- Page 1 VIPRO VP7806 Fanless Panel PC with 6.5” TFT LCD and Touch Screen Revision 1.0 100-04122010-1958...
-
Page 2: Copyright And Trademarks
However, VIA Technologies assumes no responsibility for the use or misuse of the information in this document and for any patent infringements that may arise from the use of this document. -
Page 3: Safety Precautions
Safety Precautions Do’s Always read the safety instructions carefully. Keep this User's Manual for future reference. All cautions and warnings on the equipment should be noted. Keep this equipment away from humidity. Lay this equipment on a reliable flat surface before setting it up. -
Page 4: Optional Accessories
VIPRO VP7806-R1N13A1 Standar Standar Standar Standard d d d kit kit kit kit 1 x VIPRO VP7806 unit 1 x Software driver and utility CD 2 x Wall-mount bracket 2 x Panel-mount bracket 1 x package of panel/wall mounting screw 1 x 0.5cc Thermally Conductive Dispensable Gel... -
Page 5: Table Of Contents
Power cable 2-pole Phoenix..............10 Panel-mount Brackets ................10 Wall-mount Brackets ..................11 Panel/Wall-mounting Screws ..............11 Heatsink Grease ....................11 2 VIPRO VP7806 Hardware Functionality ...........13 Introduction of I/O Layout ................14 Front View Layout..................14 Top View Layout ..................14 Bottom View Layout...................15 Right and Left View Layout..............15 I/O Connector Functionality................16... - Page 6 Setting Up the Jumpers..................36 Jumper Settings.....................36 CLEAR_CMOS: Clear CMOS jumper...........37 AT/ATX Power mode Select ..............39 PVDD2_SEL: LCD power jumper............40 4 BIOS Setup......................41 Entering the BIOS Setup Menu ..............42 Control Keys ......................42 Navigating the BIOS Menus ................43 Getting Help ......................43 Main Menu ......................44 Standard CMOS Features.................44 Advanced BIOS Features .................44 Advanced Chipset Features..............44...
- Page 7 OS Select for DRAM > 64 MB..............50 HDD S.M.A.R.T Capability .................50 Video BIOS Shadow ...................50 Full Screen Logo Show ................50 Summary Screen Show................50 CPU Feature......................51 Thermal Management................51 Thermal Monitor Bus Ratio..............51 Thermal Monitor Bus VID ................51 Hard Disk Boot Priority..................52 Advanced Chipset Features.................53 Memory Hole ....................53 System BIOS Cacheable ................53...
- Page 8 Onboard Serial Port 1 ................61 COM1 RS232/422/485 Type ..............61 Onboard Serial Port 2 ................61 COM2 RS232/422/485 Type ..............61 Onboard Serial Port 3 ................61 Onboard Serial Port 4 ................61 USB Device Setting ...................62 USB 1.0 Controller ..................62 USB 2.0 Controller ..................62 USB Operation Mode ................62 USB Keyboard Function................62 USB Mouse Function .................62...
- Page 9 DDR CAS Latency Control ...............71 DDR Burst Length..................71 DDR 1T Command Rate ................71 DRDY Table .....................71 ODT........................71 Spread Spectrum ..................72 Load Optimized Defaults................73 Set Supervisor/User Password ..............74 Save & Exit Setup ....................75 Exit Without Saving ..................76 5 Driver Installation....................77 Driver Utilities.......................78 Getting Started ....................78 Running the Driver Utilities CD .............78 CD Content ......................79...
-
Page 11: Product Overview
Product Overview... - Page 12 Its IP65 compliant front panel protects against water and dust. The VIPRO VP7806 accepts a wide range of DC power input voltages (from DC 7V – 36V). It provides multiple external I/O connectors such as Gigabit Ethernet ports, USB 2.0 ports, configurable COM ports, LVDS port and VGA port.
-
Page 13: Key Features
EATURES Fanless and Ultra Low Power Consumption Fanless and Ultra Low Power Consumption Fanless and Ultra Low Power Consumption Fanless and Ultra Low Power Consumption VIA Nano 1.3 GHz Ultra Low Power processor. Noise free and fanless operation. C C C C ompact ompact ompact ompact and R... -
Page 14: Specifications
PECIFICATIONS Processor Core Logic System • VIA Nano 1.3 GHz Processor • NanoBGA2 package: compact 21 mm x 21 mm • 800 MHz Front Side Bus speed • 1 MB L2 Cache memory System Chipset System Chipset System Chipset System Chipset •... - Page 15 Touch Screen Type Type Type Type • Fire-Wire Analog resistive Transparency Transparency Transparency Transparency • 80% ± 3% Controller: Controller: Controller: Controller: • Built-in system a EETI ETP-CP-S5XU, USB interface controller Software Driver: Software Driver: Software Driver: Software Driver: • Supports Windows XP and Windows 7 Durabuility (Knock Test) Durabuility (Knock Test): : : : Durabuility (Knock Test)
- Page 16 System I/O ports Top I/O Coastline on PC Unit I/O Coastline on PC Unit I/O Coastline on PC Unit I/O Coastline on PC Unit • One DB-9 connector for a VGA/CRT interface • One DB-26 connectors for a 24-bit single channel LVDS interface (LVDS2) •...
- Page 17 Environment Operating Operating Temperature Operating Operating Temperature Temperature Temperature • With CompactFlash disk only: -20°C up to 60 °C Specifications • With 2.5-inch hard disk drive: 0°C up to 45 °C Storage Temperature Storage Temperature Storage Temperature Storage Temperature • -20°C up to 70 °C Relative Relative H H H H umidity Relative...
-
Page 18: Vipro Vp7806 Dimensions
VIPRO VP7806 D IMENSIONS Front View Back View... -
Page 19: Right And Left View
Right and Left View... -
Page 20: Accessories
CCESSORIES Power cable 2-pole Phoenix Part # 99G33-250073 Panel-mount Brackets Part # 99G42-091536-A1... -
Page 21: Wall-Mount Brackets
Wall-mount Brackets Part # 99G42-091376-A1 Panel/Wall-mounting Screws Part # 99G44-010395 Heatsink Grease Part # 99G26-110022... -
Page 23: Vipro Vp7806 Hardware Functionality
VIPRO VP7806 Hardware Functionality This chapter provides information about the VIPRO VP7806’s external I/O connectors, switches, LED indicators and its functionality. Section includes: Introduction of I/O Layout I/O Connectors Functionality... -
Page 24: Introduction Of I/O Layout
I/O L NTRODUCTION OF AYOUT Front View Layout Top View Layout... -
Page 25: Bottom View Layout
Bottom View Layout Right and Left View Layout... -
Page 26: I/O Connector Functionality
I/O C ONNECTOR UNCTIONALITY Power Button The VIPRO VP7806 comes with a dual function Power On/Off button on the bottom I/O side that supports Soft Power -On/Off (i.e., Instant off or 4-Second Delay) and Suspend. Power Input Connector The VIPRO VP7806 comes with a Phoenix connector on the bottom I/O side that carries 7 ~ 36VDC external power input. -
Page 27: Com Port Connectors
COM Port Connectors The VIPRO VP7806 provides four D-Sub 9-pin connectors: COM1, COM2, COM3 and COM4. COM1 and COM2 ports The VIPRO VP7806 provides two D-Sub 9-pin connectors (COM1 and COM2) for RS-232/422/485 serial communications on bottom I/O side. RS-232... -
Page 28: Led Indicators
Refer to the table list below for the pin assignments of COM3 and COM4. Signal LED Indicators There are two LEDs on the VIPRO VP7806 bottom I/O side for indicating system status: • PWR LED PWR LED PWR LED PWR LED is for power status and flashes in green •... -
Page 29: Lvds Connector: Lvds2
LVDS Connector: LVDS2 The VIPRO VP7806 supports one external 24-bit single channel LVDS interface connector using D-Sub 26-pin connector on top I/O side. The connector also carries the inverter control signals. Built in LCD Backlight On/Off and Brightness control signals LVDS2 connector includes the following control signals: BLON, and BRIGHTNESS_CTL. -
Page 30: Lan Ports: Gigabit Ethernet Port 1 And 2
LAN ports: Gigabit Ethernet Port 1 and 2 The VIPRO VP7806 system is equipped with two VIA VT6130 PCIe Gigabit Ethernet controllers on the mainboard. The controllers provide support for two Gigabit Ethernet RJ-45 ports (LAN1 and LAN2) on top I/O side. Both are fully compliant with IEEE 802.3 (10BASE-T), 802.3u (100BASE-TX), and 802.3ab (1000BASE-T) -
Page 31: Hardware Installation And Upgrade
Hardware Installation and Upgrade This chapter provides information about hardware installation procedures. It is recommended to use a grounded wrist strap before handling computer components. Electrostatic discharge (ESD) can damage some components. Section includes: Basic Installation Setting Up the Jumpers... -
Page 32: Basic Installation
ASIC NSTALLATION Opening the Chassis Step 1 Step 1 Step 1 Step 1 Remove the two screws from the top I/O side. Step 2 Step 2 Step 2 Step 2 Then remove the two screws from the bottom I/O side. - Page 33 Step 3 Step 3 Step 3 Step 3 Slide the panel upward until the display panel is released from locking mechanism. Step 4 Step 4 Step 4 Step 4 Lift the display panel a little bit perpendicularly from the main body of VIPRO 7806.
- Page 34 Step 5 Step 5 Step 5 Step 5 Then disconnect connector A and connector B cables from the connectors on the main body of the VIPRO 7806 as show in the figure below. Note: Note: Note: Note: You can disconnect the connectors either from the main body or from back of the panel.
-
Page 35: Installing The Memory
Installing the Memory Step 1 Step 1 Step 1 Step 1 Remove the hard disk brackets by unscrewing the four screws. Step 2 Step 2 Step 2 Step 2 Unscrew the two screws to remove the portion of the memory heatsink in order to locate the memory slot. - Page 36 Step Step Step Step 3 3 3 3 Insert the memory module into the SODIMM socket at a 45 degree angle. Then push down until the memory module snaps into place. The SODIMM socket has two locking mechanisms that will click once the memory module has been fully inserted. Step Step 4 4 4 4 Step...
- Page 37 Step 5 Step 5 Step 5 Step 5 Peel the protective layers off of the memory thermal pad on the bottom of the memory heatsink. Step Step 6 6 6 6 Step Step Reinstall the memory heatsink and secure it with two screws.
-
Page 38: Installing The Sata 2.5" Hard Disk
Installing the SATA 2.5” hard disk Step 1 Step 1 Step 1 Step 1 Remove the SATA 2.5” hard disk mounting brackets. Step 2 Step 2 Step 2 Step 2 Prepare the hard disk screws and rubber washer. Align the mounting holes on the SATA 2.5”... - Page 39 Step Step Step Step 3 3 3 3 Align the mounting brackets with the mounting holes on the hard disk plate. Secure the brackets in place with four screws. Then connect the SATA power and data cables of the hard disk, also connect the other ends of the cables to the SATA port and SATA power port onto the board.
-
Page 40: Installing The Compactflash Card
Step 1 Step 1 Step 1 Step 1 Locate the CompactFlash access cover on the top I/O side of the VIPRO VP7806 and remove the screw to remove the access cover. Step 2 Step 2 Step 2 Step 2 Ensure the proper orientation of the CompactFlash card with the CompactFlash slot before inserting. -
Page 41: Installing Panel Mounting Kit
Note: Note: Note: Note: The cutout shown above is for embedding the VIPRO VP7806 directly into the wall without an additional chassis. If using a chassis to mount the VIPRO VP7806, ensure the cutout is sufficient for the chassis. - Page 42 Once the cutout has been prepared, slide the VIPRO VP7806 backwards into the panel opening. Step 3 Step 3 Step 3 Step 3 From the other side of the panel, align the panel mounting brackets on the rear side of VIPRO VP7806 and attach the four screws.
- Page 43 Step 4 Step 4 Step 4 Step 4 Secure the VIPRO VP7806 to the wall with four screws.
-
Page 44: Installing Wall Mounting Kit (Optional)
Installing Wall mounting kit (optional) Wall mounting should be used when the VIPRO VP7806 cannot be embedded into the wall. When wall mounting, the entire system will be exposed. For details on the assembly of the wall mounting kit, refer to the installation guide provided with the wall mounting kit. - Page 45 Step Step 2 2 2 2 Step Step Secure the both mounting brackets to the wall with four wall- mounting screws.
-
Page 46: Setting Up The Jumpers
ETTING P THE UMPERS This section will explain how to configure the VIPRO VP7806 to match the needs of your application by setting the jumpers. Jumper Settings The VIPRO VP7806 internal board provides a jumper for setting some system hardware functions. The jumper is the simplest kind of electrical switch. -
Page 47: Clear_Cmos: Clear Cmos Jumper
CLEAR_CMOS: Clear CMOS jumper The CMOS RAM of VIPRO VP7806 system internal motherboard stores system configuration data and has an onboard battery power supply. Step 1 Step 1 Step 1 Step 1 Remove the front bezel by following the procedures in Opening the Chassis. - Page 48 Step 3 Step 3 Step 3 Step 3 To reset the CMOS settings, set the jumper on pin 2 and 3 while the system is off. Return the jumper to pin 1 and 2 afterwards. Setting the jumper while the system is on will damage the mainboard.
-
Page 49: At/Atx Power Mode Select
AT/ATX Power mode Select The VIPRO VP7806 supports two kinds of power modes: ATX (default) and AT. The ATX mode requires a standby power connection and a power supply on signal to turn on the main power supply. The AT mode does not require a standby power connection but needs to be connected to ground to boot up properly. -
Page 50: Pvdd2_Sel: Lcd Power Jumper
PVDD2_SEL: LCD power jumper The VIPRO VP7815 system internal motherboard provides an onboard jumper named “PVDD2_SEL” for setting the LCD signal power to either 5V or 3.3V. When connecting the LVDS LCD Panel display to LVDS2 on the top I/O side, the setting of PVDD2_SEL must match the power requirements of the connected LVDS Panel display. -
Page 51: Bios Setup
BIOS Setup This chapter gives a detailed explanation of the BIOS setup functions. -
Page 52: Entering The Bios Setup Menu
BIOS S NTERING THE ETUP Power on the computer and press <Delete Delete> during the beginning Delete Delete of the boot sequence to enter the BIOS setup menu. If you missed the BIOS setup entry point, restart the system and try again. ONTROL Keys Description... -
Page 53: Navigating The Bios Menus
BIOS M AVIGATING THE ENUS The main menu displays all the BIOS setup categories. Use the <Left Left Left>/<Right Left Right Right Right> and <Up Up>/<Down Down Down> arrow keys to select any item Down or sub-menu. Descriptions of the selected/highlighted category are displayed at the bottom of the screen. -
Page 54: Main Menu
The Main Menu contains thirteen setup functions and two exit choices. Use arrow keys to select the items and press <Enter Enter Enter Enter> to accept or enter Sub-menu. Standard CMOS Features Use this menu to set basic system configurations. Advanced BIOS Features Use this menu to set the advanced features available on your system. -
Page 55: Pnp/Pci Configurations
PnP/PCI Configurations Use this menu to set the PnP and PCI configurations. PC Health Status This menu shows the PC health status. Frequency/Voltage Control Use this menu to set the system frequency and voltage control. Load Optimized Defaults Use this menu option to load BIOS default settings for optimal and high performance system operations. -
Page 56: Standard Cmos Features
CMOS F TANDARD EATURES Date The date format is [Day, Month, Date, Year] Time The time format is [Hour : Minute : Second] Video Settings: [EGA/VGA, CGA 40, CGA 80, MONO] Halt On Set the system’s response to specific boot errors. Below is a table that details the possible settings. -
Page 57: Ide Channels
IDE C HANNELS The specifications of your drive must match with the drive table. The hard disk will not work properly if you enter incorrect information in this category. Select “Auto Auto” whenever possible. If Auto Auto you select “Manual Manual Manual Manual”, make sure the information is from your hard... -
Page 58: Advanced Bios Features
BIOS F DVANCED EATURES Virus Warning Allows you to choose the VIRUS warning feature for IDE Hard Disk boot sector protection. Settings Description Enabled Turns on hard disk boot sector virus protection Disabled Turns off hard disk boot sector virus protection Note: Note: Note:... -
Page 59: Quick Power On Self-Test
Quick Power On Self-Test Shortens Power On Self-Test (POST) cycle to enable shorter boot up time. Settings Description Disabled Standard Power On Self Test (POST) Enabled Shorten Power On Self Test (POST) cycle and boot up time First/Second/Third Boot Device Set the boot device sequence as BIOS attempts to load the disk operating system. -
Page 60: Typematic Delay (Msec)
Typematic Delay (Msec) This item sets the delay between, when the key was first pressed and when the system begins to repeat the signal from the depressed key. Settings: [250, 500, 750, 1000] Security Option Selects whether the password is required every time the System boots, or only when you enter Setup. -
Page 61: Cpu Feature
CPU F EATURE Thermal Management This item sets CPU’s thermal control rule to protect CPU from overheat. Settings Description Thermal Monitor 1 On-die throtting Thermal Monitor 2 Ratio & VID transition Thermal Monitor 3 Dynamic Ratio & VID transition Disabled Disable the thermal monitor Thermal Monitor Bus Ratio This item sets the frequency (bus ratio) of the throttled... -
Page 62: Hard Disk Boot Priority
RIORITY This is for setting the priority of the hard disk boot order when the “Hard Disk” option is selected in the “[First/Second/Third] Boot Device” menu item. -
Page 63: Advanced Chipset Features
DVANCED HIPSET EATURES Caution: Caution: Caution: Caution: The Advanced Chipset Features menu is used for optimizing the chipset functions. Do not change these settings unless you are familiar with the chipset. Memory Hole Settings: [Disabled, 15M – 16M] System BIOS Cacheable Settings: [Disabled, Enabled] Video RAM Cacheable Settings: [Disabled, Enabled]... -
Page 64: Internal Vga Control
VGA C NTERNAL ONTROL VGA Share Memory Size This setting allows you to select the amount of system memory that is allocated to the integrated graphics processor. Settings: [Disabled, 64M, 128M, 256M] Direct Frame Buffer Settings: [Disabled, Enabled] Select Display Device This setting refers to the type of display being used with the system. -
Page 65: Cpu & Pci Bus Control
CPU & PCI B ONTROL PCI Master 0 WS Write Settings: [Disabled, Enabled] PCI Delay Transaction Settings: [Disabled, Enabled] VIA PWR Management Settings: [Disabled, Enabled]... -
Page 66: Integrated Peripherals
NTEGRATED ERIPHERALS... -
Page 67: Via Onchip Ide Device
VIA O IDE D EVICE CF Card ATA66 Settings: [Disabled, Enabled] SATA Controller Settings: [Disabled, Enabled] IDE DMA Transfer Access Settings: [Disabled, Enabled] OnChip IDE Channel 1 Settings: [Disabled, Enabled] IDE Prefetch Mode Settings: [Disabled, Enabled] Secondary Master PIO Settings: [Auto, Mode 0, Mode 1, Mode 2, Mode 3, Mode 4] Secondary Slave PIO Settings: [Auto, Mode 0, Mode 1, Mode 2, Mode 3, Mode 4]... -
Page 68: Secondary Master Udma
Secondary Master UDMA Settings: [Disabled, Auto] Secondary Slave UDMA Settings: [Disabled, Auto] IDE HDD Block Mode Settings: [Disabled, Enabled]... -
Page 69: Via Onchip Pci Device
VIA O PCI D EVICE Azalia HDA Controller Settings: [Disabled, Auto] OnBoard LAN Boot ROM Settings: [Enabled, Disabled]... -
Page 70: Superio Device
IO D UPER EVICE Onboard Parallel Port Settings: [Disabled, 378/IRQ7, 278/IRQ5, 3BC/IRQ7] Parallel Port Mode Settings: [SPP, EPP, ECP, ECP+EPP] Watch Dog Timer Select Settings: [Disabled, 10 Sec, 20 Sec, 30 Sec, 40 Sec, 1 Min, 2 Min, 4 Min]... -
Page 71: Superio Com Ports (Uarts)
IO COM P (UART UPER ORTS Onboard Serial Port 1 Settings: [Disabled, 3F8/IRQ4, 2F8/IRQ4, 3E8/IRQ4, 2E8/IRQ4] COM1 RS232/422/485 Type Settings: [By Default, RS232, RS422, RS485] Onboard Serial Port 2 Settings: [Disabled, 3F8/IRQ4, 2F8/IRQ4, 3E8/IRQ4, 2E8/IRQ4] COM2 RS232/422/485 Type Settings: [By Default, RS232, RS422, RS485] Onboard Serial Port 3 Settings: [Disabled, 3F8/IRQ4, 2F8/IRQ4, 3E8/IRQ4, 2E8/IRQ4] Onboard Serial Port 4... -
Page 72: Usb Device Setting
USB D EVICE ETTING USB 1.0 Controller Enable or disable Universal Host Controller Interface for Universal Serial Bus. Settings: [Disabled, Enabled] USB 2.0 Controller Enable or disable Enhanced Host Controller Interface for Universal Serial Bus. Settings: [Disabled, Enabled] USB Operation Mode Auto decide USB device operation mode. -
Page 73: Usb Storage Function
USB Storage Function Enable or disable Legacy support of USB Mass Storage. Settings: [Disabled, Enabled] USB Wireless LAN Support Settings: [Disabled, Enabled]... -
Page 74: Freedos Configuration
DOS C ONFIGURATION Boot into FreeDOS The system will boot to FreeDOS. Settings: [Disabled, Enabled]... -
Page 75: Power Management Setup
OWER ANAGEMENT ETUP ACPI Suspend Type Settings Description S1(POS) S1/Power On Suspend (POS) is a low power state. In this state, no system context (CPU or chipset) is lost and hardware maintains all system contexts. S3(STR) S3/Suspend To RAM (STR) is a power-down state. In this state, power is supplied only to essential components such as main memory and wakeup-capable devices. -
Page 76: Video Off Option
Video Off Option Select whether or not to turn off the screen when system enters power saving mode, ACPI OS such as Windows XP will override this option. Settings Description Always On Screen is always on even when system enters power saving mode Suspend ->... -
Page 77: Wakeup Event Detect
AKEUP VENT ETECT PowerOn by PCI Card Enables activity detected from any PCI card to power up the system or resume from a suspended state. Such PCI cards include LAN, onboard USB ports, etc. Settings: [By OS, Enabled] RTC Alarm Resume Set a scheduled time and/or date to automatically power on the system. -
Page 78: Pnp/Pci Configurations
P/PCI C ONFIGURATIONS Note: Note: Note: Note: This section covers some very technical items and it is strongly recommended to leave the default settings as is unless you are an experienced user. Init Display First Settings: [Onboard, PCIEx] PNP OS Installed Settings Description BIOS will initialize all the PnP cards... -
Page 79: Resources Controlled By
Resources Controlled By Enables the BIOS to automatically configure all the Plug-and-Play compatible devices. Settings Description Auto(ESCD) BIOS will automatically assign IRQ, DMA and memory base address fields Manual Unlocks “IRQ Resources” for manual configuration PCI/VGA Palette Snoop Settings: [Disabled, Enabled] Assign IRQ for VGA Assign IRQ for VGA devices. -
Page 80: Pc Health Status
PC H EALTH TATUS The PC Health Status displays the current status of all of the monitored hardware devices/components such as CPU voltages, temperatures and fan speeds. -
Page 81: Frequency/Voltage Control
REQUENCY OLTAGE ONTROL DRAM Frequency Settings: [DDR2-400, DDR2-533, DDR2-667, SPD] DDR CAS Latency Control Settings: [2T, 3T, 4T, 5T, 6T, SPD] DDR Burst Length Settings: [4, 8, SPD] DDR 1T Command Rate Settings: [Disabled, Enabled] DRDY Table Settings: [Slowest, Optimize] Settings: [Disabled, Enabled]... -
Page 82: Spread Spectrum
Spread Spectrum When the mainboard's clock generator pulses, the extreme values (spikes) of the pulses create EMI (Electromagnetic Interference). The Spread Spectrum function reduces the EMI generated by modulating the pulses so that the spikes of the pulses are reduced to flatter curves. -
Page 83: Load Optimized Defaults
PTIMIZED EFAULTS This option is for restoring all the default optimized BIOS settings. The default optimized values are set by the mainboard manufacturer to provide a stable system with optimized performance. Entering “Y Y Y Y ” and press <Enter Enter Enter>... -
Page 84: Set Supervisor/User Password
UPERVISOR ASSWORD This option is for setting a password for entering BIOS Setup. When a password has been set, a password prompt will be displayed whenever BIOS Setup is run. This prevents an unauthorized person from changing any part of your system configuration. -
Page 85: Save & Exit Setup
& E ETUP Entering “Y Y Y Y ” saves any changes made, and exits the program. Entering “N N N N ” will cancel the exit request. -
Page 86: Exit Without Saving
ITHOUT AVING Entering “Y Y Y Y ’ discards any changes made, and exits the program. Entering “N N N N ” will cancel the exit request. -
Page 87: Driver Installation
Driver Installation This chapter gives you brief descriptions of each mainboard driver and application. You must install the VIA chipset drivers first before installing other drivers such as VGA drivers. The applications will only function correctly if the necessary drivers are already installed. -
Page 88: Driver Utilities
RIVER TILITIES Getting Started The VIPRO VP7806 includes a driver CD that contains the drivers and software for enhancing the performance of the system. The drivers can also be downloaded from http://www.via.com.tw. Note: Note: Note: Note: The driver utilities and software are updated from time to time. -
Page 89: Cd Content
CD C ONTENT VIA Hyperion Pro Driver Hyperion Pro Driver Hyperion Pro Driver Hyperion Pro Driver Compatible with all current VIA chipsets Includes support for INF, AGP, V-RAID, and IDE VIA Graphics Driver VIA Graphics Driver VIA Graphics Driver VIA Graphics Driver Enhances the onboard VIA graphic chip.
