WowWee Robosapien Supplementary Manual

Using the Robosapien™ remote controller with Femisapien™
You cam use the WowWee™ Robosapien™ remote controller (included) to control
Femisapien.
Battery details
The remote controller requires 3 x "AAA" size batteries. To install the batteries, do
the following:
1. Open the battery compartment located on
the underside of the remote controller using a
Phillips screwdriver (not included) to remove
the screws on the battery compartment cover.
2. Insert the batteries according to the diagram.
Ensure that the positive and negative polarities
match the illustrations inside the battery
compartment.
3. Replace the battery compartment covers and
replace the screws using the screwdriver. Do
not over-tighten.
Shift levels
The remote controller has 3 shift levels. You can change levels by pressing the
Select button
SELECT SELECT
explained in Table 1, below.
Table 1
LED Color
Green
Red
IMPORTANT: After you send a command the remote controller will reset to Shift
level 1. That is, if you require Shift level 2 or 3, you need to select the shift level each
time you send a command.
A
. The LED on the remote controller indicates the shift level as
1.5V "AAA"
LR03 UM4
1.5V "AAA"
LR03 UM4
1.5V "AAA"
LR03 UM4
Shift level
Level 1
Level 2
Level 3
Battery
compartment
door
