INSTALLATION / CONNECTION

Wiring connection

(for
(For
Rear, front, subwoofer output
Antenna terminal
To front speaker (left)
To front speaker (right)
To rear speaker (left)
To rear speaker (right)
Car fuse box
Ignition switch
Car fuse box
Battery To the metallic body or chassis of the car
28
/ /
/ )
White
White/Black
Gray/Black
Green
Green/Black
Purple
Purple/Black
Red (Ignition wire)
Yellow (Battery wire)
Black (Ground wire)
)
(For )
Front, Rear/subwoofer output
Fuse (10 A)
Microphone input jack ( 13)
If no connections are made, do not let the wire come out from the tab.
Gray
Light blue/yellow
(Steering remote control wire)
Brown
(Mute control wire)
Blue/White
(Power control wire/
Antenna control wire)
When connecting to an external amplifier,
connect its ground wire to the car's chassis to
avoid damaging the unit.
To the steering wheel remote control adapter
To connect the Kenwood navigation system,
refer your navigations manual
To the power control terminal when using the
optional power amplifier or to the antenna
control terminal in the vehicle
