- Page 1 SPS-28 Space Sweeper (INCLUDES 28G & 28B) Section II Parts and Service Manual Order Parts Here: www.ivie-ent.com/parts Ph:(918)254-5161 (70100B) CLARKE TECHNOLOGY Model SPS-28 Space Sweeper Operator's Manual Page 11...
-
Page 2: Service And Maintenance
Squeeze out excess oil. Install element. Lubrication The Model SPS-28 has one grease fitting on the main drive wheel. Apply two strokes of lubricant (PN 883853) from a grease gun each month. (See Fig. 8) WARNING: To prevent injury and damage, remove the batteries or gasoline before tipping the machine. - Page 3 Install the new strip and assemble the retaining screws and washers. Be sure to install the "V" of each strip in the same relation to the core as its companion strips. (See Fig. 11) CLARKE TECHNOLOGY Model SPS-28 Space Sweeper Operator's Manual Page 13...
-
Page 4: Shop Evaluation Of Chargers
The DC charging current should start in the "normal" range and end in the "finish" range. If the charger is still inoperative after the above checks have been made, call your nearest authorized service center. Page 14 CLARKE TECHNOLOGY Model SPS-28 Space Sweeper Operator's Manual... - Page 5 Steps 5 and 7 and not in the other. Defective diode - test bulb will light up in both Steps 5 and 7. Defective Diode - Test bulb will not light up in either Steps 5 or 7. CLARKE TECHNOLOGY Model SPS-28 Space Sweeper Operator's Manual Page 15...
- Page 6 CLARKE TECHNOLOGY Model SPS-28 Main Frame, Brush Assembly and Drive System Drawing 1/99 10 11 12 11 16 17 38 39 24 25 75 76 36 67 Page 16 CLARKE TECHNOLOGY Model SPS-28 Space Sweeper Operator's Manual...
- Page 7 Strap, Static Discharge 903539 Belt, Brush Drive 798232 Spacer 815051 Knob, Handle 797236 Retainer 793923 Handle Assembly, Brush Lift 858207 Spacer 962546 Screw, 10 x ½ Rd. Hd. Type 23 CLARKE TECHNOLOGY Model SPS-28 Space Sweeper Operator's Manual Page 17...
- Page 8 CLARKE TECHNOLOGY Model SPS-28 Engine, Dust Control & Handle Assembly Drawing 4/99 53 72 11 11 12 11 10 13 95 14 16 Page 18 CLARKE TECHNOLOGY Model SPS-28 Space Sweeper Operator's Manual...
- Page 9 Filter, Dust 15724A Housing Asm., Dust Chamber 170266 Coupling 793422 Gasket, Dust Chamber 793421 Gasket, Dust Chamber Top NOTE: uindicates a change has taken place since last publication of this manual. CLARKE TECHNOLOGY Model SPS-28 Space Sweeper Operator's Manual Page 19...
- Page 10 BOTTOM 57 58 OPTIONAL SIDE BROOM 11 OR 63 ASSEMBLY...
- Page 11 796902 Pulley 61300A Bumper (Carpet Only) 796903 Pulley 980626 Washer, ½ Lock 960970 Shoulder Bolt, Pulley 980662 Washer (Carpet Only) 902659 Bearing 63900A Guard, Caster (Carpet Only) 167308 Ring, Retaining CLARKE TECHNOLOGY Model SPS-28 Space Sweeper Operator's Manual Page 21...
- Page 12 CLARKE TECHNOLOGY Model SPS-28 Wiring Diagram & Electrical Schematic 1/99 Page 24 CLARKE TECHNOLOGY Model SPS-28 Space Sweeper Operator's Manual...
- Page 13 Wire Assembly, #10 White 950805 Wire Assembly, Teminal Board - Mtr. 951004 Wire Assembly, #10 Black 794720 Insulator Motor 795220 Motor, Drive 911438 Block, Terminal 950813 Wire Assembly 842406 Cable CLARKE TECHNOLOGY Model SPS-28 Space Sweeper Operator's Manual Page 25...
