------------------------------------19 9.13. Removal of P-Board (SUB)---------------------------- 29 7.3. No Picture --------------------------------------------------19 9.14. Removal of F-Board ------------------------------------ 30 © Panasonic Corporation 2009 Unauthorized copying and distribution is a violation of law.
  • Page 2 TH-85PF12U 9.15. Removal of S1-Board and V2-Board ---------------- 30 9.16. Removal of SU-Board ---------------------------------- 31 9.17. Removal of SD-Board ---------------------------------- 31 9.18. Removal of SC-Board----------------------------------- 32 9.19. Removal of SS2-Board -------------------------------- 33 9.20. Removal of SS3-Board -------------------------------- 33 9.21. Removal of SS-Board ----------------------------------- 33 9.22.

  • Page 3: Safety Precautions

    TH-85PF12U 1 Safety Precautions 1.1. General Guidelines 1. When conducting repairs and servicing, do not attempt to modify the equipment, its parts or its materials. 2. When wiring units (with cables, flexible cables or lead wires) are supplied as repair parts and only one wire or some of the wires have been broken or disconnected, do not attempt to repair or re-wire the units.

  • Page 4: Warning

    TH-85PF12U 2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensi- tive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor “chip”...

  • Page 5: About Lead Free Solder (Pbf)

    TH-85PF12U 2.2. About lead free solder (PbF) Note: Lead is listed as (Pb) in the periodic table of elements. In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder. The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu).

  • Page 6: Service Navigation

    TH-85PF12U 3 Service Navigation 3.1. Service Hint...
  • Page 7 TH-85PF12U Board Name Function Board Name Function Digital Signal Processor, Microcomputer Power switch Format Converter, Plasma AI Processor C1 (upper) Data drive (1) (upper) Sub-Field Processor C2 (upper) Data drive (2) (upper) Slot Interface (Audio / Video / Sync Input Switch),...

  • Page 8: Applicable Signals

    TH-85PF12U 3.2. Applicable signals...
  • Page 9 TH-85PF12U...

  • Page 10: Specifications

    TH-85PF12U 4 Specifications Power Source 120 V AC, 50/60Hz Power Consumption Power on 1250 W Stand-by condition Save OFF 1.0 W, Save ON 0.5 W Power off condition 0.2 W Plasma Display panel Drive method: AC type 85-inch, 16:9 aspect ratio 74.3"...

  • Page 11: Operating Instructions

    TH-85PF12U 5 Operating Instructions...
  • Page 12 TH-85PF12U Option Menu for GPF12D series GPF12D chassis series have special function and operation setting facility called Option Menu. This Option Menu is useful for special function required customers. This should be set at the installation stage. Option menus default setting...

  • Page 13: Service Mode

    TH-85PF12U 6 Service Mode 6.1. CAT (Computer Aided Test) mode To exit the CAT mode, access the ID mode and switch off the main power. 6.1.1. IIC mode Select the IIC mode by Up/Down button on the remote control at the front page of CAT mode and then press the Action button on the remote control.

  • Page 14: Cd Mode

    TH-85PF12U 6.1.2. CD mode Select the CD mode by Up/Down button on the remote control at the front page of CAT mode and then press the Mute button on the remote control more than 3 seconds. Memory data change To exit the CD mode, press the R button on the remote control.

  • Page 15: Ms Mode

    TH-85PF12U 6.1.4. MS mode Select the MS mode by Up/Down button on the remote control at the front page of CAT mode and then press the Mute button on the remote control more than 3 seconds. To exit the MS mode, press the R button on the remote control.

  • Page 16: Iic Mode Structure (Following Items Value Is Sample Data)

    TH-85PF12U 6.2. IIC mode structure (following items value is sample data)

  • Page 17: Troubleshooting Guide

    TH-85PF12U 7 Troubleshooting Guide 7.1. Self Check 7.1.1. Display Indication 1. Self-check is used to automatically check the bus line controlled circuit of the Plasma display. 2. To get into the Self-check mode, press the volume down button on the customer controls at the bottom of the set, at the same time pressing the OFF-TIMER button on the remote control, and the screen will show.

  • Page 18: Power Led Blinking Timing Chart

    TH-85PF12U 7.1.2. Power LED Blinking timing chart 1. Subject Information of LED Blinking timing chart. 2. Contents When an abnormality has occurred to the unit, the protection circuit operates and resets to the stand by mode. At this time, the defective block can be identified by the number of blinks of the Power LED on the front panel of the unit.

  • Page 19: No Power

    TH-85PF12U 7.2. No Power First check point There are following 3 states of No Power indication by power LED. 1. No lit. 2. Green is lit then turns red blinking a few seconds later. 3. Only red is lit. 7.3.

  • Page 20: Local Screen Failure

    TH-85PF12U 7.4. Local screen failure Plasma display may have local area failure on the screen. Fig - 1 is the possible defect P.C.B. for each local area. Fig - 1...

  • Page 21: Service Fixture & Tools

    TH-85PF12U 8 Service Fixture & Tools 8.1. Service Stand When conducting repairs and servicing, install the Plasma Display to the Service Stand. Part number: TZSA07021 Installation of plasma display: 1. Lock 2 casters. 2. Check that the Alignment bar is set to the Service Stand.

  • Page 22: Sc Jig

    TH-85PF12U 8.2. SC jig Purpose: To find the failure board (SC or SU/SD) when the power LED is blinking 7 times. SC jig: Jumper connector to connect to SC50 connector on SC board Part number: TZSC09187 How to use: Caution: Remove SC jig from SC board after inspection.

  • Page 23: Disassembly And Assembly Instructions

    TH-85PF12U 9 Disassembly and Assembly Instructions • To disassemble P.C.B., wait for 10 minute after power was off for discharge from electrolysis capacitors. • marks indicate screw positions. 9.1. Rear Cover and Board Rear Cover required to remove for each board exchange.

  • Page 24: Location Of Rear Cover Screws

    TH-85PF12U Board Name Rear Cover HA-Board Unnecessary DN-Board HHH-Board Unnecessary 9.2. Location of Rear Cover screws 9.2.1. Removal of Rear Cover ( A ) 1. Remove Eye Bolt Covers M12.
  • Page 25 TH-85PF12U Rear Cover ( C ). 2. Remove screws (×24 ) and then remove the Rear Cover ( A ). 9.2.4. Removal of Rear Cover ( D ) 9.2.2. Removal of Rear Cover ( B ) 1. Remove Eye Bolt Covers M12.

  • Page 26: Removal Of Hhh-Board

    TH-85PF12U 3. Remove 3 screws (F) and then remove HA-Board. 2. Remove screws (×21 ) and then remove the Rear Cover ( D ). 9.5. Removal of H5-Board 9.3. Removal of HHH-Board 1. Remove 4 screws (A) and then remove the HHH Terminal Block.

  • Page 27: Removal Of Ds-Board

    TH-85PF12U 9.6. Removal of DS-Board 8. Remove 3 screws and then remove DS-Board. 1. Remove the HA Terminal Block and the HHH Terminal 9.7. Removal of HX-Board Block. (Refer to Removal of HA-Board and HHH-Board) 2. Remove H5-Board Block. (Refer to Removal of H5-Board) 3.

  • Page 28: Removal Of Dn-Board

    TH-85PF12U 9.8. Removal of DN-Board 2. Remove 4 screws and then remove PB-Board. Check that no bright points appears by Ve Life adjustment after both D and DN board exchange. 9.10. Removal of D-Board Check that no bright points appears by Ve Life adjustment after both D and DN board exchange.

  • Page 29: Removal Of P-Board (Main_1)

    TH-85PF12U 9.12. Removal of P-Board (MAIN_2) 5. Remove 4 screws and then remove D-Board. 1. Disconnect the connectors (CM1, CM2, CM3, CM4, P6, P11, P35). 9.11. Removal of P-Board (MAIN_1) 2. Remove 3 screws ( ) and then remove P-Board protect spacers.

  • Page 30: Removal Of F-Board

    TH-85PF12U 9.15. Removal of S1-Board and V2- 3. Remove 9 screws and then remove P-Board (SUB). Board 9.14. Removal of F-Board 1. Remove 1 screw ( ). 2. Remove 1 screw ( ) and then remove the Side Power Unit.

  • Page 31: Removal Of Su-Board

    TH-85PF12U 9.15.2. Removal of V2-Board 1. Remove 2 screws (L). 2. Remove 1 screw (M) and then remove the Side Power SW Cover. 3. Disconnect the connector (V15) and then remove V2- Board. 4. Remove 2 hooks and then remove the 5 Range Button from V2-Board.

  • Page 32: Removal Of Sc-Board

    TH-85PF12U 2. Remove the flexible cables from the connectors (SD1, 1. Remove the Side Power Unit. SD2, SD3, SD4, SD5, SD6, SD11). (Refer to Removal of S1-Board and V2-Board ) 2. Remove 6 screws and then remove Nuts For M12 Eye Bolt (side).

  • Page 33: Removal Of Ss2-Board

    TH-85PF12U 9.20. Removal of SS3-Board 6. Disconnect the connector (SC2). 7. Remove the flexible cable from the connector (SC20). 8. Remove 9 screws and then remove SC-Board. 1. Disconnect the connector (SS32). 2. Remove the flexible cables from the connectors (SS59, SS60, SS61, SS62).

  • Page 34: Removal Of Fan

    TH-85PF12U 3. Remove 13 screws and then remove SS-Board. 2. Remove 16 screws and then remove the Fan Blocks (1, 2, 3, 4). 3. Remove 8 screws and then remove the Fan (A, B). 9.22. Removal of Fan 4. Remove 8 screws and then remove the Fan (C, D).

  • Page 35: Removal Of C1-Board (Upper)

    TH-85PF12U 8. Stick the Fan Sponge around the Fan. 9.24. Removal of C2-Board (upper) Note: The Fan Sponge is not re-usable. Please use a new one when Fan exchange. 9.23. Removal of C1-Board (upper) 1. Remove the Eye Bolt (M12).

  • Page 36: Removal Of C3-Board (Upper)

    TH-85PF12U 9.25. Removal of C3-Board (upper) 2. Remove the flexible cable from the connector (C40). 3. Remove 8 screws ( ) and then remove the flexible cables from the connectors (CA13, CA14, CA15, CA16). 1. Remove the Rear Cover Fixing Metal (upper_center).

  • Page 37: Removal Of C2-Board (Lower)

    TH-85PF12U 9.29. Removal of C3-Board (lower) 4. Remove 6 screws ( ) and then remove C1-Board (lower). 9.28. Removal of C2-Board (lower) 1. Remove the Rear Cover Fixing Metal (lower_center). (Refer to Removal of C2-Board (lower)) 2. Remove the flexible cables from the connectors (C30, C31, C32).

  • Page 38: Removal Of Ac Cord

    TH-85PF12U 2. Remove the flexible cable from the connector (C40). 3. Remove 8 screws ( ) and then remove the flexible cables from the connectors (CA13, CA14, CA15, CA16). 4. Remove 6 screws ( ) and then remove C4-Board (lower).
  • Page 39 TH-85PF12U 9.32.1. Removal of Front Glass 9.32.2. Removal of V1-Board and V3-Board 1. Remove 40 screws and then remove the Fixed Angles (left, right, top, bottom). 2. Remove the Front Glass. 1. Remove 1 screw (N). 2. Disconnect the connector (V1) and then remove V1- Board.

  • Page 40: Removal Of Plasma Display Panel

    TH-85PF12U 4. Remove 16 screws and then remove the Cabinet Corner stopper Metals. Note • The felts are parts which cannot be recycled. Please use the new article when you exchange the Cabinet. 9.33. Removal of Plasma Display Panel The C1 (upper, lower), C2 (upper, lower), C3 (upper,...
  • Page 41 TH-85PF12U 9. Remove 4 screws and then remove the Cabinet Position- 4. Remove 1 screw ( ). ing Metals (left, right). 5. Remove 1 screw ( ) and then remove the Side Power Unit. 6. Remove 16 screws and then remove Cabinet Block.
  • Page 42 TH-85PF12U 15. Remove 4 screws and then remove Rear Cover Connect- ing Metal (A). 16. Disconnect the Fan Relay Connectors. 21. Disconnect the connector (H51). 22. Remove 2 screws and then remove H5-Borad Block. 23. Disconnect the connectors (DS4, DS6).
  • Page 43 TH-85PF12U 25. Disconnect the connectors of P-Board (Main_1) (CM1, 33. Disconnect the connectors (P9, P25, P91). CM2, CM3, CM4, CM5, P2). 34. Remove 9 screws and then remove P-Board (SUB). 26. Disconnect the connector of C3-Board (upper) (C35). 27. Remove 3 screws ( ) and then remove P-Board protect spacers.
  • Page 44 TH-85PF12U 41. Remove 3 screws and then remove the AC Cord. 42. Remove 4 screws and then remove the Fan Box. 43. Exchange the Plasma Display Panel.

  • Page 45: Measurements And Adjustments

    TH-85PF12U 10 Measurements and Adjustments 10.1. Adjustment Procedure 10.1.1. Driver Set-up 10.1.1.1. Item / Preparation 10.1.1.2. Adjustments 1. Set Aging pattern (white pattern signal) by IIC mode. 2. Set the picture controls as follows. Adjust driver section voltages. (Refer to the panel data on the Picture menu: Standard Panel Label).

  • Page 46: Initialization Pulse Adjust

    TH-85PF12U 10.1.2. Initialization Pulse Adjust 1. Set Aging pattern (white pattern signal) by IIC mode. 2. Set the picture controls as follows. Picture menu: Standard Picture: +25 Aspect: Full 3. Connect Oscilloscope to TPSC1 and adjust VR16601 for 125V ± 5V.
  • Page 47 TH-85PF12U 10.1.3. P.C.B. (Print Circuit Board) and Plasma Display Panel exchange 10.1.3.1. Quick adjustment after P.C.B. and Panel exchange 1. To remove P.C.B., wait 10 minute after power was off for discharge from electrolysis capacitors. 10.1.3.2. Quick adjustment after P.C.B. exchange Adjust the following voltages with the multimeter.
  • Page 48 TH-85PF12U 3. Check that the Ve Mode is set to 4. 4. Pless R button and then select and display Ve Init. 5. Check TPVE and adjust the volume. 6. Exit the IIC mode. 10.1.7. Ve Life adjustment 10.1.7.1. After exchange both D board and DN board 1.
  • Page 49 TH-85PF12U 10.1.9. Adjustment Volume Location 10.1.10. Test Point Location...

  • Page 50: Adjustment

    TH-85PF12U 10.2. Adjustment 10.2.1. RGB white balance adjustment Instrument Name Connect to Setting • RGB VGA60 W / B pattern PC input User setting: Normal • Color analyzer Panel surface (Picture menu: STANDARD) (Minolta CA-100 or equivalent) Steps Remarks [Condition] Picture Menu: Standard •...
  • Page 51 TH-85PF12U...
  • Page 52 TH-85PF12U 10.2.2. YUV white balance adjustment Instrument Name Connect to Setting • HD(1125/60i) W / B pattern (COMPONENT Output) PC input User setting: Normal • Color analyzer Panel surface (Picture menu: STANDARD) (Minolta CA-100 or equivalent) Steps Remarks [condition] Picture Menu: STANDARD •...
  • Page 53 TH-85PF12U...
  • Page 54 TH-85PF12U...

  • Page 55: Block Diagram

    TH-85PF12U 11 Block Diagram 11.1. Diagram Notes...

  • Page 56: Main Block (1 Of 2) Diagram

    TH-85PF12U 11.2. Main Block (1 of 2) Diagram SLOT INTERFACE/SYNC PROCESSOR/SOUND PROCESSOR AUDIO OUT AUDIO TERMINALS SELECT L/R_1 L/R_2 R LINE OUT AUDIO OUT SOUND MUTE L/R_3 L LINE OUT CONTROL TERMINAL L/R_4 EQUALIZER DIGITAL SIGNAL PROCESSOR SLOT1 +3.3V(P) +5V(P)

  • Page 57: Main Block (2 Of 2) Diagram

    TH-85PF12U 11.3. Main Block (2 of 2) Diagram DATA DATA DATA DATA DATA DATA DATA DATA DATA DATA DATA DATA DATA DATA DATA DATA DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER...

  • Page 58: Block (1 Of 8) Diagram

    TH-85PF12U 11.4. Block (1 of 8) Diagram HDMI INTERFACE HDMI IN A HDMI IN B IC3339 +3.3VREG IC3324 +3.3V EEPROM IC3338 DS12 IC3319 EDID A For HD CONFIG SLOT15V +5VSTB SLOT15V IC3325 IC3328 IC3335 STB5V EEPROM EDID A BUFFER SLOT_IIC2...

  • Page 59: Block (2 Of 8) Diagram

    TH-85PF12U 11.5. Block (2 of 8) Diagram SLOT INTERFACE/SYNC PROCESSOR/SOUND PROCESSOR DS11 +3.3V(P) SLOT3.3V +5V(P) SLOT5V +9V(P) SLOT9V +15V(P) SLOT15V +14V(LAN) LAN14V +5V(STB) STB5V AUDIO IN L AUDIO IN R VD_1 HD_1 PR_1 PR/R PB_1 PB/B SLOT1 S2_1 Q8021-23 RXD_S1...

  • Page 60: Block (3 Of 8) Diagram

    TH-85PF12U 11.6. Block (3 of 8) Diagram SLOT INTERFACE/SYNC PROCESSOR/SOUND PROCESSOR +9V(P) +3.3V(P) AUDIO OUT +3.3V(P) +5V(P) AUDIO OUT TERMINALS +5V(P) TERMINAL +9V(P) L LINE OUT JK8501 +15V(P) LAN+14V R LINE OUT +14V(LAN) +5V(STB) IC804 +1.8V(P) +1.8V A_OA+- - OE+-...

  • Page 61: Block (4 Of 8) Diagram

    TH-85PF12U 11.7. Block (4 of 8) Diagram +2.5V DIGITAL SIGNAL PROCESSOR FACTORY LVDS RECEIVER & TTL PARALLEL +2.5V R/G/B 30bit ASIC OUT A SCW IN A IC4513 A_OA+- - OE+- LVDS PARALLEL A_EA+- - EE+- RECEIVER PI1R0-R9 PI1D(0)-(29) 30bit PI1D(0)-(9)

  • Page 62: Block (5 Of 8) Diagram

    TH-85PF12U 11.8. Block (5 of 8) Diagram Q601,Q602 COLD COLD P(SUB) POWER SUPPLY(SUB) Q610,Q611 Q201,Q202 L604,L605 F201 T201 Vsus RESONANCE Vsus 5A 250V IC202 D254-D257 IC601 COMPARATOR IC201 IC251 Q605-Q608 D206 PC201 Vsus D653,654 PFC CONTROL Vsus POWER Vsus PHOTO COUPLER...

  • Page 63: Block (6 Of 8) Diagram

    TH-85PF12U 11.9. Block (6 of 8) Diagram FORMAT CONVERTER, PLASMA AI PROCESSOR FACTORY IC9500 DISCHARGE CONTROL IC9503 FACTORY FLASH DISCHARGE CONTROL DATA DRIVER CONTROL DATA SCAN CONTROL +2.5V IC9002 IIC3 C21(UPPER) SUSTAIN CONTROL TENP SENSOR +3.3V +3.3V(P) VIDEO DATA +1.2V +3.3V(P)

  • Page 64: Block (7 Of 8) Diagram

    TH-85PF12U 11.10. Block (7 of 8) Diagram SUSTAIN CONNECTOR (UPPER) SCAN DRIVE P(MAIN_1)P2 TPVSUS Vsus TPVSET FACTORY SC50 IC16791 VSET GEN. 16V-F SHUNT REG SUSTAIN DRIVE DC/DC CONVERTER IC16788,89 Q16604 PC16601 TPVSUS CPH2 P(MAIN_2)P11 VF_GND PHOTO COUPLER Vsus Q16001 Q16607...

  • Page 65: Block (8 Of 8) Diagram

    TH-85PF12U 11.11. Block (8 of 8) Diagram PANEL DRIVER PLASMA PANEL PANEL DRIVER PANEL DRIVER PANEL DRIVER IC17201 IC17301 CONTROL DATA CONTROL DATA BUFFER BUFFER VIDEO DATA VIDEO DATA +3.3V(P) +3.3V(P) +3.3V(P) +3.3V(P) DATA DRIVER (UPPER) P(MAIN_1)P35 DATA DRIVER (UPPER)
  • Page 66 TH-85PF12U...

  • Page 67: Wiring Connection Diagram

    TH-85PF12U 12 Wiring Connection Diagram 12.1. Wiring (1)

  • Page 68: Wiring (2)

    TH-85PF12U 12.2. Wiring (2)

  • Page 69: Wiring (3)

    TH-85PF12U 12.3. Wiring (3)

  • Page 70: Exploded View And Replacement Parts List

    Model No. : TH-85PF12U Exploded View...
  • Page 71 Model No. : TH-85PF12U Side Power part location...
  • Page 72 Model No. : TH-85PF12U Cabinet part location...
  • Page 73 Model No. : TH-85PF12U Fan part location...
  • Page 74 Model No. : TH-85PF12U Rear cover location...
  • Page 75 Model No. : TH-85PF12U Print Circuit Board...
  • Page 76 Model No. : TH-85PF12U Flat cable...
  • Page 77 Model No. : TH-85PF12U Packing and Accessories (1)
  • Page 78 Model No. : TH-85PF12U Packing (2)
  • Page 79 Model No. : TH-85PF12U Packing (3)
  • Page 80 Model No. : TH-85PF12U Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks EUR7636070R REMOTE CONTROLER K2CH3YY00002 AC CORD L6FAYYYH0030 FAN UNIT (80) L6FAYYYH0031 FAN UNIT (120) L6FAYYYH0133 FAN UNIT (92) MD85F12S1J PLASMA DISPLAY PANEL TBMA340 PANASONIC BADGE...
  • Page 81 Model No. : TH-85PF12U Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks TMME190 CLAMPER TMME203 CLAMPER TMME228 BAND HOLDER TMME237 CABLE CLAMPER TMME261 CLAMPER TMME291 EDGE SADDLE TMME292 CLAMPER TMME293 CLAMPER TMME307 CLAMPER TMME375 EYE BOLT COVER M12...
  • Page 82 Model No. : TH-85PF12U Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks TSXL860 CABLE (D32-C31) TSXL861 CABLE (D33-C21) TSXL862 CABLE (D34-C31) TSXL863 CABLE (SC20-D20) TSXL864 CABLE (C22-C32) TSXL927 CABLE (SU11-SD11) TTUA2284 REAR COVER C/L ASSY TTUA2285...
  • Page 83 Model No. : TH-85PF12U Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks XYN4+F32FJ SCREW XYN4+F8FJ SCREW XYN5+F15FJ SCREW XZBT6506 POLY BAG (INSTRUCTION BOOK) ETX2MM779AGA CIRCUIT BOARD P(SUB) ETX2MM779MG CIRCUIT BOARD P(MAIN) TNPA4103AB CIRCUIT BOARD PB TNPA4994...
